Dual charging stereo alarm clock with
speakerphone and removable battery kineta (24 pages)
Summary of Contents for iHome iBT210
Page 1
Bluetooth Wireless Dual Alarm Clock instruction manual Questions? Contact Customer Service at 1-800-288-2792...
Page 2
Introduction Thank you for purchasing the iHome iBT210. This product is designed to provide high quality wireless sound for your iPad, iPhone, iPod or other Bluetooth audio device. This instruction booklet explains the basic operation and care of the unit. Please read it carefully and keep for future reference.
Table of Contents What’s Included ..............................3 Meet Your iBT210 ............................. 4 The Display/Setting Up the Unit....................... 5 Replacing and Installing Clock Backup Batteries................6 Setting the Clock/Setting and Using the Alarms.................7-8 Previewing the Alarm and Turning the Alarm On/Off..............8 Snooze/Display Dimmer Button/Sleep Mode/FM Radio .............
Using the The Display Bluetooth Indicator Alarm 1 & Alarm 2 Indicators Battery Low Indicator PM/AM Time Display Indicators Sleep Indicator FM Radio Indicator Wake to Indicator AUX indicator Alarm Time/Date/Radio Frequency outlet Wake to source: BT (Bluetooth), FM Radio, Buzzer...
Using the Replacing and Installing Clock Backup Batteries Note: 2 AA batteries are included with the unit. Install them before using the unit. This model is equipped with a battery backup circuit that will maintain the time and alarm time settings in the event of a temporary power interruption (the display is NOT lit).
Using the Setting the Clock Press and hold the Sleep/Clock Adjust Button located on the back of the unit for 2 seconds until the clock display flashes and a beep sounds. 2. Press the Buttons to adjust the clock to the current time (hold for rapid setting).
Using the Setting and Using the Alarms (Cont’d) Press and hold the Alarm Button for 2 seconds until the alarm time display and alarm icon flash. A beep sounds. 2. Press the Buttons to adjust the alarm time to the desired time (hold for rapid setting).
Using the Snooze/Display Dimmer Button The default snooze time is 9 minutes. To adjust Snooze duration, press and hold the Snooze/Display Dimmer Button during normal operation (when no alarm is sounding). 2. Press the Buttons to select the desired snooze time (between 01 and 29 minutes).
Using the Setting and Using FM Presets The unit allows you to store up to 6 FM radio station presets Press and release the Mode Button as needed until the FM indicator icon appears on the display. Press and release the Presets Button as needed until the preset number (P1- P6) you wish to set is displayed, then press and hold the Presets Button to enter setting mode.
2 beeps will sound, indicating the iBT210 is ready to play music. There should also be an indication on your device. In the future, when unit is ON and in Bluetooth mode, the iBT210 will attempt to autolink to a previously paired device when the device is within range (about 33...
Using the Playing Audio via Bluetooth Press the Power/Alarm Reset Button to turn the unit ON. 2. Press and release the Mode Button as needed until “BT” appears on the display. 3. Press the Play/Pause/Pairing Button on the unit to play audio from your linked Bluetooth pair device.
Using the Playing Audio via Aux-In Connect one end of a standard audio cable (not included) into the aux-in jack on the back of the unit and the other end into the headphone or output jack of your audio device.
Using the Charging Devices via USB Port Connect the standard size end of a USB cable (not included) to the USB Port on back of the unit and connect the other end to the charging port on your device. It’s often best to use the charging cable supplied with your device.
Using the Battery Use Cautions and Tips • Only use the recommended/supplied batteries or equivalent • Use alkaline batteries for longer life • Do not mix old and new batteries, and do not mix alkaline, carbon-zinc or rechargeable nickel-cadmium batteries •...
Consumer Product Safety Guide IMPORTANT SAFETY INSTRUCTIONS When used in the directed manner, this unit has been designed and manufactured to ensure your personal safety. However, improper use can result in potential electrical shock or fire hazards. Please read all safety and operating instructions carefully before installation and use, and keep these instructions handy for future reference.
FCC ID: EMOIBT210 FCC Radiation Exposure Statement IC: 986B-IBT210 This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Unit doesn’t respond (no power) • Check that all connections are correct and properly plugged in. • Make sure your device is properly paired with the iBT210. • Make sure the Power is ON. Unit doesn’t respond (locked up or frozen) •...
Limited 1 Year Warranty iHome Products, a division of SDI Technologies Inc. (hereafter referred to as SDI), warrants this product to be free from defects in workmanship and materials, under normal use and conditions, for a period of one (1) year from the date of original purchase.
