Summary of Contents for Regent Terrakan Series
- Page 1 OPERATING MANUAL Cultivator technology 3000 3000 BIO Terrakan Terrakan R6 5000 5000 BIO 6000 6000 BIO...
-
Page 2: Table Of Contents
Ring roller RKW PREPERATIONS ON THE TRACTOR Suitability of the tractor Ballasting Hitch rods Tyres Electric hitch settings COUPLING AND UNCOUPLING CHASSIS- COUPLING AND UNCOUPLING HYDRAULIC FOLDING MECHANISM Unfold the device Fold up the device TRANSPORT POSITION & WORKING POSITION Subject to technical modifications; no responsibility is accepted for the accuracy of this information. www.regent.at... -
Page 3: General Information
GENERAL INFORMATION FOREWORD We are pleased that you have chosen a quality product from Regent. Regent products offer you best quality and proven techno- logy. In order to be able to take full advantage of the performance of your device and to enjoy your device for many years, please read this user manual carefully before the first use of your machine. Operate the device according to the instructions on the follo- wing pages. These operating instructions contain basic information on how to operate, maintain and transport your Regent product... -
Page 4: Guarantee And Warranty
Regent dealer. The serial number is also stamped on the top of freight forwarding. Before taking over your new machine, please the main frame near to the linkage tower. Please always have the check that the device has not been damaged in transit and that data on the nameplate ready for inquiries or orders. -
Page 5: Regulations Of General Security And Accident Prevention
REGULATIONS OF GENERAL SECURITY AND ACCIDENT PREVENTION Before using your new machine for the first time, please read all instructions carefully and operate in accordance with the „General saf- ety and accident prevention regulations“ of the manufacturer and those of the legislator of your country. The manufacturer declines all liability if the rules below are not followed. If you have any questions about the safety regulations, please contact an authorized dealer or the factory customer support of Regent Pflugfabrik GmbH. ¾ The attached danger symbols and warning signs provide tion. Before leaving the towing vehicle, always lower the important information about dangerous areas on the device coupled to the power lift, switch off the engine, machine. Heed the warnings permanently apply the parking brake and remove the ignition key. Make sure that nobody can approach chemicals (e.g. ¾ Never reach into moving parts. Do not approach the ma- pickled seeds in the seed box). chine until the machine and towing vehicle have come to a complete standstill. A safety distance of 5 m around... -
Page 6: Hercules Tine And Share Variants
¾ Long service life ¾ 12.45.172-M5 IGHTENING TORQUE: 70 Nm ¾ Good entry into the soil - Oval head screw M10x60 with nut - For Slim share (standard) - Order number: AE1.02.89 - Screw: 2 pieces 12.60.238-M5 ¾ 24.12.217 - Washer ø 13/30 x 6 - For all coulters www.regent.at... -
Page 7: Roller Variants And Straw Harrow
If the spindle is turned counterclockwise, the knives work higher. If there is a lot of organic matter, the pre-harrow can tend to clog, the knives should then be set higher or raised up completely. Make sure that the same height is adjusted on both sides, this can be checked by measuring the length of the spindle on both sides. The knife-harrow is spring-suspended and thus secured against overload. A scraper rail is mounted on the ring roller which prevents the roller from becoming blocked. www.regent.at... -
Page 8: Preperations On The Tractor
(when the device is working in the ground) the side struts must be able to swing freely and must not be fixed. In the case of semi-mounted devices, the lower links should be perma- nently locked against lateral swinging. ¾ The leg dimension between the two center hook points (D) must be set exactly to the leg dimension of the device. ¾ The top link (E) should be pegged in the hole group (F) of the to- wing vehicle so, that the imaginary extended line of the top link in intersects the front axle of the towing vehicle (working position, see depth adjustment). In this way, the tire-slip can be reduced to a minimum and the electronic hoist control can work correctly. www.regent.at... -
Page 9: Coupling And Uncoupling
¾ Bring the two parking supports (C) of the lower link support axle into the working position (supports raised). ¾ Do not remove the wheel chocks until the device is fixed by the towing vehicle ¾ Devices with chassis have their own hitch-system and are inde- pendent of the towing vehicle hitch. Lift the device only via the corresponding hydraulic control circuit. Use the device only in tractor operating mode „position control“ ¾ Make sure that there is enough space between the straw har- row and the axle of the chassis www.regent.at... -
Page 10: Hydraulic Folding Mechanism
¾ Fold the side plates into the working position (see chapter side when the machine is folded, the transport width of the rear rol- plates). ler it is less than the transport width of the tine fields (see chapter ¾ Fold the side levelling tines into the working position (see chap- roller and straw harrow). ter side leveling tines). ¾ Before entering public area, make sure that the control circuit ¾ Make sure that all bolts are secured with a pin or spring pin for the folding device is locked. before starting field work. www.regent.at... -
Page 11: Working Depth Adjustment
20.5 x 8.00 - 10 tire is 2.2 bar (32 PSI), maximum pressure: 2.5 bar (36 PSI). When operating with front wheels, we recom- mend that the top link of the tractor is hung in the elongated hole of the device side´s linkage tower. www.regent.at... -
Page 12: Double - Levelling Tines
Lock the safety hook before every transport trip. The safety hook is not necessary for devices with hydraulic folding. Transport position Working position The adjustment of the intensity or the removal of the tension spring is carried out in the same way as described in chapter DOUBLE LEVELLING TINES. The side levelling tines must be fixed in the working position for this process. www.regent.at... -
Page 13: Front Roller Wsw Ø450
The inclination and thus the intensity of the levelling board can be set on the two-stage hole group (E). To move, pull out the spring-loaded bolts on both sides, turn the level ling board to the new position and then snap the spring-loaded bolts back into place. www.regent.at... -
Page 14: Side Shields
Every 25 hours of operation: Operating fluids ¾ Tighten screws ¾ Check wear parts, replace if necessary Hydraulic fluid: Every 50 operating hours: ¾ Mineral hydraulic oil DIN 51524 HLP 46 ¾ Check ball bearings, replace if necessary Grease: ¾ Check hydraulic actuators for leaks ¾ Semi-synthetic calcium soap grease Divinol TOP 2003 www.regent.at... -
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Regent Pflugfabrik GmbH KONFORMITÄTSERKLÄRUNG DEUTSCH Der Hersteller erklärt hiermit, daß die nachstehend beschriebene neue Maschine übereinstimmt mit den Bestimmungen der Maschinen Sicherheitsverordnungen - 2006/42/EG, und damit der durch sie umgesetzten Maschinenrichtlinie RL2013/167/EG in der geltenden Fassung, und zwar mit den folgenden grundlegenden Sicherheitsanforderungen wie - Zubehörteile für... - Page 16 Regent Pflugfabrik GmbH Tel. +43 7674 62661 Bahnhofstr. 105 Fax. +43 7674 62207 4800 Attnang-Puchheim info@regent.at Austria www.regent.at...
