RS232C (RF4QR/NA GB Operation Board)
Fri. Sept., 06/2002
PRECAUTIONS
CAUTION: This installation should be made by
a qualified service person and should conform to
all local codes.
CAUTION: Changes or modifications not
expressly approved by the manufacturer may void
the user's authority to operate this equipment.
œ Make sure to also read carefully the instruction
manual for the VCR.
œ The contents of this manual may be modified without
prior notice or obligation.
œ Please note that we disclaim any liability for
damages that may have been caused by the use of
this product.
œ Do not use the VCR if smoke or a strange odor
comes from the unit, or if it seems not to function
correctly. Unplug the power cord immediately, then
consult a factory-authorized service center.
œ This manual shows all the commands for Sanyo time
lapse VCRs and real time VCRs equipped with an
RS-232C (or RS-485) connector.
The commands apply to the functions available on
each particular VCR. Therefore, if a function is not
available on your VCR the corresponding command
does not apply to your VCR.
Also, there may be some functions available on your
VCR that cannot be controlled by the command
indicated in this manual. For detailed information,
please read the VCR instruction manual.
Keep this manual handy for later reference.
œ If using the RS-485 interface to operate the VCR, it
is recommended that you use a SANYO brand
system controller.
œ If using the RS-232C interface to operate the VCR
using a computer, separate software is required.
(This software is not sold by SANYO.)
For customers in Canada
This class B digital apparatus complies with
Canadian ICES-003.
English
CONTENTS
PRECAUTIONS . . . . . . . . . . . . . . . . . . . . 1
INSTALLATION OF THE BOARD . . . . . . . . . . . 2
INTERFACE (RS-232C) . . . . . . . . . . . . . . . . 3
INTERFACE (RS-485) . . . . . . . . . . . . . . . . . 4
SETTING FOR RS-485 or RS-232C USE . . . . . . . 5
COMMANDS (RS-232C/RS-485) . . . . . . . . . . . 6
COMMANDS (RS-232C only) . . . . . . . . . . . . 12
COMMANDS (RS-485 only) . . . . . . . . . . . . . 13
COMMANDS TABLE (RS-232C/RS-485) . . . . . . 15
Declaration of Conformity
Model Number
: VZU-485/232C
Trade Name
: SANYO
Responsible party : SANYO FISHER COMPANY
Address
: 21605 Plummer Street,
Chatsworth, California 91311
Telephone No.
: (818) 998-7322
œ This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference,
and
(2) this device must accept any interference
received, including interference that may
cause undesired operation.
