Summary of Contents for Crestron Isys TPS-4500
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON...
-
Page 3: Table Of Contents
Crestron TPS-4500 & TPS-4500L 12 Inch Tilt/Lectern Touchpanel Contents 12 Inch Tilt/Lectern Touchpanels: TPS-4500 & TPS-4500L Description .......................... 1 Functional Description.................... 1 Position Lock Buttons (TPS-4500 only) ..............4 Physical Description ....................5 Leading Specifications ......................7 Installation/Setup ......................... 9 Identity Code...................... -
Page 5: Inch Tilt/Lectern Touchpanels: Tps-4500 & Tps-4500L
(30.5-cm) active matrix SVGA (800 x 600) displays that accept an expansion card that contains a NTCS video input. These units are suitable for either tabletop mounting or a lectern/wall mount in any Crestron remote control system (herein referred to as the Cresnet system). The unit operates in a 16-bit graphics mode (65,536 colors);... - Page 6 64MB. The DRAM module can be replaced with modules up to 32MB. Installation instructions are provided with each memory module. Contact a Crestron customer service representative for details and pricing. Interface Modules (TPS-4500 only) Connect the TPS-4500 to an outboard interface module, which provides expanded network/video connections for the touchpanel system.
- Page 7 Crestron TPS-4500 & TPS-4500L 12 Inch Tilt/Lectern Touchpanel available, the table and diagram below provides information so that the cable can be fabricated on site. Refer to "Appendix A: RS-232 Protocol" on page 27 for protocol details. RS-232 Pinouts DESCRIPTION...
-
Page 8: Position Lock Buttons (Tps-4500 Only)
• 24VDC 2.0A – This direct current (DC) power socket connector is used to supply power via the external power pack. Crestron recommends the Crestron PW-2420RU for the TPS-4500. If a power pack other than this crestron model is obtained, verify that it meets the required specifications and polarity as shown after this paragraph. -
Page 9: Physical Description
Crestron TPS-4500 & TPS-4500L 12 Inch Tilt/Lectern Touchpanel Two-Hand Placement for Tilting a Touchpanel to a Vertical Position Once in user position, position lock is activated which means the touchscreen can not be forced to a horizontal position without depressing the position lock button(s). The touchscreen is still free to tilt up;... - Page 10 12 Inch Tilt/Lectern Touchpanel Crestron TPS-4500 & TPS-4500L Physical Views of the TPS-4500L Touchpanel (Rear and Side) 3.250 in 4.452 in 3.250 in (8.255 cm) (11.308 cm) (8.255 cm) 10.223 in (25.966 cm) TPS-4500 The 12-inch (30.5-cm) touch sensitive viewing screen is located on the front of the TPS-4500 touchpanel.
-
Page 11: Leading Specifications
The power requirement for the TPS-VID/L is 8 Watts (0.333 Amps @ 24 VDC) The latest software versions can be obtained from the Downloads page (SIMPLWIN, TOUCHPNL, VTPRO-E, or CRESDB Libraries) of the Crestron website (www.crestron.com). 12 Inch Tilt/Lectern Touchpanels: TPS-4500 & TPS-4500L • • 7... - Page 12 RS-232 port on the TPS-4500/L. Touchpanels with later versions of firmware may include features not mentioned in this guide. Check the MANUAL Library on the Crestron FTP site for newer versions of this guide or contact a Crestron technical support representative.
-
Page 13: Installation/Setup
Cresnet Network Interconnect Drawing (Doc. 5411). The document can be obtained from the Downloads page (CABLES and MANUAL Libraries) of the Crestron website (www. crestron.com). Search for the CRESNET.PDF files. When calculating the wire gauge for a particular network run, the length of the run and the power factor of each network unit to be connected must be taken into consideration. -
Page 14: Hardware Hookup
12 Inch Tilt/Lectern Touchpanel Crestron TPS-4500 & TPS-4500L NOTE: All network wiring must consist of two twisted-pairs. One twisted pair is the +24V conductor and the GND conductor and the other twisted pair is the Y conductor and the Z conductor. - Page 15 Crestron TPS-4500 & TPS-4500L 12 Inch Tilt/Lectern Touchpanel 2. Make a small hole near the middle of the designated site; verify that the location is suitable. 3. Fasten cutout template (40049, supplied) to mounting surface; verify that the template is level.
- Page 16 12 Inch Tilt/Lectern Touchpanel Crestron TPS-4500 & TPS-4500L Positioning Touchpanel into Opening POSITION AND SECURE TOUCHPANEL INTO OPENING NOTE: WIRING NOT SHOWN FOR CLARITY DRYWALL 13. Use the #2 Phillips screwdriver and fully tighten all 12 pan head screws. Use caution and do not crack or damage mounting surface.
-
Page 17: Configuring The Touchpanel
Crestron TPS-4500 & TPS-4500L 12 Inch Tilt/Lectern Touchpanel Hardware Connections for the TPS-4500 RS-232 NET/VIDEO 24VDC 2.0A TO PC OR TO INTERFACE TO POWER RS-232 DEVICE MODULE PACK (OPTIONAL) Configuring the Touchpanel To configure the unit, it may be necessary to access a series of setup screens prior to viewing run-time screens that are loaded into the touchpanel for normal operation. -
Page 18: Diagnostics Menu
Diagnostics Menu The Diagnostics button from the Main Menu should only be used under supervision from a Crestron technical support representative during telephone support. Most of the options available from the Diagnostics Menu, shown after this paragraph, are numeric in nature and their interpretation is beyond the scope of this manual. - Page 19 Crestron TPS-4500 & TPS-4500L 12 Inch Tilt/Lectern Touchpanel Setup Menu NOTE: All touchpanel settings, except those menus with a Save and Return button, are automatically saved in non-volatile memory. Standby Timeout The touchpanel display can be turned off (standby mode) when not in active use.
- Page 20 The five buttons in the upper right corner of the menu are available for selection. Crestron suggests that even if there is no intent to use the RS-232 port, the user should select one of the five RS-232 communication options. Crestron recommends the default, RS-232 Port for Console, if the port is not being used.
- Page 21 Crestron TPS-4500 & TPS-4500L 12 Inch Tilt/Lectern Touchpanel Select the Save and Return button, located at the bottom right corner of the Interface Menu, after interface parameters have been set. RS-232 Menu RS-232 parameters, shown after this paragraph, must be set when communicating via the RS-232 port for RS-232 console and control communication.
- Page 22 12 Inch Tilt/Lectern Touchpanel Crestron TPS-4500 & TPS-4500L Video Menu Use this screen to select one of the video inputs and adjust the brightness, contrast, saturation, and hue, if necessary. The user has the option to force the video image to a certain mode (i.e., composite video or S-video) or switch modes automatically after...
-
Page 23: Visiontools™ Pro-E (New Features)
Crestron control system. This example is analogous to a traffic light that changes color as well as controlling the text on a walk/don't walk sign. -
Page 24: Programming With Simpl™ Windows
SIMPL (Symbol Intensive Master Programming Language) is an easy-to-use programming language that is completely integrated and compatible with all Crestron system hardware. The objects that are used in SIMPL are called symbols. ® SIMPL Windows offers drag and drop functionality in a familiar Windows environment. -
Page 25: How To Create The Program
Windows, Crestron recommends a SIMPL Windows and operating system upgrade. The latest version can be obtained from the Downloads page (SIMPLWIN Library) of the Crestron website (www.crestron.com). New users are required to register in order to obtain access to the FTP site. - Page 26 12 Inch Tilt/Lectern Touchpanel Crestron TPS-4500 & TPS-4500L System View of the CNXRY-16 and TPS-4500 in SIMPL Windows’ Configuration Manager Programming Manager Use the Programming Manager workspace (Project | Program System) in SIMPL Windows to select symbols and assign their respective signals. For this example, a TPS-4500 and CNXRY-16 symbols were added automatically when the devices were added to the system in the Configuration Manager workspace.
- Page 27 Crestron TPS-4500 & TPS-4500L 12 Inch Tilt/Lectern Touchpanel NOTE: For a more descriptive symbol name, as shown in the previous illustration, right mouse click on the touchpanel icon in the Network Modules folder in Program View and select Edit Symbol Comment (alternatively, highlight the icon and depress Ctrl+R or Tab).
-
Page 28: Reserved Join Numbers
12 Inch Tilt/Lectern Touchpanel Crestron TPS-4500 & TPS-4500L Reserved Join Numbers A reserved join number is a feature of the software that enables a designer to create a button on a touchpanel page that either calls up the Setup Menu, alters brightness, etc. -
Page 29: Problem Solving
17203 System Standby Timeout Problem Solving Troubleshooting The table below and on the next page provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. TPS-4500/L Touchpanel Toubleshooting POSSIBLE TROUBLE CORRECTIVE ACTION... -
Page 30: Further Inquiries
In New Zealand, call Amber Technologies at +649-410-8382. Future Updates As Crestron improves functions, adds new features, and extends the capabilities of the TPS-4500/L, additional information may be made available as manual updates. These updates are solely electronic and serve as intermediary supplements prior to the release of a complete technical documentation revision. -
Page 31: Appendix A: Rs-232 Protocol
12 Inch Tilt/Lectern Touchpanel Appendix A: RS-232 Protocol TPS-5000L touchpanels support panel operation via a host computer through the RS-232 port. Crestron recommends that the following serial data format is set. Suggested Serial Data Format Baud Rate: 38400 Data Bits: 8... - Page 32 12 Inch Tilt/Lectern Touchpanel Crestron TPS-4500 & TPS-4500L accomplished at any rate less than 2400 baud. Obviously, ramping several objects at once requires a baud rate several times as high. Indirect Text – TPS-5000L touchpanels support a feature that permits the text field in any user-defined button to be altered on the fly in RUN mode.
-
Page 33: Appendix B: Cutout Detail Of Supplied Template
Use the alphanumeric codes in the illustration and table to obtain the cutout dimensions for the lectern mount models when mounting without the BB-5000. However, Crestron recommends that the supplied template be used to avoid error. VERTICAL MEASUREMENTS HORIZONTAL MEASUREMENTS = 0.320 in (0.813 cm) -
Page 34: Return And Warranty Policies
(3) years from the date of shipment to purchaser. Disk drives and any other moving or rotating mechanical parts are covered for a period of one (1) year. CRESTRON warrants all its other products for a period of one year from the defects mentioned above, excluding touchscreen display components which are covered for 90 days. - Page 35 Crestron TPS-4500 & TPS-4500L 12 Inch Tilt/Lectern Touchpanel PRELIMINARY This page intentionally left blank. 12 Inch Tilt/Lectern Touchpanels: TPS-4500 & TPS-4500L • • 31 Operations Guide - DOC. 5891...
- Page 36 Crestron Electronics, Inc. Operations Guide – DOC. 5891 15 Volvo Drive Rockleigh, NJ 07647 12.00 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
