TRAILER CART
600 LBS., 10 CUBIC FEET
90662
ASSEMBLY & OPERATING INSTRUCTIONS
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web Site at www.harborfreight.com
©
®
Copyright
2003 by Harbor Freight Tools
. All rights reserved. No portion of this manual or
any artwork contained herein may be reproduced in any shape or form without the
express written consent of Harbor Freight Tools.
For technical questions and replacement parts please call 1-800-444-3353.
90662-Trailer Cart.p65
1
10/28/03, 1:38 PM
Advertisement
Related Manuals for Harbor Freight Tools 90662
Summary of Contents for Harbor Freight Tools 90662
- Page 1 . All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. For technical questions and replacement parts please call 1-800-444-3353.
- Page 2 HANK YOU for choosing a HARBOR FREIGHT TOOLS product. For future reference, please complete the owner’s record below: Model______________ Serial No._____________ Purchase Date_______________ SAVE THE RECEIPT, WARRANTY AND THESE INSTRUCTIONS. It is important that you read the entire manual to become familiar with the unit BEFORE you begin assembly.
- Page 3 Panel (1)-see Figure 3. From the outside of the Bottom Panel (1), slide a Bolt (22) up through the Bottom Panel (1). Slide a Washer (23) onto each Bolt (22) and thread on Nut (24)-see Figure 3. Figure 3 Tongue Support (3) Bottom Panel (1) Bottom view 90662 Page 3 90662-Trailer Cart.p65 10/28/03, 1:38 PM...
- Page 4 Support (4) and through the holes in the Hitch Tongue (10). Make certain that the axle is centered in the Wheel Axle Support (4) with equal amounts of axle on each end-see Figure 7. 90662 Page 4 90662-Trailer Cart.p65 10/28/03, 1:38 PM...
- Page 5 Bracket (13) with holes in the Rear Cross Brace (12). Insert a Bolt (21) into each of the corner holes in the Rear Cross Brace (12), into the Rear Corner Bracket (13) through a Washer (23) and secure with Nut (24)-see Figure 9. 90662 Page 5 90662-Trailer Cart.p65 10/28/03, 1:38 PM...
- Page 6 Side Panel (14) and Right Side Panel (14), and through the Front Panel (16) sides. Insert Bolts through the six holes in the bottom of the Front Panel (16). Put on Washers (23) and Nuts (24)-refer to Figure 12. 90662 Page 6 90662-Trailer Cart.p65 10/28/03, 1:39 PM...
- Page 7 (3) resting on the Hitch Tongue (10) and secured by the Tongue Latch (9). Note: Before each use, check the Tongue Latch connection to the towing vehicle to insure safe operation. Before each use, check the condition of the pneumatic tires (recommended 30 PSI) 90662 Page 7 90662-Trailer Cart.p65 10/28/03, 1:39 PM...
- Page 8 Unpacking When unpacking your Trailer Cart, check to make sure the following parts are included. If any parts are missing or broken, please call HARBOR FREIGHT TOOLS at 1-800-444-3353. Part # Description Quantity Part # Description Quantity Bottom Panel Front Corner Brace...
- Page 9 Assembly/Parts Diagram 90662 Page 9 90662-Trailer Cart.p65 10/28/03, 1:39 PM...
