- Page 1 OPERATING AND INSTALLATION INSTRUCTIONS MODEL NO. SI 251...
-
Page 2: Technical Details
TECHNICAL DETAILS MODEL NO. SI 251 Voltage: 230/240 Volts AC 50Hz Wattage: 7.9/8.6 kW Height: 900mm Width: 500mm Depth: 600mm This appliance complies with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. CE Marking Directive 93/68/EEC. -
Page 3: Table Of Contents
CONTENTS Technical Details ................. 2 Contents . - Page 4 CONTENTS Care and Cleaning ................20 Cleaning Materials .
-
Page 5: Preface
They have been approved by BEAB (British Electrotechnical Approvals Board) and are covered by a 12 month parts and labour guarantee. To get the best from your new Tricity Bendix cooker, we ask that you PLEASE READ THESE INSTRUCTIONS CAREFULLY. Particular attention should be made to cooking times and temperatures which may differ from your previous cooker. -
Page 6: Safety
SAFETY THESE WARNINGS ARE PROVIDED IN THE INTERESTS OF YOUR SAFETY. ENSURE THAT THEM ALL BEFORE INSTALLING OR USING THE COOKER. PLEASE READ CAREFULLY BEFORE INSTALLATION This appliance is heavy and care must be taken when moving it. Ensure that all packaging, both inside and outside the appliance, has been removed before the appliance is used. -
Page 7: After Use
Ensure that all vents are left unobstructed to ensure ventilation of the oven cavity. Ensure that the anti-tilt shelves are put in place correctly. Refer to instructions on page 16. Never line any part of the cooker with aluminium foil. Do not allow heatproof cooking roasting bags to come into contact... -
Page 8: Introduction
INTRODUCTION WARNING: THIS APPLIANCE MUST BE EARTHED RATING PLATE Record the model, product and serial numbers on the back cover of this instruction book, from the rating plate. This is situated on the base of the appliance on the front right hand side. The appliance must be protected by a suitably rated fuse or circuit breaker. -
Page 9: General Notes On Using Your Cooker
Overhanging surfaces or a cooker hood should be a minimum of 685mm above the hob. It is important to ensure that the appliance is level after installation. Levelling feet are fitted to the front of the appliance to accommodate uneven floors. FITTING THE STABILITY BRACKET A stability bracket is included with this appliance, which must be fitted during installation of the... -
Page 10: Getting To Know Your Cooker
GETTING TO KNOW YOUR COOKER THE CONTROL PANEL FEATURES Hotplate Controls Fan Oven/Grill Control Oven/Grill Indicator Neon... -
Page 11: The Sealed Hotplates
THE SEALED HOTPLATES BEFORE USING THE HOTPLATES FOR THE FIRST TIME Turn the control knob to a medium/high setting and allow the hotplate to heat, uncovered by a saucepan for 3-5 minutes. This hardens the protective coating on the hotplates, and makes it more resistant to normal use. A harmless smoke will be given off from the hotplates. -
Page 12: Deep Fat Frying
DEEP FAT FRYING SPECIAL FRYING NOTE: For safety purposes when deep fat frying, fill the pan one-third full of oil, DO NOT cover the pan with a lid and DO NOT leave the pan unattended. In the unfortunate event of a fire, switch OFF at the electricity supply and cover the pan with a lid or damp cloth to assist in smothering the flames. -
Page 13: The Grill
THE GRILL CAUTION - ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD BE KEPT AWAY. SELECTING THE GRILL To operate the grill, turn the oven/grill control clockwise until the grill setting oven/grill on control panel. Close the oven door. -
Page 14: Hints And Tips
To correctly locate the grill pan on the shelf, ensure that the cut out on the underside of the handle bracket locates over the front bar of the shelf. To check the progress of the food being grilled, the grill pan should be withdrawn on the shelf to tend the food during cooking, or the carrier shelf can be lifted away from the cooker and rested on a heat resistant work surface. -
Page 15: The Fan Oven
THE FAN OVEN USES OF THE FAN OVEN The oven is heated by the element around the fan situated behind the back panel. The fan draws air from the oven, the element heats the air which is circulated into the oven via the vents in the back panel. The advantages of fanned oven cooking are: PREHEATING The fan oven quickly reaches its temperature, so it is not usually necessary to preheat the oven. -
Page 16: To Fit The Oven Shelves
TO FIT THE OVEN SHELVES The shelves should be fitted with the straight rods uppermost on the frame and the forms towards the back of the oven. If not fitted correctly the anti-tilt and safety stop mechanism will be affected. Back of the Oven Straight Rods HINTS AND TIPS... -
Page 17: Oven Cooking Chart
OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperatu by 10°C to suit individual preferences and requirements. FOOD Biscuits Bread Bread rolls/buns Cakes: Small & Queen Sponges Victoria Sandwich Madeira Rich Fruit... -
Page 18: Roasting Chart
ROASTING CHART ROASTING CHART INTERNAL TEMPERATURES Rare : 50-60°C; Medium : 60-70°C; Well : 70-80°C MEAT Beef Beef, boned Mutton and Lamb Pork and veal Chicken Turkey and goose Duck Pheasant Rabbit Potatoes with meat Potatoes without meat The roasting temperatures and times given in the chart should be adequate for most joints, but slight adjustments may be required to allow for personal requirements and the shape and texture of the meat. -
Page 19: Defrost Feature
DEFROST FEATURE USES OF DEFROST FEATURE This function enables you to defrost most foods faster than some conventional methods as the oven fan circulates air around the food. It is particularly suitable for delicate frozen foods which are to be served cold e.g. -
Page 20: Care And Cleaning
CARE AND CLEANING ALWAYS SWITCH OFF THE SUPPLY BEFORE CLEANING CLEANING MATERIALS Before using any cleaning materials on your cooker, check that they are suitable and that their use is recommended by the manufacturer. Cleaners that contain bleach should NOT be used as they may dull the surface finishes. -
Page 21: Cleaning The Grill Pan, Grill Pan Grid And Oven Shelves
CLEANING THE GRILL PAN, GRILL PAN GRID AND OVEN SHELVES All removable parts, except the grill pan handle can be washed in the dishwasher. The grill pan and oven shelves may be cleaned using a soap impregnated steel wool pad. The grill pan grid should be cleaned using hot soapy water. -
Page 22: Cleaning The Door Glass
CLEANING THE DOOR GLASS To prevent damaging or weakening the door glass panels avoid the use of the following: Household detergents and bleaches Impregnated pads non-stick saucepans Brillo/Ajax pads or steel wool pads Chemical oven pads or aerosols Rust removers Bath/Sink stain removers CLEANING BETWEEN THE OUTER AND INNER DOOR GLASS... -
Page 23: Something Not Working
SOMETHING NOT WORKING? We strongly recommend that you carry out the following checks on your appliance before calling a Service Engineer. It may be that the problem is a simple one, which you can solve yourself without the expense of a service call. If our Service Engineer finds that the problem is listed below you will be charged for the call whether or not the appliance is under guarantee. -
Page 24: Service And Spare Parts
Dublin 12 Telephone: 01 4090754 CUSTOMER CARE DEPARTMENT For general enquiries concerning your Tricity Bendix appliance, or further information on Tricity Bendix products, you are invited to contact our Customer Care Department by letter or telephone as follows: Customer Care Department... -
Page 25: Customer Service Centres
TRICITY BENDIX SERVICE FORCE 0870 5 929929 To contact your local Tricity Bendix Service Centre telephone CHANNEL ISLANDS NORTH EAST SCOTLAND NORTHERN IRELAND NORTH WEST WALES... -
Page 26: Tricity Bendix Service Force
TRICITY BENDIX SERVICE FORCE 0870 5 929929 To contact your local Tricity Bendix Service Centre telephone MIDLANDS LONDON & EAST ANGLIA SOUTH EAST (M23) (M57) SOUTH WEST SI251 311298707... -
Page 27: Guarantee Conditions
Standard guarantee conditions We, Tricity Bendix, undertake that if within 12 months of the date of the purchase this Tricity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate. - Page 28 TRICITY BENDIX,PO BOX 47,NEWBURY,BERKSHIRE, RG14 5XL TELEPHONE (01635) 525542 MODEL NO. PART NO. 311298707 SI 251 "...
