Owner's Manual
IP Remote Access Unit
LISTED
About the B050-000
The B050-000 provides remote KVM access and control. You can use the B050-000 to
manage and monitor components in your servers through a modem or LAN, even if your
network is down. The B050-000 offers a comprehensive hardware solution for server
management.
Technical Support
If you need help installing, configuring or running the B050-000 IP Remote Access Unit,
call a Tripp Lite Technical Support Representative at (773) 869-1234 or visit Tripp Lite's
website at: www.tripplite.com
Note: Follow these instructions and operating procedures to ensure correct performance and to prevent damage to this unit or to its connected devices.
Copyright © 2006 Tripp Lite. All rights reserved. All trademarks are the property of their respective owners.
The policy of Tripp Lite is one of continuous improvement. Specifications are subject to change without notice.
Heading
Model #: B050-000
1F61
I.T.E.
Tripp Lite World Headquarters
1111 W. 35th Street, Chicago, IL 60609 USA
(773) 869-1234 • www.tripplite.com
