Installation and Owner's Manual
Manual de Instrucciones y del Propietario
Manuel d'Installation et d'Utilisation
2-Way Diverter Valve Trim
Acabado De Diversora
Garniture De Dérivation
Warranty Registration and Inquiry
For product warranty registration, TOTO U.S.A. Inc. recommends online warranty registration. Please visit
our web site http://www.totousa.com. If you have questions regarding warranty policy or coverage, please con-
tact TOTO U.S.A. Inc., Customer Service Department, 1155 Southern Road, Morrow, GA 30260
(888) 295-8134 or (678) 466-1300 when calling from outside of U.S.A.
™
Connelly
TS221D
TS221DW
Advertisement
Related Manuals for Toto Connelly TS221D
Summary of Contents for Toto Connelly TS221D
- Page 1 TS221DW Warranty Registration and Inquiry For product warranty registration, TOTO U.S.A. Inc. recommends online warranty registration. Please visit our web site http://www.totousa.com. If you have questions regarding warranty policy or coverage, please con- tact TOTO U.S.A. Inc., Customer Service Department, 1155 Southern Road, Morrow, GA 30260...
-
Page 2: Table Of Contents
Rough-In Dimensions ..................17 THANKS FOR CHOOSING TOTO! The mission of TOTO is to provide the world with healthy, hygienic and more comfortable lifestyles. We design every product with the balance of form and function as a guiding principle. Congratulations on your choice. -
Page 3: Included Parts
INCLUDED PARTS Check to make sure that all these parts were included in your packaging: Handle Assembly* Escutcheon* Collar Screw and Threaded Set Screw and Adapter Lock Washer Extension Hex Wrench * Actual product may vary in appearance depending on the model. INSTALLATION PROCEDURE 2-1/2”... - Page 4 Installation Procedure (continued) 3. Use an adjustable wrench to Valve* tighten the threaded extension into the valve. Threaded Extension 4. Secure adapter to the valve with the included screw and lock washer. Adapter Lock Washer Screw 5. Turn the adapter manually until it “clicks”...
-
Page 5: Care & Cleaning
Installation Procedure (continued) 6. Hold the escutcheon against the wall with the TOTO logo at the bottom. Tighten the collar onto the threaded extension with an adjustable wrench to secure. Collar Escutcheon 7. Slide handle assembly onto the adapter, and tighten onto the collar by tightening set screw. -
Page 6: Warranty
INC., 1155 Southern Road, Morrow, GA 30260 (888) 295 8134 or (678) 466-1300, if outside the U.S.A. If, because of the size of the Product or nature of the defect, the Product cannot be returned to TOTO, receipt by TOTO of written notice of the defect together with proof of purchase (original sales receipt) shall constitute delivery.
