iMarc
DSL 9720 CSU/DSU
Installation Instructions
Document Number 9720-A2-GN10-10
May 2003
Contents
...................................................................................................... 10
.................................................................................................. 11
NOTE:
In this document, CSU/DSU refers to the line termination capability of the DSL
endpoint, and does not imply association with traditional T1 or DDS equipment.
....................................................................
.....................................................................
........................................................................................
................................................................................
............................................................................................ 12
...................................................................................... 13
..................................................................... 14
........................................................................................... 15
............................................................................................ 15
....................................................................... 18
................................................................................ 22
........................................................................ 29
........................................................................... 30
..........................................
................................................................
................................................................. 20
1
NOTE: The FrameSaver
product line has been
renamed to iMarc.
.................................... 28
...................................... 31
®
2
3
3
3
4
5
Advertisement
Table of Contents
Related Manuals for Paradyne iMarc DSL 9720 CSU/DSU
Summary of Contents for Paradyne iMarc DSL 9720 CSU/DSU
-
Page 1: Table Of Contents
Using the Easy Install Screen ............... 18 Completing Setup From the NOC ..............20 Cables and Connectors ................22 iMarc DSL 9720 CSU/DSU Technical Specifications ........28 Important Safety Instructions ................ 29 Government Requirements ................30 Warranty, Sales, Service, and Training Information ........ -
Page 2: Imarc Dsl Csu/Dsu Overview
iMarc DSL CSU/DSU Overview ™ The iMarc DSL (Digital Subscriber Line) CSU/DSU is a component in the iMarc system. This system allows you to perform end-to-end service level management across a hybrid DSL/Frame Relay network. Service providers can isolate and correct problems remotely from their NOC (Network Operations Center). -
Page 3: Upgrading A Unit To Advanced Slm Feature Set
To learn more about activating Advanced SLM capability, refer to the iMarc SLV Activation Instructions (Document No. 9000-A2-GK43), or contact your sales representative. Product Documentation Online Complete documentation for this product is available at www.paradyne.com. Select Library →Technical Manuals →iMarc IP/Frame Relay Devices. Select the following documents: iMarc SLV Technical Description (9000-A2-GB30) -
Page 4: Wiring And Cables You May Need
EIA/TIA-568 specifications with 24 AWG (.5 mm) or 26 AWG (.4 mm). For standard cables, refer to Cables and Connectors on page 22 for standard pin numbers. For Paradyne cables, contact your sales representative to order them. Interface Feature or Connection... -
Page 5: Installing The Csu/Dsu
Installing the CSU/DSU Place the iMarc DSL CSU/DSU on a flat surface with clearance for the rear connectors. Procedure 1. Use an 8-pin modular straight-through cable for the network connection. Insert one end of the cable into the jack labeled NET. Insert the other end into the wall jack for DSL data communications. - Page 6 2. Use an 8-pin Ethernet cable for the Ethernet connection for local management. Insert one end of the cable into the jack labeled ETHERNET. — Use a straight-through cable to connect the other end of the cable to an Ethernet hub. Do not connect to the hub’s optional Uplink connection with a straight-through cable;...
- Page 7 3. Connect one end of the DTE’s cable to the user data port labeled PORT. Tighten the screws on each side of the connector. Attach a cable adapter, if required. (See Wiring and Cables You May Need on page 4.) Plug the other end of the cable or adapter into the DTE (router or FRAD).
- Page 8 4. Use a VT100-compatible asynchronous terminal or a PC to set up management access to the unit. Insert the DB9 plug end of an EIA-232 cable into the CSU/DSU’s COM port. Tighten the screws on each side of the connector. Insert the other end of the cable into the terminal or PC.
- Page 9 5. Insert the supplied power cord’s round end into the jack labeled POWER. Depending on the model, your power supply plugs directly into a grounded outlet or has a detachable cord that plugs into an outlet. — If you have a wall-mount transformer, plug the transformer into a grounded AC outlet.
-
Page 10: Power-On
The self-diagnostics include a power-on self-test where all of the LEDs are on. Refer to Status LEDs on page 11 for information about the LEDs. Refer to Troubleshooting on page 12 for LED indications requiring action. 9720 IDSL System Network Port 03 17411 iMarc DSL 9720 CSU/DSU... -
Page 11: Status Leds
Status LEDs After a successful self-test, the LEDs should appear as indicated in BOLD in the Condition column below. Label Indication Color Condition System LEDs Power and Green ON – The unit has power. Operational OFF – The unit is in a power-on self-test, or Status there is a failure. -
Page 12: Troubleshooting
Troubleshooting LED Symptom Action All LEDs are on. If the LEDs remain on for more than ten minutes, the CSU/DSU is not functional. Unplug the unit and reapply power. If the ALM LED is still on, contact the service provider. ALM LED only The power-on self-test may have failed. -
Page 13: Configuration Setup
Configuration Setup Once the CSU/DSU is installed, it can be accessed locally through the menu-driven user interface via an asynchronous terminal or PC connection, or remotely via a Telnet session. The following provisioning can be set up: „ Frame relay and physical layer provisioning – Typically set up by the LEC (Local Exchange Carrier) or CLEC (Competitive LEC) using the menu-driven user interface via an ASCII terminal or PC running a terminal emulation program, or a Telnet session. -
Page 14: Verifying That Self-Test Passed
main 9720-SLV Device Name: Node A 09/13/2002 09:02 MAIN MENU Status Test Configuration Auto-Configuration Control Easy Install ----------------------------------------------------------------------------- Ctrl-a to access these functions Exit If the Main Menu does not appear: „ Press Enter again „ Check the terminal or PC settings „... -
Page 15: Menu Navigation
Menu Navigation The CSU/DSU should operate using the default (factory-set) configuration options. Refer to the following table for help in navigating the menus. Press the . . . To . . . Esc key Go back one screen or menu level. See Menu Hierarchy, below. - Page 16 iMarc DSL 9720 Menu Structure Status System and Test Status Self-Test Results Last System Reset Health and Status Test Status LMI Reported DLCIs DLCI Status CIR (bps) IP Path Connection Device Name Status IP Address Status Discovery Source PVC Connection Status Source Link, DLCI, EDLCI Primary Destination Link, DLCI, EDLCI Status...
-
Page 17: Configuration System
Configuration System Frame Relay and LMI Class of Service Definitions Service Level Verification General Network Physical Frame Relay DLCI Records Data Ports Physical Frame Relay DLCI Records PVC Connections Source Link, DLCI, EDLCI Primary Destination Link, DLCI, EDLCI IP Path List Add and Display Static Paths Management and Node IP... -
Page 18: Using The Easy Install Screen
Easy Install Node IP Address Node Subnet Mask TS Access Create Dedicated Network Management Link Ethernet Port Options Screen Network 1 Operating Rate Network 1 Channel Using the Easy Install Screen An Easy Install screen is provided for custom configurations, but is not required for normal installation. - Page 19 4. Select Create a Dedicated Network Management Link to set up for permanent remote access by the NOC. Enter a DLCI at the resulting prompts. 5. If Ethernet management will be used, select Ethernet Management Options Screen to go directly to the Ethernet Management Options input screen. —...
-
Page 20: Completing Setup From The Noc
Completing Setup From the NOC Procedure 1. Access the remote CSU/DSU on the TS Management Link that was set up at the remote site in Step 4 on page 19 of Using the Easy Install Screen. 2. Ping the CSU/DSU five times within five seconds. The unit automatically accepts the destination IP address of the ping as its temporary IP address. - Page 21 Checking That Data is Being Received Procedure To verify that data is being received: 1. From the unit’s Main Menu, select either interface’s frame relay statistics. Main Menu →Status →Performance Statistics →Frame Relay →Net1-FR1 2. Repeatedly Refresh the screen to: —...
-
Page 22: Cables And Connectors
Cables and Connectors Refer to Installing the CSU/DSU on page 5 for cable installation information. Use CAT3 or better cable for the DSL line. „ The DSL network interface uses an 8-pin unkeyed modular plug. Use a standard twisted-pair cable rated at CAT3 or better. Cable 8-Pin Connector... - Page 23 „ The user data port uses a 25-position EIA-530-A connector that connects to the DTE. Circuit ITU-T Signal Mnemonic Number Direction Shield — — — Signal Common 102A — Signal Common 102B — Transmitted Data To DSU/CSU 2 (A) 14 (B) Received Data From DSU/CSU 3 (A)
- Page 24 „ An EIA-530-A-to-X.21 adapter for the user data port must have the following connections: EIA-530-A DB25 DB15 X.21 SIGNAL PLUG SOCKET SIGNAL TD-A TD-A TD-B TD-B RD-A RD-A RD-B RD-B RXC-A RXC-A RXC-B RXC-B RTS-A RTS-A RTS-B RTS-B RLSD-A RLSD-A RLSD-B RLSD-B SIG.
- Page 25 „ An EIA-530-A-to-V.35 adapter for the user data port must have the following connections: EIA-530-A DB25 V.35 MS34 SIGNAL PLUG SOCKET SIGNAL SHIELD SHIELD TD-A TD-A TD-B TD-B RD-A RD-A RD-B RD-B TXC-A TXC-A TXC-B TXC-B RXC-A RXC-A RXC-B RXC-B RLSD RLSD SIG.
- Page 26 „ The Ethernet interface connector uses an 8-pin, unkeyed modular plug. Use shielded twisted-pair CAT5, or better, cables. See Step 2 on page 6 of Installing the CSU/DSU. — To connect the CSU/DSU to an Ethernet hub, use a straight-through connection.
- Page 27 „ The communication (COM) port connector uses a 9-position, EIA-232-E connector. Pin # Signal Direction Data Carrier Detect (DCD) To DTE (Out) Receive Data (RD) To DTE (Out) Transmit Data (TD) From DTE (In) Data Terminal Ready (DTR) From DTE (In) Signal Ground (GND) —...
-
Page 28: Imarc Dsl 9720 Csu/Dsu Technical Specifications
DSL 9720 CSU/DSU Technical Specifications Item Specification Approvals FCC Part 15, ICES-003, CISPR 22 Class A digital device Safety Certifications Refer to equipment’s label for approvals on product Physical Environment Operating temperature 32°F to 122°F (0°C to 50°C) Storage temperature –4°F to 158°F (–20°C to 70°C) -
Page 29: Important Safety Instructions
Important Safety Instructions 1. Read and follow all warning notices and instructions marked on the product or included in the manual. 2. Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these slots and openings must not be blocked or covered. -
Page 30: Government Requirements
CE Marking When the product is marked with the CE mark on the equipment label, a supporting Declaration of Conformity may be downloaded from the Paradyne World Wide Web site at www.paradyne.com. Select Library → Technical Manuals → CE Declarations of Conformity. -
Page 31: Warranty, Sales, Service, And Training Information
Document Feedback We welcome your comments and suggestions about this document. Please mail them to Technical Publications, Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773, or send e-mail to userdoc@paradyne.com. Include the number and title of this document in your correspondence. Please include your name and phone number if you are willing to provide additional clarification. - Page 32 " *9720-A2-GN10-10*...
