Summary of Contents for Tricity Bendix TB1000 W
-
Page 1: Washing Machine
OPERATING & INSTALLATION INSTRUCTIONS WASHING MACHINE TB1000 W 35.292.493/0... -
Page 3: Important Safety Information
Under no circumstances should you attempt to repair the machine yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Contact your local Tricity Bendix Service Centre. Always insist on genuine Tricity Bendix spare parts. -
Page 4: Your New Washing Machine
Your New Washing Machine Your new washing machine, meets all modern needs for effective treatment of laundry with low water, energy and detergent consumption. Automatic cooling of the wash water to 60°C before draining, with the 90°C programme. This reduces thermal shock to fabrics, helping to prevent any creasing. -
Page 5: Table Of Contents
Technical Specifications Unpacking Positioning Water inlet Water drainage 8-11 Levelling Special conditions In the interest of the environment Electrical connections Permanent connection Tricity Bendix Service Force Addresses 12-14 16-17 18-19 20-21 Safety instructions Hints and tips Step by step instructions 29-30... -
Page 6: Description Of The Appliance
Description of the Appliance 1 Detergent dispenser drawer 2 “Mains-on” light 3 “Options” buttons 4 Programme guide 5 Program selector dial & ON/OFF switch 6 Door opening handle 7 Filter 8 Adjustable feet Detergent dispenser drawer Prewash Main Wash Fabric softener AL035... -
Page 7: The Control Panel
The Control Panel 1 Detergent dispenser drawer 2 Mains-on light This light illuminates when the appliance is operating. 3 HALF LOAD button Available for programmes 1 to 5. Pressing this button before starting the programme there will be one rinse less which leads to energy and water saving. -
Page 8: Operating Sequence
Operating Sequence Before your first wash, we recommend that you run a cotton cycle at 60°C, without any laundry in the machine, to remove any manufacturing residue from the drum and tub. Pour 1/2 a measure of detergent into the dispenser drawer and start the machine. -
Page 9: Start The Machine
5. Select the required programme Turn the programme selector dial CLOCKWISE to the required programme. 6. Start the machine Before starting up the machine check that: the appliance is plugged in the water supply taps are turned on the door and the detergent dispenser drawer are closed. -
Page 10: Washing 2 Kg Of Mixed Fabrics At 50 °C
WASHING 2 KG OF MIXED FABRICS AT 50 °C Suppose you have 2 kg of MIXED FABRICS to wash. They are rather delicate fabrics and should not be washed at a high temperature. 1. Load the laundry Open the door. Place the laundry in the drum, one item at a time, shaking out as much as possible. -
Page 11: Select The Required Programme
5. Select the required programme Turn the programme selector dial CLOCKWISE to the required programme 6. Start the machine Before starting up the machine check that: the appliance is plugged in the water supply taps are turned on the door and the detergent dispenser drawer are closed. -
Page 12: Washing Hints
Washing Hints Do NOT overload the machine. Weigh the laundry the first few times you use the appliance. The average weights of the most common items are listed below as a guide: 1000g = 1 kg Sheet Pillow case Tablecloth Serviette Tea towel Linen hand towel... -
Page 13: Which Detergent To Use
Which detergent to use?... To ensure you obtain the best wash results from your appliance, it is important to use the right detergent in your everyday wash, and only detergents recommended for use in automatic machines. To maintain the appearance of your clothes and household textiles and to make them last longer you should use different types of detergent for different washes, whether for whites, colours or delicates. -
Page 14: And In Which Form
And in which form? Not only are there different types of detergent, but they are also available in different forms. Whether you choose a powder or liquid in traditional or compact form is down to personal choice. Traditional Powders Pour the powder directly into the dispenser drawer. Do not sprinkle powder onto clothes in the machine drum. -
Page 15: Wash Care Symbols
Wash Care Symbols Wash care labels inside garments recommend how to launder your clothes with the best results. The care labelling code is in line with care labelling used in the rest of Europe. The symbols used make it easy to select the correct programme on your washing machine. -
Page 16: Washing Programmes
Washing Programmes Programmes for cotton and linen Degree of soil and type Wash programme White example heavy soiled Whites+Prewash garments, household underwear, towels. White example normally soiled Whites garments, household underwear, towels. Fast coloured cotton or Fast coloureds linen fabric, shirts, underwear, towels. -
Page 17: Washing Programmes
Washing Programmes Programmes for synthetics, delicates and wool Degree of soil and type Wash programme Synthetic or mixed fabrics, Mixed fabrics coloured garments, non- shrink shirts, blouses. Synthetic or mixed fabrics, Synthetics coloured garments, non- shrink shirts, blouses. Lightly soiled synthetic Quick &... -
Page 18: Maintenance And Cleaning
Maintenance and Cleaning Before any maintenance or cleaning is carried out you must DISCONNECT the appliance from the electricity supply Descaling The water we normally use contains lime. It is a good idea to periodically run a high temperature wash with detergent or use a descaler in the machine. -
Page 19: Cleaning The Filter
Cleaning the filter The water drain filter A clean filter is important for the correct functioning of the machine, and should therefore be cleaned after every washing programme. Open the filter door and place a container underneath to catch any spillage. If the filter is blocked and the machine is unable to drain you will need to drain the water manually from the machine at this stage. -
Page 20: Something Not Working
Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your Tricity Bendix Service Force Centre, please carry out the checks listed below. Important: If you call out an engineer to a fault if listed below or to repair a fault caused by incorrect use or installation a charge will be made even if the appliance is in guarantee. -
Page 21: Service & Spare Parts
Tricity Bendix Service Force Centre. Service & Spare Parts If you require an engineer or wish to purchase spare parts contact your local Tricity Bendix Service Force Centre by telephoning: 0990 929929 Your telephone call will be routed to the Service Centre covering your post code area. -
Page 22: Peace Of Mind For Twelve Months
This guarantee is in addition to your statutory and other legal rights. We, Tricity Bendix, undertake that if, within 12 months of the date of the purchase, this TRICITY BENDIX appliance or any part thereof is proved to be defective... -
Page 23: Installation Instructions
Installation Instructions It is dangerous to alter the specifications or attempt to modify this product in any way. Care must be taken to ensure that the appliance does not stand on the electrical supply cable. Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. -
Page 24: Unpacking
Unpacking All transit bolts and packing must be removed before using the appliance You are advised to keep all the packaging for re-use in case the appliance has to be transported again. Unscrew and remove the three rear transit bolts (using a spanner). -
Page 25: Positioning
Positioning Your new Tricity Bendix washing machine has been designed to be permanently plumbed in to your home’s water supply and drainage system. However, if this is not possible, it may be connected to suitable existing taps, with the drain hose discharging into the sink. -
Page 26: Water Drainage
Water drainage This appliance is designed to be permanently plumbed into your home's water supply and drainage system. The appliance drain hose should hook (use the plastic “U-piece” supplied) into a standpipe with an internal diameter of approximately 38mm (see diagram) thus ensuring there is an air break between the drain hose and standpipe. -
Page 27: Levelling
Levelling Level the washing machine by loosening or tightening the feet. Once in the right position fix the feet by pushing the nuts against the base of the case. Accurate levelling prevents vibration, noise and displacement of the machine during operation. After levelling the machine, secure the feet by tightening the ring nuts with the aid of a screwdriver. -
Page 28: Electrical Connections
The cover/carrier is indicated by the coloured insert at the base of the plug. A replacement cover/carrier must be obtained from your local Tricity Bendix Service Centre, whose address are listed at the back of this instruction manual. WARNING: a cut off plug inserted into a 13 amp socket is a serious safety (shock) hazard. -
Page 29: Tricity Bendix Service Force Addresses
Tricity Bendix, 55-77High Street, Slough, Berkshire SL1 1DZ Consumer care telephone number 08705 950950 © Electrolux Household Appliances Limited...
