- Page 1 CIB 3023 (Z7309H01B) 10-Button Hands-Free Answer on Intercom (HFAI) Voice Terminal (3161) CIB 3023 Comcode 105-253-025 Issue 3...
- Page 2 CIB 3023 (Z7309H01B) 10-Button Hands-Free Answer on Intercom (HFAI) Voice Terminal (3161) The 10-Button HFAI Voice Terminal (Figure 1) allows you to program and use all the custom features that your communications system pro- vides. It also permits you to answer and talk on announced intercom calls without lifting your handset.
- Page 3 imprinted on the appropriate pieces. Separate instructions follow for each application. Wall support Desk support Base Runner FIGURE 2 Unassembled Desk Stand/Wall Mount DESK STAND ASSEMBLY Break the pieces of the desk stand/wall mount away from the runner. Discard the runner. Find the stand pieces labeled Base and Desk Support.
- Page 4 4 Turn the voice terminal upside down, and position the stand on the voice terminal so that the stand’s mounting slots (Figure 4A) fit just below the voice terminal’s mounting tabs (Figure 4B). Mounting Locking tabs Mounting slots Stand attached to voice terminal (bottom view) FIGURE 4 Attaching the Voice Terminal to the Desk Stand...
- Page 5 Desk support FIGURE 5 10-Button HFAI Voice Terminal Attached to the Desk Stand Check to see that one end of the handset cord is attached to the handset. If it is not, plug it into the handset now. Plug the other end of the handset cord into the jack on the middle front of the voice terminal.
-
Page 6: Wall Mount Assembly
11 To remove the 10-Button HFAI Voice Terminal from the desk stand, set the handset aside, turn the voice terminal upside down, and unplug the modular voice terminal cord. Press down on the locking tab to release the stand, and slide the stand down and away from the voice terminal. - Page 7 Select a mounting space at least as large as the voice terminal. Use the base as a template and mark the four mounting screw locations on the wall. Unpack the hardware kit, which was ordered separately from the voice terminal. Select the proper-sized toggle bolts for your wall thickness.
- Page 8 Insert the top two screws into the base, and partially thread the screws into the toggles. Insert the two remaining screws into the lower mounting holes. Tighten all four screws (Figure 9). Top of base FIGURE 9 Wall Mount Attached to Wall Converting the Voice Terminal for Wall Mounting 1 Remove the number card retainer with a straightened paper clip or similar device, and remove the number card (Figure 10).
- Page 9 2 Remove the screw under the number card, and lift out the handset retainer from the upper housing (Figure 11). Handset retainer screw Handset retainer FIGURE 11 Handset Retainer and Screw Rotate the handset retainer 180 degrees (Figure 12). Handset retainer removed Rotate to Handset retainer...
- Page 10 Handset retainer Handset retainer after rotation Handset retainer Handset screw retainer screw FIGURE 13 Handset Retainer in Wall Mount Position Replace the screw, the number card, and the number card retainer. Plug one end of the modular voice terminal cord into the jack labeled Line on the bottom of the voice terminal.
-
Page 11: Your Voice Terminal
Mounting Mounting tabs slots Voice terminal Wall mount (back view) (top view) Wall mount Jack for handset cord FIGURE 14 Attaching the 10-Button HFAI Voice Terminal to the Wall Mount Check to see that one end of the handset cord is attached to the handset. -
Page 12: Setting The Volume
Volume Test/ Program control switch FIGURE 15 T/P Switch and Volume Control Setting the Volume Use the volume control switch, located on the left side of the voice termi- nal, to set the volume for the ringing, the speaker, and the button clicks (Figure 15). - Page 13 Recessed Button Plastic label openings cover on face sheet plate plate FIGURE 16 Removing the Button Label Sheet Lift the button label sheet off the voice terminal. Identify the buttons by typing or writing the information on the button label sheet. INSERTING THE BUTTON LABEL SHEET Place the button label sheet on the voice terminal so that the holes on the label sheet fit over the buttons.
- Page 14 Handsets for the Hearing Impaired and for Noisy Locations All voice terminals come with a handset that is hearing-aid compatible. Two other types of handsets are also available: The (R6C3) Impaired-Hearing Handset (31753) has an extra amplifier to provide greater volume in the earpiece. A thumbwheel volume control on the handset allows the volume to be turned up or down, as needed.
- Page 15 User’s Card 10-Button Hands-Free Answer on Inercom (HFAI) Voice Terminal Using the Hands-Free Answer on Intercom Feature (See your user’s guide for information on other features.) The Hands-Free Answer on Intercom Voice Terminal allows you to answer intercom calls without lifting your handset. If you lift your handset, you turn off the Hands-Free Answer on Intercom feature and you cannot reactivate it during the call in progress.
