www.sylvania.com
SYLVANIA LEDVANCE
Luminaires Installation Guide
WALL PACK NON-CUTOFF 105W
For warranty coverage, please register at www.sylvania.com/warrantyregistration.
PLEASE READ ALL INSTRUCTIONS BEFORE ATTEMPTING INSTALLATION
• TO PREVENT PERSONAL INJURY OR PRODUCT DAMAGE ONLY LICENSED ELECTRICIANS SHOULD
PROVIDE ALL INSTALLATION SERVICES.
• TO AVOID ELECTRIC SHOCK OR COMPONENT DAMAGE DISCONNECT POWER BEFORE ATTEMPTING
INSTALLATION OR SERVICING.
• THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE NATIONAL ELECTRIC CODE (NEC) AND
ALL APPLICABLE FEDERAL, STATE AND LOCAL ELECTRIC CODES AND SAFETY STANDARDS.
• USE CAUTION WHEN HANDLING THIS PRODUCT DURING OR AFTER OPERATION AS IT MAY BECOME HOT
AND CAUSE BURNS. DISCONNECT PRODUCT AND ALLOW COOLING PRIOR TO SERVICING.
• ANY ALTERATION OR MODIFICATION OF THIS PRODUCT IS EXPRESSLY FORBIDDEN AS IT MAY CAUSE
SERIOUS PERSONAL INJURY, DEATH, PROPERTY DAMAGE AND/OR PRODUCT MALFUNCTION.
• TO PREVENT PRODUCT MALFUNCTION AND / OR ELECTRICAL SHOCK THIS PRODUCT MUST BE
PROPERLY GROUNDED.
• THIS LUMINAIRE IS TO BE WALL MOUNTED ONLY.
• THIS LUMINAIRE IS DESIGNED TO OPERATE IN AMBIENT TEMPERATURES RANGING FROM -40°F TO
+104°F (-40°C TO +40°C).
The Wall Pack luminaires are environmentally
preferable LED alternatives to traditional HID
luminaires, offering up to 77% in energy
savings. Ideal in place of traditional luminaires,
or as new installations, the Wall Pack series is
offered in three wattages/lumen packages for
illuminating building exteriors, outdoor
corridors, walkways, and stairwells.
Advertisement
Summary of Contents for Sylvania LEDVANCE WALL PACK NON-CUTOFF 105W
- Page 1 For warranty coverage, please register at www.sylvania.com/warrantyregistration. PLEASE READ ALL INSTRUCTIONS BEFORE ATTEMPTING INSTALLATION • TO PREVENT PERSONAL INJURY OR PRODUCT DAMAGE ONLY LICENSED ELECTRICIANS SHOULD PROVIDE ALL INSTALLATION SERVICES.
- Page 2 Confidential – for internal use only Competitor Product Comparison SAFETY PRECAUTIONS: IMPORTANT: READ CAREFULLY BEFORE INSTALLING THE FIXTURE. RETAIN FOR FUTURE REFERENCE. GENERAL: Upon receipt of the fixture, thoroughly inspect for any freight damage which should be brought to the attention of the delivery carrier. Front View Side View Top Visor...
- Page 3 Confidential – for internal use only Competitor Product Comparison ADDING AN ACCESSORY(OPTIONAL): Wire Guard Top Visor Group A: (a) #8x32Tx5/16" screw; (b) #8 washer; (c) #8 round flat gasket; (d) #8 hex machine screw nut Group B:#10x24Tx5/16" screw; #10 washer; #10 round flat gasket Adding Wire Guard and Top Visor Accessory (Sold Separately) After step 6 in “Installation”, disconnect the wiring and remove the front housing.
