- Page 1 Register your product and get support at www.philips.com/welcome EN User manual DA Brugervejledning DE Benutzerhandbuch ES Manual del usuario FR Mode d’emploi Manuale utente NL Gebruiksaanwijzing SV Användarhandbok MCD388...
-
Page 3: Table Of Contents
Contents 1 Important Safety Notice 2 Your DVD Micro Theater Introduction What’s in the box Overview of the main unit Overview of the remote control 3 Connect Place the unit Before you connect Connect TV Connect FM antenna Connect power Place the unit 4 Get started Prepare the remote control... -
Page 4: Important
1 Important Safety Important Safety Instructions a Read these instructions. b Keep these instructions. c Heed all warnings. d Follow all instructions. e Do not use this apparatus near water. f Clean only with dry cloth. g Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. - Page 5 b Fix new fuse which should be a BS1362 5 Amp, A.S.T.A. or BSI approved type. c Refit the fuse cover. If the fitted plug is not suitable for your socket outlets, it should be cut off and an appropriate plug fitted in its place. If the mains plug contains a fuse, this should have a value of 5 Amp.
-
Page 6: Notice
European Community. Any changes or modifications made to this device that are not expressly approved by Philips Consumer Lifestyle may void the user’s authority to operate the equipment. Recycling Your product is designed and manufactured with high quality materials and components, which can be recycled and reused. - Page 7 Please inform yourself about the local rules on separate collection of batteries. The correct disposal of batteries helps prevent potentially negative consequences on the environment and human health. Environmental information All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet.)
- Page 8 • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Norge Typeskilt finnes på...
-
Page 9: Your Dvd Micro Theater
2 Your DVD Micro Theater Congratulations on your purchase, and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.Philips.com/welcome. Introduction With this unit, you can: • watch video from DVD/VCD/SVCD or USB/SD/MMC devices •... -
Page 10: Overview Of The Main Unit
Overview of the main unit Caution • Use of controls or adjustments or performance of procedures other than herein may result in hazardous radiation exposure or other unsafe operation. STANDBY/ECO POWER • Turn on the apparatus or switch to the Eco Power standby mode. b Display panel •... -
Page 11: Overview Of The Remote Control
n TUNING • Search within a track or disc. • Tune to a radio station. o SOURCE • Select a source. • Start or pause play. • Stop play. • Erase a program. • Activate/deactivate the demonstration mode. Overview of the remote control •... - Page 12 c DISPLAY/RDS • Display play information on a connected TV. • For selected FM radio stations: display RDS information. d DISC MENU • For video discs: access or exit the disc menu. • For video discs with playback control(PBC): turn on/off PBC. e SLEEP/TIMER •...
-
Page 13: Connect
3 Connect Place the unit Place the unit near to the TV. Keep the speakers at the normal listening ear-level and directly parallel to the listening area. Place the subwoofer at the corner of the room or at least one meter away from the TV. - Page 14 Connect HDMI (High Definition Multimedia Interface), DVI (Digital Visual Interface), or HDCP (High-bandwidth Digital Contents Protection)-compliant TVs through HDMI for the best picture quality. This connection transmits both video and audio signals. Through this connection, you can watch DVDs that contain HD (High-Definition) content. Note •...
- Page 15 Option 3: Connect through component video Connect a progressive scan TV through component video for higher quality video. Pr/Cr Pb/Cb COMPONENT VIDEO IN PUT Connect component video cables (red/ blue/green - not supplied) to: • COMPONENT VIDEO OUT (Pr/Cr Pb/Cb Y) sockets on this unit. •...
-
Page 16: Connect Fm Antenna
Connect audio cables L AUDIO OUT R To play sound from the TV through this unit, connect audio cables (red/white - not supplied) to: • AUX IN L/R sockets on this unit. • the audio output sockets on the TV. Connect FM antenna •... -
Page 17: Place The Unit
Place the unit Attach the rear cover. Attach the supplied table stand to the bottom of the main unit. Place the main unit on a hard, flat and stable surface. • You can also mount the unit on a wall. -
Page 18: Get Started
Always follow the instructions in this chapter in sequence. If you contact Philips, you will be asked for the model and serial number of this apparatus. The model number and serial number are on the back of the apparatus. Write the numbers here: Model No. -
Page 19: Find The Correct Viewing Channel
• Go to the lowest channel on your TV, then press the Channel Down button until you see the Philips screen. • Press the source button repeatedly on the remote control of your TV. -
Page 20: Turn On Progressive Scan
Press SYSTEM MENU to exit the menu. Press DISC followed by numeric key “1” to turn off the progressive scan mode on the unit. » The blue Philips DVD background screen is displayed. Note • In the progressive mode, if you press followed by numeric key “1”... -
Page 21: Play
5 Play Note • With some disc/file types, play may differ. Play discs Caution • Never look at the laser beam inside the unit. • Risk of product damage! Never play discs with accessories such as disc stabilizer rings or disc treatment sheets. -
Page 22: Play From Usb/Card
Play from USB/CARD Note • Ensure that the USB device or SD/MMC card contains playable music, pictures or video. Slide down SLIDE OPEN , then insert the device. • For USB devices: Insert the USB plug into the socket. • For SD/MMC cards: Insert the card into the SD/MMC socket. -
Page 23: Play Control
Play control Select repeat/shuffle play options During play, press MODE/DIM repeatedly to select a repeat option or the shuffle play mode. • To resume normal play, press MODE/DIM repeatedly until no option is displayed. Repeat A-B (DVD/VCD/CD/MP3/ WMA) During music or video play, press A-B at the start point. -
Page 24: Picture View Options
Select a file, then press ANGLE/PROG to add the file to the program list. Repeat step 2 until the program is complete. Press DISC MENU until the program list is displayed. Press OK / to play the program. To delete a file from the [Program List]: Press DISC MENU until the program list is displayed. -
Page 25: Adjust Settings
6 Adjust settings Press SYSTEM MENU. Select a setup page. Select an option and then press Select a setting and then press OK / • To return to the previous menu, press • To exit the menu, press MENU. General setup On [General Setup Page], you can set the following options: [TV Display]... -
Page 26: Video Setup
[Night Mode] Make loud sound level softer and soft sound level louder so that you can watch the DVD movies at a low volume, without disturbing others. • [On] – enjoy quiet viewing at night (DVDs only). • [Off] – enjoy surround sound with its full dynamic range. - Page 27 Note • If the language you have set is not available on the disc, the disc uses its own default language. • For some discs, the subtitle/audio language can only be changed from the disc menu. [Parental] Restricts access to discs that are unsuitable for children.
-
Page 28: Tune To Fm Radio Stations
7 Tune to FM radio stations Ensure that you have connected and fully extended the supplied FM antenna. Press TUNER. Press and hold When the frequency indication starts to change, release the button. » The FM tuner tunes to a station with strong reception automatically. -
Page 29: Show Rds Information
Note • The accuracy of the transmitted time depends on the RDS station that transmits the time signal. Show RDS information RDS (Radio Data System) is a service that allows FM stations to show additional information. If you tune to a RDS station, a RDS icon and the station name are displayed. -
Page 30: Adjust Volume Level And Sound Effect
8 Adjust volume level and sound effect Adjust volume level During play, press VOL +/- to increase/ decrease the volume level. Adjust subwoofer volume Press SUBW VOL to adjust the subwoofer volume. Select a sound effect Note • You cannot use different sound effects at the same time. -
Page 31: Other Features
9 Other features Activate demonstration mode You can see an overview of all features. In standby mode, press unit to activate the demonstration mode. » A demonstration of major available features starts. To deactivate the demonstration mode: Press on the main unit again. Adjust brightness of display panel In standby mode, press MODE/DIM... -
Page 32: Product Information
• For audio players with headphone sockets: Connect a 3.5mm audio cable to the MP3 LINK socket and to the headphone socket on the audio player. Select the MP3 Link/AUX source. Start play on the audio player. Record to a digital recorder You can record audio from this unit to a digital recorder. -
Page 33: Supported Disc Formats
Tuner (FM) Tuning Range 87.5 - 108MHz Tuning grid 50KHz Sensitivity - Mono, 26dB S/N Ratio <22 dBf - Stereo, 46dB S/N Ratio >43 dBf Search Selectivity >28dBf Total Harmonic Distortion <2% Signal to Noise Ratio >55dB Speakers Speaker 4ohm Impedance Speaker Driver 3”... -
Page 34: Rds Program Types
Supported formats: • USB or memory file format FAT12, FAT16, FAT32 (sector size: 512 bytes) • MP3 bit rate (data rate): 32-320 Kbps and variable bit rate • WMA v9 or earlier • Directory nesting up to a maximum of 8 levels •... -
Page 35: Troubleshooting
If the problem remains unsolved, go to the Philips web site (www.philips.com/support). When you contact Philips, ensure that your unit is nearby and the model number and serial number are available. No power •... - Page 36 • Moisture has condensed inside the system. Remove the disc and leave the system turned on for about an hour. Disconnect and reconnect the AC power plug, and then turn on the system again. • As a power-saving feature, the system turns off automatically 15 minutes after disc play reaches the end and no control is operated.
- Page 38 © 2010 Koninklijke Philips Electronics N.V. All rights reserved. Document order number: MCD388_12_UM_V4.0...
