Contec F&eIT Series User Manual

10m/100m auto-mdix switching hub (8-port)
Hide thumbs Also See for F&eIT Series:
Table of Contents

Advertisement

Quick Links

Download this manual
MANUAL
SH-8008(FIT)H
HABEN SIE FRAGEN ODER
WÜNSCHEN SIE EIN INDIVIDUELLES ANGEBOT?
Unser Team berät Sie gerne persönlich.
TELEFON
+ 49 (0) 81 41/36 97-0
TELEFAX
+ 49 (0) 81 41/36 97-30
E-MAIL
info@plug-in.de
WWW.PLUG-IN.DE
ADRESSE
Am Sonnenlicht 5
D-82239 Alling bei München
Erwähnte Firmen- und Produktnamen sind zum Teil eingetragene Warenzeichen der jeweiligen Hersteller.

Advertisement

Table of Contents
loading

Related Manuals for Contec F&eIT Series

Summary of Contents for Contec F&eIT Series

  • Page 1 MANUAL SH-8008(FIT)H HABEN SIE FRAGEN ODER WÜNSCHEN SIE EIN INDIVIDUELLES ANGEBOT? Unser Team berät Sie gerne persönlich. TELEFON + 49 (0) 81 41/36 97-0 TELEFAX + 49 (0) 81 41/36 97-30 E-MAIL info@plug-in.de WWW.PLUG-IN.DE ADRESSE Am Sonnenlicht 5 D-82239 Alling bei München Erwähnte Firmen- und Produktnamen sind zum Teil eingetragene Warenzeichen der jeweiligen Hersteller.
  • Page 2 F&eIT Series 10M/100M AUTO-MDIX Switching HUB (8-port) SH-8008(FIT)H User’s Manual CONTEC CO.,LTD.
  • Page 3 Check Your Package Thank you for purchasing the CONTEC product. The product consists of the items listed below. Check, with the following list, that your package is complete. If you discover damaged or missing items, contact your retailer. Product Configuration List - Unit…1...

  • Page 4: Copyright

    No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document. The information in this document is subject to change without notice.

  • Page 5: Table Of Contents

    Table of Contents Check Your Package..........................i Copyright ............................ii Trademarks ............................ii Table of Contents ..........................iii Before Using the Product About the Unit ............................ 1 Features............................1 Customer Support ..........................2 Web Site............................2 Limited One-Year Warranty....................... 2 How to Obtain Service ........................
  • Page 6 External Dimensions......................... 17 SH-8008(FIT)H...

  • Page 7: Before Using The Product

    1. Before Using the Product 1. Before Using the Product This chapter provides information you should know before using the product. About the Unit SH-8008(FIT)H is an IEEE-802.3(Ethernet)/IEEE-802.3u(Fast Ethernet) compliant, 8-port switching HUB unit, equipped with full-duplex communication support, AutoMDI/MDI-X feature, and auto-recognition function of communication rates (10Mbps/100Mbps) and communication methods (half/full duplex) by the auto-negotiation feature.

  • Page 8: Customer Support

    You can download updated driver software and differential files as well as sample programs available in several languages. Note! For product information Contact your retailer if you have any technical question about a CONTEC product or need its price, delivery time, or estimate information. Limited One-Year Warranty CONTEC F&eIT products are warranted by CONTEC CO., LTD.

  • Page 9: Safety Precautions

    1. Before Using the Product Safety Precautions Understand the following definitions and precautions to use the product safely. Safety Information This document provides safety information using the following symbols to prevent accidents resulting in injury or death and the destruction of equipment and resources. Understand the meanings of these labels to operate the equipment safely.

  • Page 10: Handling Precautions

    Handling Precautions CAUTION Do not modify the unit. CONTEC will bear no responsibility for any problems, etc., resulting from modifying this unit. Do not use or store the equipment in a hot or cold place, or in a place that is subject to severe temperature changes.

  • Page 11: Environment

    1. Before Using the Product Environment Use this product in the following environment. If used in an unauthorized environment, the board may overheat, malfunction, or cause a failure. Operating temperature 0 - 50°C Operating humidity 10 - 90%RH(No condensation) Corrosive gases None Floating dust particles Not to be excessive...
  • Page 12 1. Before Using the Product SH-8008(FIT)H...

  • Page 13: Nomenclature Of Unit Components And Their Settings

    2. Nomenclature of unit Components and Their Settings 2. Nomenclature of unit Components and Their Settings Names of unit Components Figure 2.1 shows the nomenclature of unit components. POWER Power supply connector 5 - 24VDC LED : LINK/ACT Orange : 10M Green : 100M LED Indicator 10BASE-T/100BASE-TX port...
  • Page 14 2. Nomenclature of unit Components and Their Settings SH-8008(FIT)H...

  • Page 15: Installation And Connection

    3. Installation and Connection 3. Installation and Connection Installation Method Mounting on a DIN Rail Mounting procedure (1) Pushing the fixing hook with a flat-blade screwdriver renders it into a lock-enabled condition. 35mmDIN rail Press here to lift the fixing hook Figure 3.1.
  • Page 16 3. Installation and Connection (3) The fixing hook is automatically locked, and the unit can be mounted in one-touch. Fixing hook Side view Figure 3.1. Mounting on a DIN rail < 3 / 3 > SH-8008(FIT)H...
  • Page 17 3. Installation and Connection Removal procedures (1) Lower the fixing hook for the unit to unlock it. 35mmDIN rail Figure 3.2. Removing the unit from the DIN rail < 1 / 3 > (2) With the fixing hook unlocked, pull the lower part of the unit toward you. Side view Figure 3.2.

  • Page 18: Connection Method

    3. Installation and Connection Connection Method Supplying the Power to the Switching HUB Unit The Switching HUB Unit and power supply unit (POW-DD10GY, etc) can be cable connected using the detachable connector that is provided on either the unit face or the unit face. Keep the cable length no greater than 50cm (for AWG24 - 16).

  • Page 19: Connecting To A Network

    4. Connecting to a Network 4. Connecting to a Network Network Cables Cables meeting the following specifications should be used: Equal to or greater than Categor 3 UTP, STP cable (for 10BASE-T) Equal to or greater than Categor 5 UTP, STP cable (for 100BASE-TX) There are straight/cross UTP and STP cables.

  • Page 20: Limitations On The 10M Hub

    4. Connecting to a Network Limitations on the 10M HUB In the case of a 10BASE-T HUB, the number of HUB that can be connected in a cascading fashion using UTP cables is 4 levels. The maximum allowable UTP cable length between cascade-connected HUB is 100 meters.

  • Page 21: System Reference

    5. System Reference 5. System Reference Specification Table 5.1. Specifications Item Specification Ethernet standards IEEE802.3/IEEE802.3u -compliant Data transfer rate 10Mbps/100Mbps (auto-recognition) Access method CSMA/CD Communications method All ports: full/half duplex (auto-switching) Topology Star topology Flow control FullDuplex : IEEE802.3x compliant flow control HalfDuplex : Back pressure Number of effective ports Switching method...
  • Page 22 5. System Reference Table 5.2. Installation Environment Requirements Item Specification Operating temperature 0 - 50 ° C Storage temperature -10 - 60 ° C Humidity 10 - 90%RH(No condensation) Floating dust particles Not to be excessive Corrosive gases None Line-noise *1 AC line/2kV, Signal line/1kV (IEC1000-4-4Level 3, EN61000-4-4Level 3) Line-Noise Static electricity...
  • Page 23 5. System Reference External Dimensions (1.2) POWER 5 -24VDC LED : LINK/ACT Orange : 10M Green : 100M SH-8008H 64.7 52.4 [mm] Figure 5.1. External dimensions SH-8008(FIT)H...
  • Page 24 SH-8008(FIT)H User’s Guide CONTEC CO., LTD. May 2013 Edition No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. [05222013] [07062005] Management No. A-40-675 [05222013_rev3] Parts No.
