• While every effort has been made to ensure that the information contained in this guide is
accurate and complete, no liability can be accepted for any errors or omissions
• NUVICO reserves the right to change the specifications of the hardware and software
described herein at any time without prior notice.
• No part of this guide may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language in any form, by any means, without prior written
permission of NUVICO.
• NUVICO makes no warranties for damages resulting from corrupted or lost data due to a
mistaken operation or malfunction of the cameras, peripheral devices, or unapproved/
unsupported devices.
Warning and Caution
WARNING!
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS
THROUGH THE VENTILATION GRILLS OR OPENINGS ON THE EQUIPMENT.
CAUTION!
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral is intended to alert the user to
the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the appliance.
1

Advertisement

Table of Contents
loading

Summary of Contents for easynet EC-2M-OV39N-ONV

  • Page 1 Disclaimer • While every effort has been made to ensure that the information contained in this guide is accurate and complete, no liability can be accepted for any errors or omissions • NUVICO reserves the right to change the specifications of the hardware and software described herein at any time without prior notice.
  • Page 2 FCC Compliance Statement FCC INFORMATION: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT.
  • Page 3 Important Safeguards • Read these instructions. • Heed all warnings. • Follow all instructions. • Do not use this equipment near water. • Clean only with dry cloth. • Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
  • Page 4: Table Of Contents

    1. Introduction ................ 5 About This Manual ..................5 1.1 Key features ..................... 5 1.2 Content Verification .................. 6 1.3 EC-2M-OV39N-ONV HD Camera Dimensions ......... 7 2. Installation and Configuration ..........8 2.1 Installation ....................8 2.2 Adjusting 3-Axis Gimbal ................9 2.3 Connection Cable ...................
  • Page 5: Introduction

    1. Introduction About This Manual Thank you for purchasing our EasyNet EC-2M-OV39N-ONV HD Camera. This full-featured camera comes equipped with a progressive scan imager, which transmits at high definition 1920 x 1080 resolution as well as enhances low light sensitivity and provides crystal clear pictures even in challenging lighting environments.
  • Page 6: Content Verification

    1. Introduction 1.2 Content Verification Before installing the camera, please make sure that all of the following items are included in the box. 1. EC-2M-OV39N-ONV HD Camera 2. Installation Guide 3. Mounting Template Sheet 4. Service Monitor Cable and Controller...
  • Page 7: Ec-2M-Ov39N-Onv Hd Camera Dimensions

    1. Introduction 1.3 EC-2M-OV39N HD Camera Dimensions...
  • Page 8: Installation And Configuration

    2. Installation and Configuration Installation and Configuration 2.1 Installation The dome camera is for use in surface or pendent mounting applications and the mounting The dome camera is for use in surface or pendent mounting applications and the mounting The dome camera is for use in surface or pendent mounting applications and the mounting member must be capable of supporting loads of up to 3.3lb (1.5kg).
  • Page 9: Adjusting 3-Axis Gimbal

    2. Installation and Configuration 2. Installation and Configuration 2.2 Adjusting 3-Axis Gimbal Axis Gimbal The Gimbal mechanism yields maximum rotation and placement as shown below. mechanism yields maximum rotation and placement as shown below. mechanism yields maximum rotation and placement as shown below. •...
  • Page 10: Connection Cable

    2. Installation and Configuration 2.3 Connection Cable Wire Color Description Red: 24VAC Main Power, 2pin terminal, 24VAC (20VA or 8.4W) White: 24VAC/GND Heater Power, 2pin terminal, 24VAC (40VA or 20W) Green: 24VAC To use the built-in heater, 24VAC power supply must be Black: 24VAC/GND connected to this dedicated input.
  • Page 11: Using Service Monitor Port And Wire Controller

    2. Installation and Configuration 2.4 Using Service Monitor Port and Wire Controller Service monitor output port (J3) is located on the board of the dome camera, and is used for two purposes. 1. Adjust zoom and focus. Once you connect the wire controller to the service monitor port, then, using your own handheld service monitor, press buttons to zoom in or zoom out to desired focal length.
  • Page 12: Resetting To The Factory Default Settings

    2. Installation and Configuration 2.5 Resetting to the Factory Default Settings To reset the EC-2M-OV39N HD Camera to the original factory settings, use the Reset button (SW1) on the board of the dome camera, as described below: Using the Reset Button Follow the instructions below to reset the HD Camera to the factory default settings using the Reset button.
  • Page 13: Program And Operation

    3. Program and Operation Program and Operation 3.1 Detecting IP cameras with IP Cam Finder Detecting IP cameras with IP Cam Finder IP Cam Finder utility automatically discovers and displays NUVICO IP Cameras on your network. So please IP Cam Finder utility automatically discovers and displays NUVICO IP Cameras on your network. So please IP Cam Finder utility automatically discovers and displays NUVICO IP Cameras on your network.
  • Page 14: Access From A Web Browser

    3. Program and Operation Program and Operation The Network Camera can be used with Windows operating system and web browsers. The Network Camera can be used with Windows operating system and web browsers. The Network Camera can be used with Windows operating system and web browsers. The recommended web browsers are Internet Explorer, Safari, Firefox, Opera and Google Chrome with Windows.
  • Page 15: Access From The Internet

    3.3 Access from the internet Once the Network Camera is connected to the Internet, it is accessible on your local network (LAN). To access the video encoder from the Internet, you must configure your broadband router to allow incoming data traffic to the video encoder.
  • Page 16: Live View Page

    3.5 Live View Page The live view page comes in several screen modes like 1920x1080, 1280x1024, 1280x720, 704x480(576), 640x480, 352x240(288), and 320x240. Users are allowed to select the most suitable one out of those modes. Please adjust the mode in accordance with your PC specifications and monitoring purposes. General controls Live View Page Search &...
  • Page 17 The Full Screen button causes the video image to fill the entire screen area. No other The Full Screen button causes the video image to fill the entire screen area. No other The Full Screen button causes the video image to fill the entire screen area. No other windows will be visible.
  • Page 18: Network Camera Setup

    3.6 Network Camera Setup This section describes how to configure the network camera, and is intended for product Administrators, who have unrestricted access to all the Setup tools; Operators, who have access to the settings for Basic, Live View, Video & Image, Event, and System Configuration. You can configure the network camera by clicking Setup in the top right-hand corner of the Live View page.
