TracVision UHD7 SWM Expansion Kit
Installation Instructions
These instructions explain how to install a SWM (single-wire multiswitch) expansion kit for use
®
with the TracVision
exceed the number of tuners that are supported by the standard system, allowing you to
connect even more receivers/DVRs to the system.
KVH Kit Part No.
72-0897
72-0898
NOTE: Complete instructions on how to use the system are provided in the Help.
Installation Steps
1. Inspect Parts and Get Tools ................. 3
2. Remove the Radome or Hatch............. 4
3. Bypass the Internal DSWM .................. 5
4. Connect Cables to the Antenna ........... 7
5. Wire the Polarity Locker....................... 8
Who Should Install the Expansion Kit?
To ensure a safe and effective installation, KVH recommends that a KVH-authorized marine
technician install the TracVision UHD7 SWM Expansion Kit. KVH-authorized technicians have
the tools and electronics expertise necessary to modify the antenna system. To find a technician
near you, visit www.kvh.com/wheretogetservice.
Technical Support
If you need technical assistance, please contact KVH Technical Support:
North/South America, Australasia
Phone: +1 401 847-3327
Email:
support@kvh.com
(Mon.-Fri., 9 am-6 pm; Sat., 9 am-2 pm ET, -5 GMT)
Europe, Middle East, Africa, Asia-Pacific
Phone: +45 45 160 180
Email:
support@emea.kvh.com
(Mon.-Thu., 8 am-4:30 pm; Fri., 8 am-2 pm, +1 GMT)
KVH, TracVision, and the unique light-colored dome with dark contrasting baseplate are registered trademarks of KVH Industries, Inc.
All other trademarks are property of their respective companies. The information in this document is subject to change without notice.
No company shall be liable for errors contained herein. © 2019 KVH Industries, Inc., All rights reserved.
UHD7. With a SWM expansion kit installed, the TracVision system can far
Tuners Supported
52
104
54-1329 Rev. A | 72-0897 | 72-0898
6. Wire the SWM Expander...................... 9
7. Seat the DSWMs................................... 10
8. Wire the Receivers ............................... 11
9. Configure the Receivers...................... 13
1
