Summary of Contents for MSI Optix G24 Series
- Page 2 I.Safety Prevention Measures Please always place The altitude and the Do not hold the plug Do not use a broken this device on a stable tropical environment w i t h w e t h a n d ; power plug nor keep surface;...
-
Page 3: Installation Instructions
II.Installation Instructions 1.Accessories Power cord Base/Stand Signal cable Warranty card User manual (The above pictures are for illustration only and the physical accessories shall govern.) 2. Angle Adjustment 2.1 The screen can be adjusted by 2.2 When adjusting the angle of the inclining forward and backward;... - Page 4 III. Connect the Monitor to PC Before connecting the LCD monitor to the PC, please power down the PC and the monitor. Power Plug Connect the power cord of the monitor into the POWER port in the back of the monitor. VGA Port Connect the VGA cable into the VGA IN port in the back of the monitor (this needs the...
-
Page 5: User Setup
IV. User Setup 1. Schematic Diagram of Keys 2. Description of Keys' Functions Pops up the menu/Backs to the previous menu (in case of main menu, exits from the whole menu). When the menu is activated, used as the left function selection key, and decreases progressively the value of the progress bar;... - Page 6 V. Operation Menu (OSD) Function Descriptions Second First level First level Third level Third level Second level Description level menu item menu icon menu item menu item menu icon menu icon Brightness Adjust display brightness NONE NONE NONE NONE Adjust display contrast Contrast NONE NONE...
- Page 7 Second First level First level Second level Third level Third level Description level menu item menu icon menu item menu item menu icon menu icon English English English Française Française Française Deutsch Deutsch Deutsch Italiano Italiano Italiano Language Español Español Español 繁中...
- Page 8 VI. FAQ Faults occurring Possible solutions The power indicator ◆ Check if the power is on. light is not on Check if the power cord is connected. ◆ Impossible plug-and-play ◆ Check if the function of plug-and-play of the device is compatible with PC.
-
Page 9: Product Specifications
VII. Product Specifications Picture Picture Diagonal Dot distance (mm) Optimal aspect ratio dimensions (mm) dimensions resolution 60cm(23.6″) 16:9 521.4*293.28 0.27156x0.27156 1920*1080 Storage -20 ℃ to 60 ℃ Ambient temperature temperature Working 5 ℃ to 40 ℃ temperature Humidity RH for operation 20% to 80% Note: The actual application of the above parameters shall be subject to the specific model.
