DIGITAL PORTION SCALE
MODEL PS-7
With Check Weighing Mode
OWNER'S MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Detecto PS-7

Summary of Contents for Detecto PS-7

  • Page 1 DIGITAL PORTION SCALE MODEL PS-7 With Check Weighing Mode OWNER’S MANUAL...

  • Page 3: Table Of Contents

    Installation ......1 Digital Portion Scale. The PS-7 is equipped with a Unpacking .
  • Page 4 8528-M303-O1 Rev D  PS-7...

  • Page 5: Installation

    Access is via a removable cover on the bottom of the scale. The PS-7 can operate for up to 20 hours of continuous use with a fully charged battery pack. Full charging the rechargeable battery pack before the first use is necessary.

  • Page 6: Installing A Replacement Battery

    If the battery voltage drops too low for accurate weighing, the scale will automatically shut off and you will be unable to turn it back on. When the low battery indicator is displayed, the operator should plug-in the 15VDC adapter. 8528-M303-O1 Rev D  PS-7...

  • Page 7: Display Annunciators

    (between the Under and the Over Limit settings). UNDER This annunciator triangle is turned on (with NO display backlight) to signal that the weight is less than the Under Limit setting. 8528-M303-O1 Rev D  PS-7...

  • Page 8: Key Functions

    3. Press and hold the TARE key and the ON/OFF key for 3 seconds to enter the Configuration mode. 4. Press the TARE key to confirm the setting for each menu. 5. In Gravity Compensation mode, press the TARE key to choose number from 0~9. 8528-M303-O1 Rev D  PS-7...

  • Page 9: Operation

    Display Backlight The PS-7 is equipped with a back lit display. The display backlight will be turned on during weighing and will automatically turn off 5 seconds after the weight has been removed from the scale.

  • Page 10: Check Weighing

    (ex: a pan or a plate) or zero the display. To exit the Check Weighing Mode and return to the Normal Weighing Mode, press the MODE key. The scale will beep once, and the Under annunciator triangle will turn off. 8528-M303-O1 Rev D  PS-7...

  • Page 11: Check Weighing Operation

    Over Limit weight setting. NOTE: The display will also show (with a RED display backlight) and the scale will beep three times when the weight is greater than the Over Limit weight setting. Over 8528-M303-O1 Rev D  PS-7...

  • Page 12: Configuration

    3. Press the UNIT key to toggle between: Enabled (display will change to Disabled (display will change to 4. Press the TARE key and then the UNIT key 3 times. 5. The display will change to Unit 6. Proceed to AUTOMATIC SHUTOFF. 8528-M303-O1 Rev D  PS-7...
  • Page 13 3. Press the TARE key to display the buzzer (beeper) status. 4. Press the UNIT key to toggle between: Enabled (display will change to Disabled (display will change to 5. Press the TARE key and then the UNIT key. 6. Proceed to GRAVITY COMPENSATION. 8528-M303-O1 Rev D  PS-7...

  • Page 14: Gravity Compensation

    0 to 9. 6. Repeat step 5 until the desired gravity value has been entered. 7. Press the ON/OFF key (to confirm the entered gravity value), and return the scale to the normal operating mode. 8528-M303-O1 Rev D  PS-7...

  • Page 15: Display Messages

    (-10%) CARE AND MAINTENANCE The heart of the PS-7 Digital Portion Scale is a precision load cell located in the center of the scale base. It will provide accurate operation indefinitely if protected against overload of scale capacity, dropping items on scale, or other extreme shock.
  • Page 16 Cardinal Scale Manufacturing Co. 203 E. Daugherty, Webb City, MO 64870 USA Ph: 417-673-4631 or 1-800-641-2008 Fax: 417-673-2153 Technical Support: 1-866-254-8261 E-mail: tech@cardet.com 8528-M303-O1 Rev D 12/18 IN-8299 80001D 8528-M303-O1 Rev D  PS-7...
