Pentair Berkeley 3PL Installation, Operation & Parts Manual

Description
Corrosion resistant convertible jet pumps (Models 3PL,
5PL, 7PL, 10PL, 10PLS11C and 15PLS11C) are adaptable
to either shallow or deep well installations. A shallow well
ejector (purchase separately) is used for suction lifts of
25 feet or less and can be used with drilled (cased) wells,
driven well points, and cisterns or lakes. With a deep well
ejector installed, the convertible jet pump can be used on
wells up to 110' deep (depending on ejector package used).
Pump is equipped with a capacitor start motor and a 30-50
psi preset pressure switch.
Unpacking
Open carton and remove pump. Check for loose, missing, or
damaged parts.
general safety information
reaD anD folloW
safety instrUctions!
this is the safety alert symbol. When you see this
symbol on your pump or in this manual, look for one of the
following signal words and be alert to the potential for
personal injury!
warns about hazards that will cause serious
personal injury, death or major property damage if ignored.
warns about hazards that can cause serious
personal injury, death or major property damage if ignored.
warns about hazards that will or can cause
minor personal injury or property damage if ignored.
note: Indicates special instructions which are important but
not related to hazards.
Carefully read and follow all safety instructions in this
manual and on pump.
Keep safety labels in good condition.
Replace missing or damaged safety labels.
electrical safety
Hazardous voltage. can shock, burn, or
cause death. Ground pump before connecting to power
supply. Disconnect power before working on pump, motor,
or tank.
293 WRIGHT STREET, DELAVAN, WI 53115 WWW.BERKELEYPUMPS.COM
PH: 888-782-7483
© 2013 Pentair, Ltd. All Rights Reserved.
InstallatIon, operatIon & parts Manual
Models 3PL, 5PL, 7PL, 10PL,
10PLS11C, 15PLS11C
Convertible Jet Pumps
capacitor voltage may be hazardous. To
discharge motor capacitor, hold insulated handle screwdriver
BY THE HANDLE and short capacitor terminals together. Do
not touch metal screwdriver blade or capacitor terminals. If
in doubt, consult a qualified electrician.
Wire motor for correct voltage. See "Electri cal" section
of this manual, motor nameplate, and diagram inside motor
junction box cover.
Ground motor before connecting to power supply.
Meet United States National Electri cal Code, Canadian
Elec tri cal Code, and local codes for all wiring.
Follow wiring instructions in this manual and in motor
junction box when connecting motor to power lines.
general safety
Hazardous pressure! Do not run pump
against closed discharge. Release all pressure on system
before working on any component.
Do not touch an operating motor. Modern
motors are designed to operate at high temperatures. To
avoid burns when servicing pump, allow it to cool for 20
minutes after shut-down before handling.
Do not allow pump or any system com po nent to freeze. To
do so will void warranty.
Pump water only with this pump.
Periodically inspect pump and system components.
Wear safety glasses at all times when working on pumps.
Keep work area clean, uncluttered and properly lighted;
properly store all unused tools and equipment.
Keep visitors at a safe distance from the work areas.
pump body may explode if used as a
booster pump unless relief valve capable of passing full
pump flow at 75 psi is installed.
california proposition 65 Warning
This product and related accessories contain
chemicals known to the State of California to cause cancer,
birth defects or other reproductive harm.
BE367 (Rev. 02/25/13)
