Philips HDRW720/17B Quick Start Manual

If you don't have a set-top box follow the instructions for 'Connection without Set-Top Box'. If you have a set-top box,
follow the instructions for 'Connection without Set-Top Box' then the instructions for 'Connection with Set-Top Box'.
Connection without Set-Top Box
Before Connecting
Your TV should be plugged into the wall jack via the antenna
cable. Unplug the antenna cable from the TV.
Connecting
1
Connect the antenna cable (plugged out from the
TV) to ANTENNA IN socket at the rear of
the recorder.
2
Connect the provided antenna cable into the TV
OUTPUT socket at rear of the recorder and into
the Antenna In socket of the TV.
3
a
Connect the Video (CVBS) cable (yellow) to the
VIDEO (CBVS) socket of the TV and to the OUT 2
VIDEO (CBVS) socket at rear the recorder.
or
3
b
Connect the S-Video cable to the S-VIDEO socket
of the TV and to the OUT 2 S-VIDEO socket at rear
the recorder.
4
Connect the red Audio cable to the red socket of
the TV and recorder and the white Audio cable to
the white socket of the TV and recorder.
5
Connect the power cable from the recorder to an
AC power outlet.
DVD Recorder/Hard Disk
Connection with Set-Top Box
With the TV Guide on Screen TM System, your new Philips
Hard Disk & DVD Recorder can control your set-top box
(satellite receiver or cable TV box) via the IR-Blaster (G-
LINK cable). You can now only record TV shows that are
received through the cable box.
Connecting
Follow the instructions under 'Connection without Set-Top
Box' to connect the recorder then proceed to step 1 below.
1
Connect the G-LINK cable (supplied) to the G-LINK
socket at the rear of the recorder.
2
Place the IR-Blaster transmitter in front of your set-
top box in such a way that it can acquire the signal
broadcasted by the transmitter.
3
If not already connected, plug in the power cable of
your set-top box to an AC power outlet.
Television
DVD Recorder/Hard Disk
Cable Box
IR-Blaster
Positioning of G-LINK transmitter
Set-Top Box
IR-Blaster
Note
The IR-Blaster must be placed about one inch in front of
the set-top box.
Remote Control
Television
Description
9
1
REC/OTR STANDBY
Record the current TV Switch on or off.
show and mark record-
10
DISC MENU
ings in the TSB to be
Display the DVD menu.
stored on HDD.
11
INFO
2
TUNER
Display additional
Switch to live TV.
information.
3
COLOUR BUTTONS
12
GUIDE/TV
Call up the GUIDE
Have different functions
Plus+® system.
(shown at bottom of
13
screen) in different menus.
LEFT , RIGHT ,
4 UP , DOWN ,
BROWSER HDD
OK
Call up the HDD menu.
Used to navigate through
5
STOP the menus.
Stop playback/recording.
14
PLAY
Hold down to open and
Play/resume from
close the disc tray.
disc/HDD.
6
PAUSE
15
JUMP FWD
Pause playback.
To jump forward a
7
JUMP BACK certain time.
Jump back a certain time.
16
NEXT
8
PREVIOUS Next Chapter or Title.
Previous chapter or title.
Hold down to search
Hold down to search forwards.
backwards.
Finding the Viewing Channel Installing Set-Top Box
1
Press the STANDBY-ON button on the recorder. If you do not have a set-top box, go to step C.
1
The recorder will display 'IS THE TV ON?'
Select 'Yes' and press OK
Tip
UP
OPEN/CLOSE TV GUIDE OK Selected 'No' if you don't and proceed to Step C.
HARD DISK & DVD RECORDER
STANDBY-ON 2
DOWN
STANDBY-ON OPEN
Select 'Yes' and press OK
2 Front Panel of Recorder
set-top box. Select 'No' for all other.
Switch on the TV set.
Tip
3
If you have selected 'No', proceed to Step C.
Press the '0' button on the TV remote control, scroll
3
down until you see the Menu Language menu. This is
Press UP
your correct viewing channel for the recorder.
on the recorder which the cable service is tuned to
Tip
and press OK
If unable to find the correct viewing channel, check your
4
connections again or check your TV's user manual.
You are now prompted to connect the IR-Blaster, do
so if you haven't.
Tip
For more information on installing additional receivers, see
the user manual.
1
Press UP
Installation
of your set-top box and press OK
Follow the on-screen instructions:
Tip
1
Select your Menu Language. If you do not see your brand, select 'not listed'.
2
Tip
Read the information on screen carefully and press
Use the recorder's remote control to make the selections.
2
OK
Select your Audio Language.
3
3
Change the channel on your set-top box to 02 and
Select your Subtitle Language.
press OK
4
Select your TV Shape.
4
The recorder will now attempt to change the channel
5
Select your Country.
number to 09 on your set-top box. Press UP
6
DOWN
The recorder will now ask if you have connected
your antenna. Do so if you haven't.
7
The recorder will now start automatic Channel Search.
Tip
If no channels were found, check your antenna connection
and check your user manual to search for channels.
8
Check Date and Time and press OK to finish.
TV Guide on Screen Installation
TM
5
1
If it has not, refer to the user manual for more details
Press OK when you see 'Welcome to Your TV
on installing your set-top box.
Guide on Screen System'.
2 6
Find your IR-Blaster if you haven't connected it Check the settings on screen, if they are incorrect select
and press OK . 'No, repeat setup process'. If they are correct, select 'Yes,
3
end setup process' and press OK
Press UP or DOWN to select your
7
country and press OK . Press OK
on Screen
Step 2: Configuring for Cable
You have indicated that you have. Now the TV on Screen complete the setup.
System need some additional information.
8
Switch the set-top box to the channel that transmits
Is a cable box connected to this DVD Recorder?
Yes the TV Guide data, leave it on overnight to load the
No
program data. It will be available in the next 24 hours.
philips
Using your your DVD Recorder remote, move up or down to highlight your answer. Press
OK to choose.
4
Key in your zip code and press OK .
if you have cable service.
if you have a external
or DOWN to select the channel
.
Finalize Installation
or DOWN to select the brand
.
to confirm.
.
or
to select 'Yes' if it has.
Step 2: Configuring for Cable
Testing complete.
If your cable box automatically changed to and remained on
channel 09, the test was successful.
Is your cable box now tuned to channel 09?
Yes
No
Test this code again
Using your your DVD Recorder remote, move up or down to highlight your answer. Press
OK to choose.
to confirm.
after you finish reading about TV Guide
TM System information and OK again to
Important Note
You must leave the recorder in Standby mode at night in
order for it to load new program listings.
