Sony VAIO PCG-K Series Replacement Instructions

Hard disk drive
Hide thumbs Also See for VAIO PCG-K Series:

Advertisement

Quick Links

These easy instructions are intended to guide you through the replacement process.
To avoid electric shock please make sure product is turned off and AC Adaptor is disconnected
from the power source. Remove jewelry before you begin work to avoid scratching the surface of
your notebook computer.*
Place your notebook computer on a clean, stable and covered surface to avoid damage to the
computer's case.
Follow the ESD (Electrostatic Discharge) damage prevention instructions:
o Hold parts by the edges, away from exposed circuitry when possible.
o Do not walk around excessively as this promotes static build-up.
The appearance of the electronic components shown in the illustrations may be different from the
components shipped. This slight difference does not affect the accuracy of these instructions.
* Sony is not responsible for any loss of data associated with your computer or any damage caused by
incorrect handling of the computer under these procedures. The terms of your Sony Limited Warranty
continue to apply.
Step 1
.
To prevent any kind of cosmetic
damages and scratches, place your PC upside
down on top of a soft surface, with the ports
facing you.
P/N T99860098
Rev. D
IMPORTANT!
PLEASE READ BEFORE YOU START
*
PCG-K Series Hard Disk Drive
Replacement Instructions
Step 2
.
CAUTION!
Disconnect the power cord and
remove the battery. Failure to
do so can result in damage to
the PC.
1/2
Step 3
.
Using the enclosed
magnetic screwdriver, remove
the marked screw and set
aside.

Advertisement

loading

Summary of Contents for Sony VAIO PCG-K Series

  • Page 1 This slight difference does not affect the accuracy of these instructions. * Sony is not responsible for any loss of data associated with your computer or any damage caused by incorrect handling of the computer under these procedures. The terms of your Sony Limited Warranty continue to apply.
  • Page 2 Return the old HDD Bay to screws, as shown in the Sony following the included picture. over shipping instructions. tighten the screws! P/N T99860098 Rev. D...
