Blodgett B48-BBBB-SU Specification Sheet

B48-BBBB-SU
48" Heavy Duty Sectional Range with
Eight Open-Top 35K BTU Step Up Burners
Model B48A-BBBB-SU with 24" Flue Riser
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Flue riser
24"
36"
Single-shelf (mounts on 24" flue riser)
Solid shelf
Tubed shelf
Double-shelf (mounts on 36" flue riser)
Solid shelves
Tubed shelves
Stainless-steel back
Deep range depth
Additional oven racks
Bolt down flange feet
Casters (in lieu of legs)
Open frame base with casters
Cable restraint kit for units on casters
Project
Item No.
Quantity
Model B48A-BBBB-SU (Convection Oven Base)
Model B48D-BBBB-SU (Standard Oven Base)
Model B48N-BBBB-SU (Modular Range-Top)
The Blodgett 48" wide sectional-range with eight open-top step up burners
is available with a choice of two types of base (a convection oven or a
standard oven) or with no base (for mounting as a modular range-top).
Three flue-riser heights are available, and the flue riser can support up to
250 pounds (for an optional shelf, salamander-broiler, or cheese melter).
An optional rearward-extending flue riser is available to increase the overall
depth to match a deep battery. Battery-design assistance is available!
SPECIFY
Gas Type
Manifold
Flue Riser Height
Range Depth
Position in Battery
Electric Power (ovens)
Operating altitude (if above 2000 ft (700 meters) _____________________
Blodgett can often accommodate special or custom requirements. Contact your
Blodgett representative.
STANDARD FEATURES (
Eight open-top 35,000 BTU burners with separate controls
Removable welded grates
5" flue riser
7" stainless-steel front rail with "belly bar"
Standard range depth
Battery end-units have solid side (no manifold cover plate)
Stainless-steel front and sides
Fully insulated lining and burner boxes
6" adjustable legs (except on modular range-top model)
Warranty: two year parts and labor from date of purchase
STANDARD FEATURES (Convection & Standard
45,000 BTU oven with standing pilot (optional electronic ignition available)
Cool-to-the-touch oven handle
Recessed oven control panel for added reliability
Standard-oven interior is 14" high, 26" wide, 26.5" deep (so sheet pans fit
either way)
Two oven racks (2-1/4" between each of five positions)
"Insta-On" thermostat with a wide range of 150°F to 550°F
Convection-oven models have 1/3 hp, two-speed blower
Porcelain enamel oven interior
BLODGETT
www.blodgett.com
1100 Old Honeycutt Road Fuquay-Varina, NC 27526 USA
Phone: (877) 255-3976 • Fax: (866) 644-1354
Natural Gas Propane
Front (1-1/4") Rear (1")
5" 24" (option)
Standard Deep (option)
Left End Right End
120V 208/240V
)
All models
36" (option)
Not at End
)
Ovens
