RedMax 596766202 Use And Care Manual

RedMax 596766202 Use And Care Manual

48 oz handheld sprayer
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
596766202
48 oz Handheld Sprayer
Use and Care Manual
CAUTION: Read and follow all instructions
For Help, Information or Parts, Contact your nearest authorized
service dealer. Visit RedMax® online at www.redmax.com.
Manual No. 183854
Rev. 03 09/20/18
ECN18-078
5 1/2" x 8 1/2" Booklet

Advertisement

loading

Related Manuals for RedMax 596766202

Summary of Contents for RedMax 596766202

  • Page 1 48 oz Handheld Sprayer Use and Care Manual CAUTION: Read and follow all instructions For Help, Information or Parts, Contact your nearest authorized service dealer. Visit RedMax® online at www.redmax.com. Manual No. 183854 Rev. 03 09/20/18 ECN18-078 5 1/2” x 8 1/2” Booklet...

  • Page 2: Safety Precautions

    For safe use of this product, you must read and follow all instructions before use. TEST SPRAYER WITH WATER BEFORE USING ANY CHEMICALS. If you experience problems or have questions contact your nearest authorized service dealer. Visit RedMax® online at www.redmax.com. Page 2...
  • Page 3 ASSEMBLY INSTRUCTIONS SELECT USING NOZZLE CHART BELOW ADJUSTABLE CONE USES: (Nozzle selections may vary by model) Spot spraying in or around flower beds, trees, and shrubs. Edging along fences, driveways, and walkways. Killing brush such as poison ivy, poison oak, kudzu and wild blackberry.
  • Page 4 OPERATING INSTRUCTIONS CONTINUED Pressurizing 1. Pressurize the sprayer by pumping the handle in a smooth up and down motion. (Figure C). Figure C Spraying 1. Direct brass nozzle away from you and press trigger to begin spraying. (Figure D). 2. Turn the brass nozzle tip to adjust the spray pattern.

  • Page 5: Changing Nozzles

    OPERATING INSTRUCTIONS CONTINUED Changing Nozzles This sprayer comes with a brass adjustable cone nozzle installed. It may be replaced by one of the sup- plied fan tips, using the supplied cap nut. 1. Remove brass adjustable cone nozzle from sprayer by turning the plastic nozzle body counter-clock- wise (Figure G).
  • Page 6 PUMP SEAL MAINTENANCE WARNING: ALWAYS DEPRESSURIZE SPRAYER BEFORE DISASSEMBLING AS DESCRIBED IN THE RELEASE TANK PRESSURE SECTION. Shut-off Seal 1. Push PRV dial forward to release tank pressure (Figure 1). 2. Unscrew nozzle base from front of sprayer by turning counter-clockwise (Figure 2). 3.
  • Page 7 TROUBLESHOOTING/ KITS, PARTS & ACCESSORIES TROUBLE LOOK FOR REMEDY 1. Dirt or debris on pump gasket or 1. Clean dirt or debris from pump gas- Sprayer leaks at pump or closure. ket and closure as described in Pump sprayer does not build pres- 2.
  • Page 8 SERVICE KITS, PARTS & ACCESSORIES ARE AVAILABLE BY CONTACTING YOUR NEAREST AUTHORIZED SERVICE DEALER VISIT REDMAX® ONLINE AT WWW.REDMAX.COM. Page 8...
