F E AT U R E D M O D E L
511-738
7" & 5-1/8" bowl depths
F E AT U R E S
18 gauge, 304 series stainless steel
•
Sliding safety glass cutting board and removable
•
colander included
18/10 chrome/nickel content
•
Long-lasting, easy-to-clean, satin polish finish
•
Rear drain placement
•
Pop-up waste for main bowl
•
C O D E / S TA N DA R D S C O M P L I A N C E
ASME 112.19.3-00
IAPMO/UPC listed
I N C L U D E D A C C E S S O R I E S
Basket Strainer
Sliding Safety Glass Cutting Board
Custom Stainless Steel Colander
WA R R A N T Y
Blanco America's Pinnacle Series sinks feature a
LIMITED LIFETIME WARRANTY to be free of all
manufacturing defects under normal use.
See our complete warranty for details.
While Blanco America endeavors to provide accurate
information, all dimensions are nominal, cannot be
guaranteed, and are subject to change or cancellation.
Blanco America assumes no responsibility for use of
superseded or voided specifications.
P R O D U C T S P E C I F I C AT I O N
Drop-in sink to be 39-3/8" in length and
20-1/16" in front-to-back depth. Sink to be
made from 18 gauge, 304 series stainless
steel, with 18/10 chrome/nickel content and
satin polished finish. Sink to feature rear
drain placement and straight bowl sides with
approximately 1" corner radius. Sink to be
Blanco Model 511-738, with left bowl depth of
7" and right bowl depth of 5-1/8".
J O B I N F O R M AT I O N
Job Name:
Contact:
Date Specified:
Specifier:
Contractor:
N O M I N A L D I M E N S I O N S
MODEL
OVERALL
511-738
39-3/8 x 20-1/16
DXF cutout templates available on our web site.
K N O C K O U T H O L E L O C AT I O N S
Pr e - drilled for single -hole faucet
and r emot e drain operat ion.
No addit ional holes available.
SI N K SP EC I F I CAT I ON S
Pinnacle Series
BLANCOAXIS 6S™ Left Drainboard
Model 511-738
MODEL 511-738
BOWL DEPTH
LEFT RIGHT
7
5-1/8
B L A N C O A M E R I C A
8 0 0 . 4 51. 5 7 8 2
w w w. b l a n c o a m e r i c a .c o m
© 2008 BLANCO AMERICA 09/08
SPEC-003
DRAIN
DIAMETER
3-1/2
