Summary of Contents for Philips 32PW9570/05
- Page 2 MODEL : PROD. NO : Please note the reference numbers for your TV set located on the packaging or on the back of the set.
-
Page 3: Table Of Contents
Due to continuous product improvements this manual is subject to change without notice. End of life directives Philips is paying a lot of attention to producing environmentally-friendly in green focal areas.Your new TV contains materials which can be recycled and reused. -
Page 4: Preparation
Preparation & Place the TV on a solid surface. For ventilation, leave at least 5 cm free all around the TV. Do not place the TV on a carpet.To prevent any unsafe situations, do not place any objects on top of the TV. Avoid heat, direct sunlight and exposure to rain or water. -
Page 5: Your Remote Control
Use of the remote control Note: For most keys pressing a key once will activate the function. Pressing a second time will de-activate it. When a key enables multiple options, a small list will be shown. Press repeatedly to select the next item in the list. The list will be removed automatically after 4 seconds or press 1) B Standby 2) VCR DVD SAT AMP CD... - Page 6 Use of the remote control 16)x Pixel Plus 2 demo on/off In the right part Pixel Plus 2 and Digital Natural Motion are switched on. 17)Ì Cinema Go: 18) Q Surround mode Incredible surround With stereo transmission, and when Incredible surround is selected, it seems as VCR DVD SAT AMP CD though the loudspeakers are spread further apart from one another.
-
Page 7: To Use The Menus
To use the menus VCR DVD SAT AMP CD † Select Ò ‡ π ® cursor to select æ adjustments ® key to activate ® ® return or switch ® main menu on/off MENU Press the i key on the remote control to get information about the selected menu item. -
Page 8: Store Tv Channels
Store TV channels After language and country are set correctly, you can now search for and store the TV channels in two different ways: using Automatic Installation or Manual Installation (tuning-in channel by channel). Select your choice with the cursor right. Automatic installation Automatic install Install... -
Page 9: Reshuffle The Programme List
Reshuffle the programme list You can change the order of the stored TV channels. & Select in the Installation menu. Reshuffle é Follow the instructions on screen. TV Setup General Source Decoder Setup Menu background Smart surf Factory settings Tilt adjust Programme title Teletext level 2.5 Auto surround... -
Page 10: Source
Auto Surround Sometimes the broadcaster transmits special signals for Surround Sound encoded programmes.The TV automatically switches to the best surround sound mode when is switched Surround Set/Change code The Child lock feature (see TV, Features, p. 11) allows you to lock channels to prevent others from watching certain programmes.To watch locked channels, a 4-digit code must be entered.The Set/Change code menu item... -
Page 11: Demo
Demo Setup Auto demo Demo Install Dealer demo - Digital options - Light sensor - Comb filter TV menu Press the key on the remote control to summon the main menu. MENU Press the key on the remote control to get information about the selected menu item. Picture menu Picture Sound Features... -
Page 12: Sound Menu
Sound menu Sound Smart sound Equalizer Volume Balance (Loudness) Headphone volume Surround mode (Dual I-II) (Mono/Stereo) (Nicam/Analogue) (3D effect) Delta volume Active Control The TV continuously measures and corrects all incoming signals in order to provide the best picture possible. &... -
Page 13: Features Menu
Features menu Features Programme list Subtitle Sleeptimer On during mute Child lock On timer Zoom Programme list Press the key to switch over to the selected TV channel or external. Select subtitles The subtitle page must be stored for each TV channel: Switch on teletext and select the proper subtitle page from the index. -
Page 14: Teletext Guide
Teletext guide TV channels which broadcast teletext also transmit a page with the programme guide of the day. If the displayed teletext programme guide page satisfies the Video Programming via Teletext (VPT) requirements, it will be possible to record, remind, watch or lock programmes. page ball selection ball BBC1... -
Page 15: Teletext
Teletext Most TV channels broadcast information via teletext.This TV has a 1200 pages memory that will store most broadcasted pages and subpages to reduce waiting time. After each programme change, the memory is refreshed. Switch Teletext on and off Press b to switch the teletext on. 102 W «03 04 05 06 07 08 09 10 11 12»... - Page 16 Teletext menu (only available in full screen teletext mode) & Press the key to activate the menu. MENU é Press the cursor up/down to select the menu items. “ Press the cursor right to activate. Reveal Reveals/conceals hidden information on a page, such as solutions to riddles and puzzles.
-
Page 17: Connect Peripheral Equipment
Connect Peripheral Equipment There is a wide range of audio and video equipment that can be connected to your TV. The following connection diagrams show you how to connect them. Depending on the versions, the TV set is equipped with 2 or 3 SCART connectors EXT1, EXT2 and EXT3 located on the rear. -
Page 18: To Select Connected Equipment
Stereo amplifier and two extra front speakers AUDIO To select connected equipment Press the v key on the remote control repeatedly to select to where you connected your equipment at the back or the right side of your TV. Remark : Most equipment (decoder, recorder) carries out the switching itself, when it is switched on. * Only available on certain versions. -
Page 19: Audio- And Video Equipment Keys
Audio- and video equipment keys This system remote control operates the following Philips equipment:TV,VCR, DVD, SAT (RC5), AMP (+TUNER), CD; Press the Select Another device can be selected by pressing Select repeatedly within 2 seconds.The led will blink slowly to indicate the device. -
Page 20: Tips
Tips Do not touch, push or rub or strike the screen with anything hard as this may Care of the screen scratch, mar or damage the screen permanently. And please do not rub with dust clothes with chemical treatment. Do not touch the surface with bare hands or greasy cloth (some cosmetics are detrimental to the screen). -
Page 21: Information For Users In The Uk
Information for users in the UK (Not applicable outside the UK) Positioning the TV For the best results, choose a position where light does not fall directly on the screen, and at some distance away from radiators or other sources of heat. Leave a space of at least 5 cm all around the TV for ventilation, making sure that curtains, cupboards etc. - Page 24 ß...
