ASROCK SBC-330 Settings Manual

*15G06M050001AK*
P/ N: 15G06M050001AK V1.1
SBC-330
1 : 2-Pin Buzzer Header
2 : Clear CMOS Header
1-2 : Normal
2-3 : Clear CMOS
3 : mSATA Select
1-2 : mini-PCIe
2-3 : mSATA
4 : 4-Pin CPU FAN Connector (+12V)
FAN_SPEED_CONTROL 4
FAN_SPEED
3
+12V
2
GND 1
5 : USB2.0 Headers
(USB2_5_6, USB2_7_8)
DUMMY
GND GND
+B +A
-B -A
USB_PWR USB_PWR
1
6 : Backlight Power Select
(LCD_BLT_VCC) (BKT_PWR1)
1-2 : +5V
2-3 : +12V
3-4 : +12V
4-5 : DC_IN Power
Jumpers and Headers Setting Guide
BIOS
Chip
USB 3.0
35
T: USB2
B: USB1
USB 3.0
T: USB4
34
B: USB3
DP2
33
DP1
32
LAN1
31
30
LAN2
29
HD_AUDIO1
1
1
28
SPEAKER1
1
1
JGPIO_PWR1
1
JGPIO1
JGPIO_SET1
1
1
27 26 25 23
24
7 : Panel Power Selection (LCD_VCC)
(PNL_PWR1)
1-2 : +3V
2-3 : +5V
3-4 : +5V
4-5 : +12V
8 : BL1, BL2
9 : Clear CMOS Header (CLRMOS1)
Open : Normal
Short : Auto Clear CMOS When AC
Power On
10 : SATA3 Connectors
(SATA3_1, SATA3_2)
11 : SATA Power Output Connector
GND
1
+5V GND
12 : System Panel Header
GND
PWRBTN#
PLED-
PLED+
13 : ATX/AT Mode Select (PWR_JP1)
1-2 : AT Mode
2-3 : ATX Mode
DDR4_B1 (Support DDR4 Only)
DDR4_A1 (Support DDR4 Only)
1
BLT_PWR1
1
1
BLT_VOL1
LPC1
PWR_COM1 PWR_COM4
1 1
PWR_COM2 PWR_COM3
1
1 1
COM1 COM2 COM3 COM4
21 18 17
22 20 19
1
1
SATA3_2
SATA3_1
+12V
GND
RESET#
GND
HDLED-
HDLED+
1
1
1
CLRMOS1
2
1
MSATA_SEL1
3
1
4
USB2_7_8 USB2_5_6
5
1 1
6
1
7
1 8
1
1
9
1
CLRMOS1
SATA3_2
10
SATA3_1
11
SATA_PWR1
12
1
1
PANEL1
13
DC_IN1
1
16 15 14
14 : ATX Power Connector
(Input 12V or 19V-36V)
1-4 : GND
2-3 : DC Input
15 : Inverter Power Control Wafer
(BLT_PWR1)
PIN
1
1
2
3
4
5
6
16 : LPC Header
COM1, 2, 3, 4 Headers
17 : COM4
18 : COM3
20 : COM2
22 : COM1*
Signal Signal
PIN PIN PIN
Name Name
10 DUMMY 8 CCTS# 6
9 DUMMY 7 RRTS# 5
Signal Name
GND
GND
CON_LBKLT_CTL
CON_LBKLT_EN
LCD_BLT_VCC
LCD_BLT_VCC
2
1
Signal Signal Signal
PIN PIN
Name Name Name
DDSR# 4 DDTR# 2 RRXD
GND 3 TTXD 1 DDCD#
