- Page 1 ® Intel Express Redundant Power Supply User Guide...
- Page 2 Copyright © 1998, Intel Corporation. All rights reserved. Intel Corporation, 5200 NE Elam Young Parkway, Hillsboro OR 97124-6497 Intel Corporation assumes no responsibility for errors or omissions in this manual. Nor does Intel make any commitment to update the information contained herein.
- Page 3 Express Redundant Power Supply (RPS) provides a back-up power source to Intel network devices such as an Intel hub or switch. This ensures that your devices will receive uninterrupted power and zero packet loss should the device’s internal power supply fail. For a complete list of supported devices, see the Intel Web site at http://support.intel.com/support/express/rps.
-
Page 4: Installation
RPS. edge is on top. Remove the cover plate from the device (Intel hub or switch) • The term device generically refers to an Intel hub or switch. Input 100-120V/2A • Remove the RPS cover plate from the device... -
Page 5: Check The Leds
Backup Power Uninterruptable Power Supply (UPS) source is 110 or 230VAC. Tip: Intel recommends that you Note: If you don’t connect both AC connect the Main and Backup Power power cords, the audio alarm sounds when... -
Page 6: Checking For Problems
Using the RPS Levels of redundancy The RPS has three levels of redundancy: Main Power Main Power Low: You’ll have a low level of redundancy when you connect only the Main Power on the RPS. You’ll be protected against a device’s internal Backup Power power supply failing, but not against an electrical outage. -
Page 7: Troubleshooting
To reset the alarm Press the Audio alarm reset button on the front panel of the RPS. The alarm will sound again if another error event occurs. Note Replacing a faulty device Anytime you remove an AC power cable from the RPS, the audio Unplug the RPS’s AC power cords. -
Page 8: Understanding Leds
Understanding LEDs Intel Express Redundant Power Supply Supply 3 System Supply 1 RPS status RPS status Power Device status Device status Temperature/ Fans Supply 2 Supply 4 RPS status Audio alarm RPS status reset Device status Device status Status Meaning... -
Page 9: Technical Information
Technical Information Humidity (non-condensing) operating: 10% minimum, 85% maximum non-operating: 10% minimum, 85% maximum Temperature operating: 0° C minimum, 40° C maximum non-operating: -20° C minimum, 65° C maximum Dimensions width: 17.35 inches (44.06 cm) height: 2.625 inches (6.66 cm) depth: 13 inches (33.02 cm) weight: approximately 25 lbs (11.34 kg) Altitude... -
Page 10: Limited Warranty
(RMA) number either to the company from whom you purchased it or to Intel (North America only). If you ship the product, you must assume the risk of damage or loss in transit. You must use the original container (or the equivalent) and pay the shipping charge. - Page 11 (RMA) number either to (a) the company from whom you purchased it or (b) to Intel, North America only (if purchased in Europe you must deliver the product to “(a)”. If you ship the product, you must assume the risk of damage or loss in transit.
-
Page 12: Regulatory Information And Warnings
Manufacturer Declaration This certifies that the Intel Redundant Power Supply complies with the EU Directive 89/336/EEC, using the EMC standards EN55022 (Class A) and EN50082-1. These products also meet or exceed EN 60950 (safety) requirements. These products have been tested and verified to meet CISPR 22 Class A requirements. - Page 13 Ne pas utiliser ni modifier le câble d’alimentation C. A. fourni, s’il ne correspond pas exactement au type requis. Assurez vous que le système soit débranché de son alimentation ainsi que de toutes les liaisons de télécomunication, des réseaux, et des lignes de modem avant d’enlever le capot.
-
Page 14: Intel Customer Support
Intel Customer Support Automated Support You can reach Intel’s automated support services 24 hours a day, every day at no charge. The services contain the most up-to-date information about Intel products. You can access installation instructions, troubleshooting information, and general product information. - Page 15 *713265-001* 713265-001...
