Discover Your Phone
Headphone jack
Left side key
Navigation key
Left soft key
Dial key
Charger jack /
Earplug jack/
Data transfer port
Philips continuously strives to improve its
products. Therefore, Philips reserves the right to
revise this user guide or withdraw it at any time
without prior notice. Philips provides this user
guide "as is" and does not accept, except as
required by applicable law, liability for any
error, omission or discrepancy between this user
P699_EN
guide and the product described. The device is
meant to be connected to GSM/GPRS network.
Back of phone:
Camera lens
How to ...
262K color
Power On/Off
main screen
Make a call
Right soft key
End a call
Power Supply key
Right side key
Answer a call
Reject a call
Number keys
Access the
Microphone
Main menu
Access the
SIM switch
Access the
menu
Show the phone
book list
1
Long press the power supply
key
In idle mode, press the
number keys, then press the
dial key
During a call, press the right
soft key
Press the dial key
Press the power supply key
In idle mode, press the left
soft key
In idle mode, press the right
soft key
In idle mode, press the up
Tools
key
In idle mode, press the down
key
8/23/07, 5:17 PM
Advertisement
Table of Contents
Related Manuals for Philips CT0699SLV/40
Summary of Contents for Philips CT0699SLV/40
-
Page 1: Discover Your Phone
Earplug jack/ Data transfer port Philips continuously strives to improve its products. Therefore, Philips reserves the right to revise this user guide or withdraw it at any time without prior notice. Philips provides this user guide “as is” and does not accept, except as... - Page 2 Access the In idle mode, press the left Audio Player Access the In idle mode, press the right menu Show In idle mode, press the dial Call Logs Access the In idle mode, press the right preview side key window of the Camera Take photos In the preview window of...
- Page 3 Softkeys The left and right keys are located at the top of the keypad area. Pressing the soft keys allows you to select the option displayed on the screen directly above them, including options during a call. The functions of the soft keys change according to the current context.
- Page 4 Press the right soft key to back or return to the previous menu. How to use this manual This user manual strives to provide you with concise and complete information regarding your Philips 699 phone. It includes the following: Discover your phone This section presents an...
-
Page 5: Table Of Contents
1.Getting Started ... 7 Inserting the SIM card and Memory card .. 7 Power on the phone ... 9 Power off the phone ... 9 Charging the battery ... 9 2.Calling ... 11 Make a call ... 11 Make an international call ... 11 Receive/Mute/End a call ... - Page 6 8.Messages ... 25 SMS ... 25 MMS ... 28 Voice Mail Server ... 31 Broadcast Message ... 32 9.User Profiles ... 33 10. Settings ... 34 Pen Calibration ... 34 SIM switch ... 34 Phone Setup ... 34 Call Setup ... 36 Network Setup ...
- Page 7 Webcam ... 53 Icons & Symbols ... 54 Precautions ... 56 Troubleshooting ... 60 Philips Authentic Accessories ... 62 Trademark Declaration ... 63 Limited warranty ... 64 Specific Absorption Rate Information ... 67 Declaration of conformity ... 68 P699_EN 8/23/07, 5:17 PM...
-
Page 8: Getting Started
1.Getting Started Please read the safety instructions in the “Precautions” section before use. Before you start using your phone, you must insert a valid SIM card supplied by your GSM operator or retailer. The SIM card contains your subscription information, your mobile phone number, and a small quantity of memory in which you can store phone numbers and messages. - Page 9 You may lose all your personal settings if you remove the battery when the phone is switched on. Insert the SIM card Make sure that the clipped corner of the SIM card is facing the correct direction, and the metallic contacts are facing downwards.
-
Page 10: Power On The Phone
Replace the battery and the back cover With the metallic contacts facing downwards, press the battery down into its slot until it locks into place. Note that the hinge should be at the bottom of the phone. Press down the back cover until it locks into place. When inserting the battery, be careful not to damage the metallic connectors of the SIM card slot. - Page 11 Plug the charger into an electrical outlet. Plug the charger connector into the bottom of the phone (with the arrow pointing upward). The battery symbol indicates the state of charge. If the phone is charging while power off, a charge indicator will appear on the screen.
-
Page 12: Calling
2.Calling Make a call You can make a call only when the network name appears on the screen. From idle mode 1. In idle mode, you can press the number keys to enter the phone numbers, or tap enter the dial screen, then tap the on-screen numbers to enter the phone number. -
Page 13: Call Handsfree
Call Handsfree For your comfort and safety, move the phone away from your ear when calling in handsfree mode. To activate handsfree during a call, press the left soft key Option, then select H-Free left soft key again; To deactivate handsfree during a call, press the left soft key menu, then select Option... -
Page 14: Make A Second Call
Make a second call (Network dependent) Dial a second call (Network dependent) You can make a second call by putting the current call on hold: 1. During a call with Party A, you can enter Party B’s number using the keypad or select 2. -
Page 15: Input Method
3.Input Method General outline This mobile phone supports English input and provides the following input methods: Multitap abc, Numeric, Smart ABC, The available input method is dependent on the language display. Keypad functions The keypad functions are as follows: Left soft key: Generally used for confirmation Right soft key: To return or delete. -
Page 16: Phone Book
4.Phone Book Press the down key in idle mode to display the phone book list. This phone is able to store up to 500 phone book records. The number of records you can store on the SIM card is dependent on the capacity of your SIM card. - Page 17 Delete: Select “From SIM” or “From Phone” to respectively delete all the entries in the SIM card or the onboard phonebook. You can also select “One By One” to delete telephone number individually. To delete all the entries from the SIM card or phone, you need to enter a password.
- Page 18 You can select a contact from the phonebook list and press the left soft key Options following operations: Dial: Press the left soft key to dial the current number. SMS: Send a short message to the current Send phone entry. Dial: Set up an IP dial number.
-
Page 19: Fun & Games
5.Fun & Games Games You can play three different games: ColorBalls, and Puzzle. For each game, you can begin Memory with Start Game Game Help, or you can view Best Grades Game Level. Game: Starts a new session of the selected Start game. -
Page 20: Services
6.Services You can use the value-added services provided by your network operator. Your mobile phone supports STK functions. This service is provided by your network operator. If your SIM card and network operator cannot support this service, then you will not be able to see this function in the menu. - Page 21 If the bookmark is empty, you need to enter the URL address of the website before connecting to it. For example, if you want to add sina website to the bookmark, you need to enter: wap.sina.com. 3.Recent Pages Display the recent pages. Select a recent entry and connect to the page directly.
-
Page 22: Data Account
7.WAP Online Functions The following options are available when you press the left soft key when browsing WAP service Option pages: Goto: Connect to the current selected WAP site. Homepage: Return to the WAP service home page. Refresh: Download the current page again. Bookmarks: Display all your saved bookmarks. - Page 23 Number: Enter the phone number to dial for connection to the server. User Name: Enter the user name to login to the server. Password: Enter the password to login to the server. Line Type: Select Analogue or ISDN. Speed: Select the rate to transmit/receive data to/ from the server.
-
Page 24: Call History
7.Call History Missed Calls Displays the telephone number or name of the missed calls (if the number is already stored in the phonebook). Select a record from the missed calls list, press the left soft key to view details of the record. -
Page 25: Call Time
Call Time You can check the call time record in this menu. The options are: Last Call Time: Display the time of the last call. Sent: Display the total time of your sent Total calls. Received: Display the total time of your Total received calls. -
Page 26: Messages
8.Messages If your network supports SMS (short message service) and you have subscribed to this service, you can send short messages through the short message service center. The mobile phone also supports Enhanced Messaging Service (EMS) that includes picture, animation, melody, sound, etc. You can use the preset template to create short messages. - Page 27 URL: Extract the URL address (must start with http:// or wap) in the current message and display them in a list. You can select one of the address and connect to it directly. Objects: Extract a sound or picture object in Save the current message (EMS), and save it.
- Page 28 Alignment: Set the alignment mode as Automatic, Left, Center or Right. Paragraph: Add a new paragraph with Automatic Alignment mode, Left Alignment mode, Center Alignment mode or Right Alignment mode. Input Method: Select an input method. After selecting Done, if you select person, you will be prompted to enter the recipient’s telephone number;...
-
Page 29: Mms
Setting: Set Common Delivery Report Off. If you set it as “On”, when the recipient receives your message, or if the message is not received for some reasons, the message centre will send a status report to inform you. Your network operator must support this function for it to be available. - Page 30 In the recipient list interface, you can press the left soft key to carry out the following Option operations: Number: Add the recipient’s phone number. E-mail: Add the recipient’s email Edit: Edit the selected number. Delete: Delete the selected number from the recipient list.
- Page 31 Some of the options above only appear under certain circumstances. For example, “Delete Slide” only appears when the current MMS exceeds one page. Each page of a MMS can only contain one picture and one sound. When the current page contains a sound or picture, “Add image”...
-
Page 32: Voice Mail Server
3.Outbox If you have selected to save the MMS before sending, the message will be saved in the Outbox. The MMS which is being sent cannot be deleted. 4.Drafts Contains MMS that were not sent yet. You can further edit them before sending. 5.Template Press the left soft key to enter the message... -
Page 33: Broadcast Message
Broadcast Message Broadcast messages refer to public messages sent by your network operator. If you use the broadcast message service, you can receive messages on various topics from your network operator, such as: the weather, taxis, hospitals, etc. Please contact your network operator for the available topics. -
Page 34: User Profiles
9.User Profiles Your mobile phone comes with various user profiles for you to set your mobile phone’s ring tone according to the environment. General: For use under general circumstances. Meeting: For use in meetings. This requires presetting (for example, Alert Type set to Vibration Only). -
Page 35: Settings
10.Settings Pen Calibration Tap the cross symbol at the center of the screen to calibrate the stylus pen. SIM switch The phone supports two SIM cards and you can switch between the two SIM cards. On idle mode, hole 0 key. The phone will reboot and switch to the other SIM card. - Page 36 2.Schedule Power On/Off You can set four timings to turn on/off the mobile phone. Each timing includes: Status (Disable or Enable), Power On or Off and time. Once you have set the timing, the mobile phone will turn on or off accordingly at the set time. Time cannot be repeated, because the same time cannot be activated at the same time.
-
Page 37: Call Setup
8.Shortcuts You can edit the shortcut menu. The shortcuts are > menu. Tools Shortcuts 9.Dedicated key In this menu, you can Edit the shortcut function of the navigation keys on standby: Up key, Down key, Left key and Right key. 10.Flight Mode You can select three kinds of mode: Flight Mode... - Page 38 Calls: Divert all incoming calls when Divert All Voice you did not answer. The number of rings before the call is diverted is determined by the network. Unreachable: Divert all incoming calls Divert If when the phone is not reachable due to some network error or other reasons.
-
Page 39: Network Setup
• Periodic: Periodic reminders beep periodically every time the timer expires; the times may range from 30 to 60 secs. 6. Call Time Display Turn this option “On” or “Off ” to activate or deactivate the display of call time. 7. -
Page 40: Security Setup
Security Setup You can set the security options of your mobile phone to avoid the unauthorized use of your mobile phone and SIM card. 1.SIM Lock The PIN code can prevent unauthorized use of your SIM card. You can carry out the following operations: If SIM Lock is Off, select “On”... -
Page 41: Restore Factory Settings
Mode: Enter PIN2 number and then turn the fixed dialing function on or off. Fixed Dial List: Displays the fixed dialing list. If the list is empty, you can press the left soft key add and edit name and number of the fixed dial list. You need to enter your PIN2 code to turn the Fixed Dialing function on or off. -
Page 42: Default Encoding Type
Default Encoding Type Select for traditional chinese character BIG5 encoding type, and select for simplified GB2312 chinese character encoding type. Sound Effect You can choose from 8 equalizer modes. You can also select to restore the Restore Factory Default phone to its default settings. Settings P699_EN 8/23/07, 5:17 PM... -
Page 43: Multimedia
11.Multimedia Camera To enter preview window of the camera, press the left\right keys to switch with EV; press the up/down keys to adjust Zoom (you can adjust Zoom only when the photo size is 160 x 120 and 320 x 240); press to adjust Effect... -
Page 44: Imageviewer
When is set to “On”, the saving and Cont Shot taking of photo will finish at the same time. The default name of the image is “IMG” + “four serial number of the pictures (the numbers will increase accordingly)” + the letter. You can view the photos from the “ImageViewer”... -
Page 45: Video Player
Player: Go to Video Player list, display the movies list that is saved in the current video player menu (if Storage is set to “Phone”, D:\ is displayed; if Storage is set to “Memory Card”, Memory Card:\ is displayed). CamCorder Setting: Set White Balance, EV, Night Mode and Frequency. -
Page 46: Audio Player
When the movie is playing, you can adjust the speed by pressing the left/right keys, and adjust the rate of progression by pressing up/down keys. When the movie is playing, press the left side key to adjust the volume, press the left soft key, to pause/resume the video, press the right side key or tap to capture the image in the movie;... -
Page 47: Sound Recorder
Sound Recorder The mobile phone supports the recording of voice memos. The default file extension is “amr” or “wav”. If the sound recorder is empty, it will display Folder. Press the left soft key to carry out the Option following operations: Record: Record a new voice memo. -
Page 48: File Manager
Forward: Send as ring tone; or send To User Profile MMS; or send EMS; or send Settings: Select Phone Memory Card preferred storage location. You can press the left soft key Option the following operations: Play: Play the current melody. Play Speed: Adjust the melody play speed: Fast, Normal or Slow. - Page 49 Forward: Forward the file to other locations. Detail: Display details of the file including Date and Size. Rename: Rename the file. Copy: Copy the current file to another location. Press the left soft key to select this option; the files in the same root directory will be displayed. If you are copying the file within the same root directory, press the up/down keys to select a location and press...
-
Page 50: Tools
12.Tools Bluetooth Bluetooth is a global standard for wireless connectivity. Bluetooth is based on low-cost, short-range radio. Bluetooth technology facilitates the replacement of cables normally used to connect one device to another, with one universal short- range radio connection. Two Bluetooth devices can communicate with each other when they come within a range of 10 meters of each other. -
Page 51: Calendar
The connection mode of the devices may differ. Please read the device user guide before making the connection. Calendar When you enter the Calendar menu, the screen will display the current month. Press the navigation keys to change date. 1.Task list You can enter the “Task List”... -
Page 52: Units Converter
Press the up/down keys to enter the symbols for the four arithmetical operators: +, M+, -, or M-. Press the left/right keys to enter the symbols for the four arithmetical operators: x, MC, Pressing the right soft key to delete the latest Clear entry or result Press the right soft key... -
Page 53: Dictionary
Dictionary Dictionary function only support simplified Chinese and English. The Dictionary features English to menu. Word Word Class menu features CET-4, Word Class Business. Enter random word class and press the left soft key to carry out the following Option operations: Explanation: Display the English to Chinese result. -
Page 54: Webcam
Webcam You can carry out video chat by connecting the camera lens of the phone to the internet via the PC. You need the following PC tools: 1. The operating system of the PC is Windows XP SP2 or newer. 2. -
Page 55: Icons & Symbols
Icons & Symbols In idle mode, several symbols can be displayed simultaneously on the main screen. If the network symbols isn’t displayed, the network is not currently available. You may be in a bad reception area, moving to a different location may help. - Page 56 - The bars indicate the battery level Battery (4 bar = full, 1bar = low). - You have a missed call. Missed call Silent - Silent mode is activated. - Silent during a call. Call Silent SIM1 card idle - currently making SIM1 card.
-
Page 57: Precautions
Precautions Radio Waves Your cellular mobile phone is a low power radio transmitter and receiver. When it is operating, it sends and receives radio waves. The radio waves carry your voice or data signal to a base station that is connected to the telephone network. - Page 58 Always switch off your phone... Inadequately protected or sensitive electronic equipment may be affected by radio energy. This interference can lead to accidents. Before boarding an aircraft and/or when packing the phone in your luggage: the use of mobile phones in an aircraft may be dangerous for the operation of the aircraft, disrupt the mobile phones network and may be illegal.
-
Page 59: Battery Information
Accessories, as the use of any other accessories may damage your phone and may be dangerous, and will make all guarantees for your Philips phone null and void. The use of an incorrect type of battery may also cause an explosion. - Page 60 Philips has marked the battery and packaging with standard symbols designed to promote the recycling and appropriate disposal of your eventual waste. The battery should not be disposed of with general household waste.
-
Page 61: Troubleshooting
Your battery seems to over heat You might be using a charger that was not intended for use with your phone. Make sure you always use the Philips authentic accessory shipped with your phone. Your phone does not display the phone numbers... - Page 62 You have a feeling that you have missed some calls Check your call divert options. The display shows INSERT SIM Check that the SIM card has been inserted correctly. If the problem remains, your SIM card may be damaged. Contact your operator. When attempting to use a feature in the menu, the mobile displays NOT ALLOWED Some features are network dependent.
-
Page 63: Philips Authentic Accessories
Additional accessories may also be provided or sold separately. Package contents may therefore vary. To maximize the performance of your Philips mobile phone and not to void the warranty, always purchase Philips Authentic Accessories that are specially designed for use with your phone. -
Page 64: Trademark Declaration
Trademark Declaration Bluetooth is a trade-mark owned by telefonaktiebolaget LM Ericsson, Sweden and licensed to Philips. P699_EN 8/23/07, 5:17 PM... -
Page 65: Limited Warranty
(6) months from the date of purchase. P699_EN 3. What Will Philips Do if The Product is Not Free From Material Defects in Materials and Workmanship During The Limited Warranty Period? During the limited warranty period, Philips or its... - Page 66 P699_EN b) The SIM card must be removed from the Product before it is given to Philips. Philips assumes no liability for damaged or loss of the SIM card or the data contained therein. c) If the Product failure is not covered by this limited...
- Page 67 LIMITED REMEDY. This limited warranty represents the complete and exclusive agreement between the Consumer and Philips with respect to this cellular Product and it supercedes all prior agreements between the parties, oral or written, and all other communications between the parties relating to the subject matter of this limited warranty.
-
Page 68: Specific Absorption Rate Information
While there may be differences between the SAR levels of various phones and at various positions, they all meet the international protection standards for exposure to radio waves. The highest SAR value for this Philips 699 model phone when tested for compliance against the standard was 0,49W/kg for ICNIRP recommendation and 0,697W/kg for IEEE Standard. -
Page 69: Declaration Of Conformity
Declaration of conformity Philips Electronics Hong Kong Ltd Business Group Mobile Phone 5/F, Philips Electronics Building 5 Science Park Avenue Shatin New Territories Hong Kong declare under our sole responsibility that the product Philips 699 GSM/GPRS Dualband Digital Mobile Phone...
