Page 1 OWNER’S MANUAL OUTLANDER - ENGLISH - OGXE11E1...
Page 2 Use of any other type of diesel fuel can adversely affect the engine. Vehicles in the warranty period: M/T: Manual Transmission All warranty repairs must be carried out by a MITSUBISHI MOTORS Au- A/T: Automatic Transmission thorized Service Point. CVT: Continuously Variable Transmission Vehicles outside the warranty period: Where the vehicle is repaired is at the discretion of the owner.
Page 3 Table of contents Overview General information Locking and unlocking Seats and seat belts Instruments and controls Starting and driving For pleasant driving For emergencies Vehicle care Maintenance Specifications...
Page 4 Overview Instruments and controls E00100105675 1. Active stability control (ASC) OFF switch* p. 4-58 2. Sonar switch* p. 4-66 3. Adaptive Front lighting System (AFS) OFF Switch* p. 3-49 4. Headlamp levelling switch* p. 3-46 5. Combination headlamps and dipper switch p. 3-42 Turn-signal lever p.
Page 5 Overview 1. Combination headlamps and dipper switch p. 3-42 Turn-signal lever p. 3-48 Front fog lamp switch* p. 3-50 Rear fog lamp switch p. 3-51 Headlamp washer switch* p. 3-56 2. Shift paddles* p. 4-27, 4-33, 4-42 3. Instruments p. 3-02 4.
Page 6 Overview 1. Hazard warning flasher switch p. 3-50 2. Digital clock* p. 5-62 Audio system* p. 5-10, 5-24 MITSUBISHI Multi-Communication System* 3. Centre ventilators p. 5-02 4. Supplemental restraint system - airbag (for front passenger’s seat) p. 2-31, 2-35 5. Upper glove box p. 5-88 6.
Page 7 Overview 1. Digital clock* p. 5-62 Audio system* p. 5-10, 5-24 MITSUBISHI Multi-Communication System* 2. Hazard warning flasher switch p. 3-50 3. Built-in cup holder p. 5-91 4. Personal box p. 5-90 5. Bonnet release lever p. 8-03 6. Fuel tank filler door release lever p. 03 7.
Page 8 Overview Interior E00100204086 1. Luggage room lamp p. 5-87 2. Assist grip p. 5-94 Coat hook p. 5-94 3. Room lamp (rear) p. 5-85 4. Adjustable seat belt anchor p. 2-21 Seat belts p. 2-19 5. Lock switch p. 1-41 6.
Page 9 Overview 1. Supplemental restraint system - curtain airbag* p. 2-31, 2-38 2. Bottle holder p. 5-92 3. Sunglasses holder* p. 5-90 4. Sunroof switch* p. 1-43 Map lamp & room lamp (front) p. 5-85, 5-86 5. Head restraints p. 2-14 6.
Page 10 Overview 1. Lock switch p. 1-41 2. Electric remote-controlled outside rear-view mirrors switch p. 4-10 3. Central door lock switch p. 1-28 4. Electric window control switch p. 1-41 5. Adjustable seat belt anchor p. 2-21 Seat belts p. 2-19 6.
Page 11 Overview 1. Sunroof switch* p. 1-43 Map lamp & room lamp (front) p. 5-85, 5-86 2. Sunglasses holder* p. 5-90 3. Bottle holder p. 5-92 4. Supplemental restraint system - curtain airbag p. 2-31, 2-38 5. Cargo area cover p. 5-93 6.
Page 12 Overview Luggage area E00100401478 1. Luggage hook p. 5-94 2. Accessory socket p. 5-84 3. Luggage hook p. 5-94 4. Jack p. 6-08 Tools p. 6-08 5. Luggage hook p. 5-94 6. Luggage hook p. 5-94...
Page 13 Overview Outside (Front) E00100504568 1. Bonnet p. 8-03 2. Windscreen wipers p. 3-51 3. Sunroof* p. 1-43 4. Electric window control p. 1-41 5. Fuel tank filler p. 03 6. Outside rear-view mirror p. 4-10 Side turn-signal lamps* p. 3-48, 8-24, 8-29 7.
Page 14 Overview Outside (Rear) E00100504571 1. Split tailgate p. 1-31 2. Keyless entry system* p. 1-04 Keyless operation system* p. 1-07 Locking and unlocking the doors p. 1-26 3. Size of tyres and wheels p. 9-17 Tyre inflation pressures p. 8-12 Changing tyres p.
Page 15: Table Of Contents
General information Fuel selection...................02 Filling the fuel tank................03 Installation of accessories..............04 Modification/alterations to the electrical or fuel systems....05 Genuine parts...................05 Safety and disposal information for used engine oil......06 Disposal information for used batteries...........06 Auto Stop & Go (AS&G) system*..........06...
Page 16: Fuel Selection
FFV) engine malfunction. For details, please con- fuel affect the engine’s performance and dura- 95 RON or higher, or tact a MITSUBISHI MOTORS Authorized bility. Bio ethanol E 85 Service Point. Poor quality petrol can cause problems such as difficult starting, stalling, engine noise...
Page 17: Filling The Fuel Tank
1- Remove If the tank cap must be replaced, use only 2- Close a MITSUBISHI MOTORS original part. 3. Remove the fuel cap. Fuel tank capacity 2WD: 63 litres 4WD: 60 litres Refueling 1.
Page 18: Installation Of Accessories
Due to large number of accessory and replacement door. parts of different manufactures available in the mar- ket, it is not possible, not only for MITSUBISHI 4. Insert the gun in the tank port as far as it goes. MOTORS, but also for a MITSUBISHI MOTORS...
Page 19: Modification/Alterations To The Electrical Or Fuel Systems
“general operators permit” (an ap- electrical or fuel systems E00200500499 praisal for the part) or through the execution of the MITSUBISHI MOTORS has gone to great lengths E00200400368 part in an officially approved manner of construc- to bring you a superbly crafted automobile offering...
Page 20: Safety And Disposal Information For Used Engine Oil
General information Safety and disposal information Disposal information for used Auto Stop & Go (AS&G) system* for used engine oil batteries E00201500034 This paragraph summarizes the major items of the E00200600155 E00201300032 Auto Stop & Go (AS&G) system such as the char- acteristics, operating procedures, etc.
Page 21 General information Deactivation 2. Place the gearshift lever in the “N” (Neutral) Auto go position. E00201700049 E00201900038 You can deactivate the system by pressing the “Au- Depress the clutch pedal while the gearshift lever is to Stop & Go (AS&G) OFF” switch. Then the “ ” in the “N”...
Page 22 General information Vehicle speed is 3 km/h (2 mph) or higher when coasting on a slope. Mode selection dial is set to the demister po- sition. When the air conditioning is operated by pressing the air conditioning switch. When the preset temperature of the air condi- tioning is changed significantly.
Page 23 Locking and unlocking Keys....................1-02 Electronic immobilizer (Anti-theft starting system).....1-03 Keyless entry system*..............1-04 Keyless operation system*............1-07 Doors....................1-26 Central door locks.................1-28 Dead Lock System*..............1-29 “Child-protection” rear doors............1-31 Split tailgate..................1-31 Inside tailgate release..............1-34 Security alarm system*..............1-35 Electric window control..............1-41 Sunroof*..................1-43...
Page 24: Keys
Locking and unlocking Keys Type 2 NOTE The emergency key fits all locks. The key number is stamped on the tag as in- E00300102373 dicated in the illustration. Type 1 Make a record of the key number and store the key and key number tag in separate pla- The key fits all locks.
Page 25: Electronic Immobilizer (Anti-Theft Starting System)
Point as soon as possible. To obtain a replace- ment or extra spare key, take your vehicle In cases like these, remove the object or and all remaining keys to your MITSUBISHI additional key from the vehicle key. Then MOTORS Authorized Service Point. All the try again to start the engine.
Page 26: Keyless Entry System
Locking and unlocking Keyless entry system* To unlock CAUTION Press the UNLOCK switch (2). All the doors and E00300302418 Press the remote control switch, and all doors and the tailgate will be unlocked. If the doors and tail- Do not modify or add parts to the immo- the tailgate will be locked or unlocked as desired.
Page 27 MOTORS Authorized Service Point. MITSUBISHI MOTORS Authorized Service In a vehicle equipped with the MITSUBISHI Mul- Operation of the Dead Lock System Point. ti-Communication System (MMCS), it is possible A maximum of 8 remote control switches are In a vehicle that has a Dead Lock System, it is pos- to change the setting by means of screen operations.
Page 28 4. Release in sequence the LOCK and UN- LOCK switches within 10 seconds of press- ing the LOCK switch in step 3. 2. With the MITSUBISHI mark facing you, in- sert the cloth covered tip of a straight blade NOTE...
Page 29: Keyless Operation System
A MITSUBISHI MOTORS Authorized Serv- Electromedical device operations could fect implantable cardiac pacemakers or ice Point can replace the battery for you if be affected by radio waves.
Page 30 • Only starting the engine: interior transmit- key use. The battery life is 1 to 3 years, de- pending on usage conditions. When the bat- tery wears out, have it replaced at a MITSUBISHI MOTORS Authorized Service NOTE Point. The keyless operation key uses an ultra-weak Because the keyless operation key continual- electromagnetic wave.
Page 31 Locking and unlocking Operating range for locking and unlocking the If the keyless operation key is within the op- To operate using the keyless operation erating range, even someone not carrying the doors and tailgate function key can lock and unlock the doors and tail- E00306200444 E00305800616 The operating range is about 70 cm from the driv-...
Page 32 For further in- tral door locks, Split tailgate” on pages 1-26, For vehicles equipped with the mirror retrac- formation, please contact your MITSUBISHI 1-28 and 1-31. tor switch, the outside rear-view mirrors auto- MOTORS Authorized Service Point.
Page 33 Point. the vehicle is unlocked. switch is pressed. On vehicles equipped with MITSUBISHI • Disable the operation confirmation func- If the keyless operation function is set to Multi-Communication System (MMCS), tion (blinking of the turn-signal lamps).
Page 34 If you lose one of the keyless operation keys, produces a match, the steering wheel lock is re- E00306600031 contact a MITSUBISHI MOTORS Author- Push the ignition switch and turn it slowly. leased and the ignition switch can be turned.
Page 35 (A/T or CVT) or the gearshift lever (Twin If any of the following warnings are activated, Clutch SST) is in the “P” (PARK) position. please contact a MITSUBISHI MOTORS Author- ized Service Point. CAUTION Do not turn the ignition switch to the “LOCK”...
Page 36 Locking and unlocking Keyless operation key take-out monitoring system Type 1 Type 1 E00308000260 You could be carrying another key- Type 1 less operation key with a different Refer to “Key lock-in prevention sys- Type 2 Type 2 code, or the keyless operation key tem”...
Page 37 LOCK switch, a warn- pletely closed, a warning is issued with the warn- MITSUBISHI MOTORS Authorized Service ing is issued with the warning display and the buz- ing display and the buzzer buzzing for about 3 sec- Point.
Page 38 Locking and unlocking Steering wheel lock Starting CAUTION E00306800192 E00306900441 Never attempt to start the engine by push- To lock Tips for starting ing or pulling the vehicle. Turn the steering wheel until it is locked. Do not operate the starter motor continuous- Do not run the engine at high rpm or ly longer than 10 seconds;...
Page 39 Locking and unlocking On vehicles equipped with A/T or CVT, Using the MIVEC engine (3000 models) On vehicles equipped with Twin Clutch make sure the selector lever is in the “P” SST, make sure the gearshift lever is in the The MIVEC engine automatically switches its in- (PARK) position.
Page 40 Locking and unlocking On vehicles with Twin Clutch SST, when the To operate without using the keyless The glove box can only be locked or un- engine has not been started within about 5 sec- locked with the emergency key. When leav- operation function onds after the diesel preheat indication lamp ing your key at a hotel reception or lending...
Page 41 The engine is stopped, but the audio system and oth- If you lose one of the keyless operation keys, er electrical devices can be operated. contact a MITSUBISHI MOTORS Author- ized Service Point as soon as possible. To obtain a replacement or extra spare key, The engine is running, and all the vehicle’s electri-...
Page 42 Locking and unlocking When turning from “ACC” to “LOCK” To unlock CAUTION 1. [Vehicles with M/T] Turn the emergency key to the “ACC” position While pushing the ignition switch, turn to the while moving the steering wheel slightly right and If the engine is stopped while driving, the “LOCK”...
Page 43 Locking and unlocking NOTE gine is started, but they do not indicate an ab- CAUTION normality. On vehicles equipped with A/T or CVT, the • You may hear operational sounds of the starter will not operate unless the selector lev- If your vehicle is equipped with a turbo- Twin Clutch SST and you may feel vibra- er is in the “P”...
Page 44 Locking and unlocking NOTE 8. Insert the keyless operation key into the emer- WARNING gency key. On vehicles with the Auto Stop & Go (AS&G) system, the starter will not operate Make sure to remove the keyless opera- unless the clutch pedal is fully depressed tion key from the emergency key after (Clutch interlock).
Page 45 Locking and unlocking 6. While pushing the lock release button (A), re- 8. Insert the keyless operation key into the emer- depressing the accelerator pedal, and release move the cover of the ignition switch. gency key. it when the engine starts. NOTE Minor noises may be heard on engine start- up.
Page 46 MITSUBISHI MOTORS Authorized Service E00307700710 Point. To unlock Press the remote control switch, and all doors and On vehicles equipped with MITSUBISHI Press the UNLOCK switch (2). All the doors and the tailgate will be locked or unlocked as desired. It Multi-Communication System (MMCS), the tailgate will be unlocked.
Page 47 MOTORS Authorized Service Point. locked in response. 2. Place the combination headlamps and dipper In a vehicle equipped with the MITSUBISHI Mul- • The indication lamp (3) is dim or does switch in the “OFF” position, and leave the ti-Communication System (MMCS), it is possible not come on.
Page 48: Doors
Never leave children in the vehicle unat- E00309600045 tended. 1. With the MITSUBISHI mark facing you, in- Coin type battery Be careful not to lock the doors while the CR2032 sert the cloth-covered tip of a straight blade key is inside the vehicle.
Page 49 Locking and unlocking NOTE NOTE Ignition switch on reminder system* When locking or unlocking with the key, on- The driver’s door can be opened without us- E00310100372 ly the driver’s door will be locked or unlocked. ing the lock knob by pulling on the inside When the engine was started using the keyless op- To lock or unlock all doors and the tailgate, door handle.
Page 50: Central Door Locks
(A/T or CVT) or gate NOTE the gearshift lever (Twin Clutch SST) position. On vehicles equipped with MITSUBISHI These functions are not activated when the vehi- Using the central door lock switch Multi-Communication System (MMCS), cle is shipped from the factory.
Page 51: Dead Lock System
Locking and unlocking Dead Lock System* 4. Press the switch again within 2 seconds. Driver’s and front passenger’s door lock/unlock switches* The turn-signal lamps will blink three times E00305100185 to show that the Dead Lock System has been The Dead Lock System helps to prevent theft. set.
Page 52 (E) and auto- matic locking. For details, please contact a Tailgate OPEN siwtch MITSUBISHI MOTORS Authorized Service Point. On vehicles equipped with MITSUBISHI Multi-Communication System (MMCS), screen operations can be used to make the ad- justment. Refer to the separate owner’s man- ual for details.
Page 53: Child-Protection" Rear Doors
Split tailgate If you need advice on how to set the Dead E00300900768 E00301401158 Lock System, please contact a MITSUBISHI MOTORS Authorized Service Point. WARNING It is dangerous to drive with the tailgate (upper gate and lower gate) open, since carbon monoxide (CO) gas can enter the cabin.
Page 54 Locking and unlocking 2. Move the lever (A) in the direction of the ar- The tailgate cannot be opened when the bat- row and slowly fold down the lower gate. tery is flat or disconnected. To close 1. Raise the lower gate until it locks properly in position with a click.
Page 55 Locking and unlocking 2. Pull the upper gate grip (B) downward as il- lustrated. Gently shut the upper gate from the outside so that it is completely closed. Al- ways ensure the tailgate is securely closed. NOTE Always close the lower gate before closing the upper gate.
Page 56: Inside Tailgate Release
Locking and unlocking Inside tailgate release To open CAUTION 1. Open the lid (A) inside of the tailgate. E00303400214 The inside tailgate release is designed to provide a Always keep the release lever lid on tail- way to open the tailgate in the case of a discharged gate closed when driving so that your lug- battery.
Page 57: Security Alarm System
For details, (the impact detection function) Have vehicle inspected please contact a MITSUBISHI MOTORS Au- Detect a motion in the vehicle. (the interior MITSUBISHI MOTORS Authorized Service thorized Service Point. intrusion detection function) Point.
Page 58 Locking and unlocking The system preparation time extends from the System cancellation point at which all of the doors and the tailgate are It is possible to cancel the system activation during locked by pressing the LOCK switch on the remote the system preparation mode or the system armed control switch or the keyless operation function to mode.
Page 59 4. After approximately 10 seconds, the buzzer MITSUBISHI MOTORS Authorized Service will make a sound. Keep the windscreen wip- Point. er and washer switch pulled towards you. (If Avoid leaving valuable items inside the vehi- the windscreen wiper and washer switch was...
Page 60 Locking and unlocking NOTE Tailgate LOCK switch* Except for vehicles equipped with the keyless operation The system preparation mode is not activated system when the doors and the tailgate have been locked using a method other than the keyless entry system or the keyless operation func- tion (namely a key, the inside lock knob or the central door lock switch).
Page 61 “ON” or “ACC” position. hicle with the windows slightly open. If you want to register additional remote con- 1. Turn the ignition switch to the “LOCK” posi- trol switches, please contact a MITSUBISHI Cancelling the system tion. MOTORS Authorized Service Point.
Page 62 Locking and unlocking Alarm activation NOTE NOTE E00301900749 During an alarm operation, the alarm is dis- When the ignition switch is turned to the When the system is in the system armed mode, the played on the information screen in the multi- “ON”...
Page 63: Electric Window Control
Locking and unlocking Electric window control Press the switch down for opening the window, Driver’s switch (RHD) and pull up the switch for closing it. E00302200446 The electric windows can only be operated with the ignition switch in the “ON” position. WARNING Before operating the electric window con- trol, make sure that nothing can get trap-...
Page 64 Locking and unlocking To unlock, press it once again. Safety mechanism (driver’s door win- NOTE dow only) The safety mechanism can be activated if the driving conditions or other circumstances E00302500726 If a hand or head is trapped in the closing window, cause the driver’s door window to be subjec- it will lower automatically.
Page 65: Sunroof
Locking and unlocking NOTE Sunroof* To tilt down, press the switch (3). The safety mechanism can be activated if the E00302800282 driving conditions or other circumstances WARNING cause the sunroof to be subjected to a physi- Sunroof cal shock similar to that caused by a trapped The sunroof can only be operated with the ignition Do not put head, hands or anything else hand or head.
Page 66 Locking and unlocking Be sure to close the sunroof completely CAUTION when washing the vehicle or when leaving the vehicle. Be careful that hands are not trapped Be careful, not to put any wax on the weath- when closing the sunshade. erstrip (black rubber) around the sunroof opening.
Page 67 Seats and seat belts Seat....................2-02 Arrangement of seats..............2-03 Seat adjustment................2-05 Front seat..................2-05 Second seat...................2-08 Third seat (7 persons)..............2-10 Head restraints................2-14 Making a luggage room..............2-15 Making a flat seat.................2-17 Seat belts..................2-19 Pregnant women restraint.............2-22 Seat belt pretensioner system and force limiter system....2-22 Child restraint................2-23 Seat belt inspection...............2-31 Supplemental restraint system (SRS) - airbag......2-31...
Page 68 Seats and seat belts Seat E00400101827 1-Front seat 3- Third seat (7 persons) To adjust forward or backward ® p. 2-05 To fold out the underfloor-stowable third seat ® p. 2-10 To recline the seatback ® p. 2-06 To adjust seat height (driver’s seat on- ly) ®...
Page 69: Arrangement Of Seats
Seats and seat belts Arrangement of seats E00400200342 The seats can be arranged as desired to the patterns shown below. 5 persons 7 persons Normal usage 7 persons ® p. 2-10 — Flat seat ® p. 2-17 2-03...
Page 70 Seats and seat belts 5 persons 7 persons To fold down the second seat ® p. 2-15 Making a luggage area To fold down the second seat ® p. 2-15 2-04...
Page 71: Seat Adjustment
Seats and seat belts Seat adjustment Front seat CAUTION E00400300271 E00400400142 To adjust forward or backward Adjust the driver’s seat so that you are comfortable Make sure the seat is adjusted by an and that you can reach the pedals, steering wheel, E00400500462 adult or with adult supervision for cor- switches etc.
Page 72 Seats and seat belts Power type To recline the seatback Power type Adjust the seat by operating the switch as indicated Adjust the seatback angle by operating the switch E00400600580 by the arrows. as indicated by the arrows. Manual type In order to recline the seatback, lean forward slight- ly, pull the seatback lock lever up, and then lean backward to the desired position and release the lev-...
Page 73 Seats and seat belts To adjust seat height (driver’s seat on- NOTE 2- To move the rear of the seat up and down To prevent the battery from discharging, use the power seat while the engine is on. E00400700549 Manual type To adjust the seat height, operate the lever repeated- ly to adjust.
Page 74: Second Seat
Seats and seat belts Heated seats* Second seat CAUTION E00401100742 E00402000399 The heated seats can be operated with the ignition or receive minor burns (red skin, heat blis- switch in the “ON” position. The indication lamp ters, etc.): WARNING (A) will illuminate while the heater is on. •...
Page 75 Seats and seat belts To adjust forward or backward (vehi- To recline the seatback CAUTION cles with second seat slide function) To adjust the seatback, lean forward slightly, slow- ly pull up the lever, then lean backward to the de- Pull the seat adjustment lever and lightly push the A spring is loaded in the reclining mecha- sired position and release the lever.
Page 76: Third Seat (7 Persons)
Seats and seat belts Accessing the underfloor-stowable Third seat (7 persons) WARNING third seat (7 persons) E00402700383 For reasons of safety, whenever passen- E00412600040 To fold out the underfloor-stowable The passenger gets on or off the third seat after fold- gers sit in the third seat, be sure to raise ing down the second seat.
Page 77 Seats and seat belts Fasten the pulled up cover to the seatback 4. Pull the belt (C- black) to release the lock. 6. Raise the head restraints. with the band (A). 5. Tilt the whole of the third seat to the rear. 7.
Page 78 Seats and seat belts To retract 1. Open the tailgate. Refer to “Split tailgate” on page 1-31. 2. Pull up the cover (A) from the rear direction. Fasten the pulled up cover to the seatback with the band (B). WARNING CAUTION When lifting up the third seat, do not put Do not put your hands on the end trim...
Page 79 Seats and seat belts If the third seat is difficult to lock, return it If the third seat is difficult to lock, make sure 7. Return the cover to its position. to its original position. Then push it down that the rear of the third seat is securely while pulling strongly on the belt until the locked to the floor, and then strongly tilt the rear of the third seat makes contact with the...
Page 80: Head Restraints
Seats and seat belts Head restraints To raise the head restraint, move it upward. To low- Installation er the restraint, move it downward while pushing To install the head restraints, first confirm that they E00403301338 the height adjusting knob (A) in the direction of the are facing the correct direction, and then insert arrow.
Page 81: Making A Luggage Room
Seats and seat belts Making a luggage room NOTE On vehicles with a third seat, fold down the E00403400299 second seat to get on or off the third seat. Re- fer to “Accessing the underfloor-stowable WARNING third seat (7 persons)” on page 2-10. The seatbacks can be moved one side at a time.
Page 82 Seats and seat belts Luggage area switch operation* WARNING While the tailgate or a rear door is open, pull the switch (B) for about 1 second or more. When folding the seatbacks forward from behind, an adult should perform the operation, making sure there is no one in the second seat.
Page 83: Making A Flat Seat
Seats and seat belts Making a flat seat E00404300471 By removing the head restraints and fully reclining the seatbacks of the seats, one large flat seat is ach- ieved. WARNING Never drive while there are occupants sit- ting on the flat seat. This can be extreme- ly dangerous.
Page 84 Seats and seat belts (Refer to “Head restraints” on page 2-14 and (Refer to “To adjust forward or backward” 5. The flat seat configuration is now complete. “Cargo area cover” on page 5-93) on page 2-05 and “To recline the seatback” To return the seats to the normal position, re- on page 2-06) verse the procedure above.
Page 85: Seat Belts
Seats and seat belts Seat belts NOTE WARNING You can check if the belt locks by pulling it E00404800636 To protect you and your passengers in the event of forward quickly. No modifications or additions should be an accident, it is most important that the seat belts made by the user which will either pre- be worn correctly while driving.
Page 86 Seats and seat belts Driver’s seat belt warning lamp and The warning lamp goes off and the tone stops after WARNING approximately 90 seconds. display Subsequently, if the seat belt is still not fastened, The seat belts must not be twisted when E00409800758 the warning lamp and tone will be activated to re- worn.
Page 87 Seats and seat belts Adjustable seat belt anchor (front Second and third seat belt storage To store the second seat belt buckles seats) E00405300205 E00412100016 Store the second seat belts (excluding the centre When the second seat belts are not in use, insert the E00405000329 seat belt) and third seat belts as shown in the illus- buckles into the seat cushion slits.
Page 88: Pregnant Women Restraint
After the pretensioner seat WARNING belts have been activated, we recommend you have it replaced by a MITSUBISHI To obtain the best results from your pre- MOTORS Authorized Service Point. tensioner seat belt, make sure you have ad-...
Page 89: Child Restraint
Seats and seat belts Child restraint Caution for installing the child re- Use rearward facing child restraints in the rear seat or turn off the front passenger’s airbag ON-OFF straint on vehicles with a front passen- E00406401587 switch. (Refer to “To turn an airbag off” on page When transporting children in your vehicle, some ger airbag 2-34).
Page 90 Seats and seat belts The child restraint system should be appropri- WARNING ate for the child’s weight and height and prop- erly fit in the vehicle. For a higher degree of When the child restraint system is not in safety: THE CHILD RESTRAINT SYSTEM use, keep your child restraint system se- SHOULD BE INSTALLED IN THE REAR cured with the seat belt or remove it from...
Page 91 IUF- Suitable for ISOFIX forward child restraint systems of universal category approved for use in the mass group. IL- Suitable for particular ISOFIX child restraint systems given in the following list (MITSUBISHI MOTORS genuine parts). X- ISOFIX position not suitable for ISOFIX child restraint systems in this mass group.
Page 92 Seats and seat belts NOTE MITSUBISHI MOTORS Europe B.V. reserves the right to changes without any prior announcement. For further information, please contact a MITSUBISHI MOTORS Authorized Service Point. 2-26...
Page 93 U- Suitable for “universal” category restraints approved for use in this mass group. L- Suitable for particular child restraint systems given in the following list (MITSUBISHI MOTORS genuine parts.). X- Seat position not suitable for children in this mass group.
Page 94 Seats and seat belts NOTE There is no applicable MITSUBISHI MOTORS Genuine Parts to the Mass Group “0-Up to 10 kg”. MITSUBISHI MOTORS Europe B.V. reserves the right to changes without any prior announcement. For further information, please contact a MITSUBISHI MOTORS Authorized Service Point.
Page 95 Seats and seat belts Installing a child restraint system to Tether anchorage locations It is not necessary to retain the child restraint sys- tem using the vehicle’s seat belts. There are 3 child restraint anchorage points located the lower anchorage (ISOFIX child re- on the back of the second seatbacks.
Page 96 Seats and seat belts 2. Push the child restraint system’s connectors 4. Latch the tether strap hook (F) of the child Installing a child restraint system to a (A) into the slit (B) in accordance with the in- seat to the tether anchorage bar (G) and tight- 3-point type seat belt (with emergency structions provided by the child restraint sys- en the top tether strap hook so it is securely...
Page 97: Seat Belt Inspection
MITSUBISHI MOTORS Authorized against head injuries in certain moderate-to-severe Service Point.
Page 98 Seats and seat belts How the Supplemental Restraint Sys- The airbags deployment produces a sudden, loud WARNING noise, and releases some smoke and powder, but tem works these conditions are not injurious, and do not indi- Place all infants and small children in the E00407301381 cate a fire in the vehicle.
Page 99 Seats and seat belts Caution for installing the child re- WARNING straint on vehicles with a front passen- A REARWARD FACING CHILD RE- ger airbag STRAINT must NOT be used in the front E00408800038 passenger seat if the front passenger’s air- The label shown here is attached on vehicles with a bag has not been deactivated.
Page 100 We E00412300050 E00410200130 recommend you to have the system in- The front passenger’s airbag OFF indication lamp spected by a MITSUBISHI MOTORS is located in the instrument panel. Authorized Service Point. WARNING • If the indication lamp remains on when the front passenger’s airbag ON-...
Page 101 Seats and seat belts 3. Insert the key into the ignition switch, and The front passenger’s airbag deploys at the same Deployment of front airbags turn the ignition to the “ON” position. The time as the driver’s airbag, even if the passenger E00407501530 front passenger’s airbag OFF indication seat is not occupied, and inflates at two different...
Page 102 Seats and seat belts Because frontal collisions can easily move you out Examples of some typical conditions are shown in The front airbags ARE NOT DESIGNED TO DE- of position, it is important to always properly wear the illustration. PLOY when... your seat belts.
Page 103 They must cupant if the airbag inflates. promptly be replaced, and we recom- mend you to have the entire airbag sys- inspected MITSUBISHI MOTORS Authorized Service Point. Side airbag system* E00407600303 The side airbags (A) are contained in the driver and front passenger seatbacks.
Page 104 Seats and seat belts The label shown here is attached to the seatbacks Deployment of side airbags and cur- The side airbags and curtain airbags MAY NOT with a side airbag. DEPLOY when… tain airbags With certain types of side collisions, the vehicle’s E00407701444 body structure is designed to absorb the shock to The side airbags and curtain airbags ARE DE-...
Page 105 Seats and seat belts 3- Collision with a utility pole, tree or other nar- The side airbags and curtain airbags ARE NOT WARNING row object DESIGNED TO DEPLOY when… The side airbags and curtain airbags are not de- The side airbags and curtain airbags in- signed to deploy in conditions where they cannot flate with great force.
Page 106 We recommend work around and on the stays on. side airbags and curtain airbags system The SRS warning lamp is shared by the Supplemen- to be done by a MITSUBISHI MOTORS tal Restraint System (SRS) and the seat belt preten- Authorized Service Point. sioner system.
Page 107 SRS inspected by a MITSUBISHI MOTORS Authorized Service Point. We recommend any maintenance per- formed on or near the components of the SRS to be performed by a MITSUBISHI NOTE MOTORS Authorized Service Point. When you transfer ownership of the vehicle...
Page 109 Instruments and controls Instruments...................3-02 Multi-information display.............3-03 Indication lamp, warning lamp, and information screen display list.................3-25 Indication lamps................3-37 Warning lamps................3-38 Information screen display............3-39 Combination headlamps and dipper switch........3-42 Headlamp levelling...............3-46 Turn-signal lever................3-48 Adaptive Front lighting System (AFS)*........3-48 Hazard warning flasher switch.............3-50 Fog lamp switch................3-50 Wiper and washer switch..............3-51 Headlamp washer switch*............3-56...
Page 110: Instruments
Instruments and controls Instruments Tachometer NOTE E00500301064 You can adjust to 8 different levels for when E00500101222 The tachometer indicates the engine speed (r/min). the position lamps are illuminated and 8 for The tachometer helps you to obtain more economi- when they are not.
Page 111 Instruments and controls Multi-information display E00519900825 [Except for vehicles equipped with Twin Clutch SST] Always stop the vehicle in a safe place before operating. The following information is included on the multi-information display: warnings, odometer, tripmeter, service reminder, engine coolant temperature, fuel remain- ing, outside temperature, selector lever position, 4WD operation status, average and momentary fuel consumption, driving range, average speed and meter illumination.
Page 112 Instruments and controls [For vehicles equipped with Twin Clutch SST] Always stop the vehicle in a safe place before operating. The following information is included on the multi-information display: warnings, odometer, tripmeter, service reminder, engine coolant temperature, fuel remain- ing, outside temperature, Twin Clutch SST control mode, 4WD operation status, gearshift lever position, average and momentary fuel consumption, driving range, average speed, and meter illumination.
Page 113 Instruments and controls NOTE The fuel units, temperature units, display language, and other settings can be changed. Refer to “Changing the function settings (when the ignition switch is “ON”)” on page 3-17. The display screen is different depending on whether the ignition switch is “OFF” or “ON”. Refer to “Information screen (when the ignition switch is “OFF“)”...
Page 114 Instruments and controls Multi-information meter switch This mark is also displayed if there is an- Information screen (when the ignition other warning other than the one dis- E00520000679 switch is “OFF“) Each time the multi-information meter switch is op- played. When the cause of the warning E00520200684 erated, a sound is emitted and the multi-informa- display is eliminated, the...
Page 115 Instruments and controls Odometer/Tripmeter If tripmeter is displayed, only tripmeter Both tripmeters can count up to will be reset. 9999.9 km (9999.9 miles). E00521201620 Each time you lightly press the multi-information When a tripmeter goes past 9999.9 km meter switch, the display screen switches. (9999.9 miles), it returns to 0.0 km Type 1 (0.0 miles).
Page 116 Instruments and controls Refer to “Warning display list (when the ignition If you press the multi-information meter switch, Refer to “Information screen (when the ignition switch is “OFF”)” on page 3-27. the display screen switches to the screen that was switch is “OFF“)”...
Page 117 Instruments and controls Information screen (when the ignition Refer to “Warning display list (when the ignition Type 1 switch is “ON”)” on page 3-29. switch is turned from “OFF” to “ON”) E00520700735 When the ignition switch is turned to the “ON” po- Type 1 Type 2 sition, the display screen switches in the following...
Page 118 Instruments and controls When the cause of the warning display Information screen (when the ignition 6- Average speed display, average fuel consump- tion display, momentary fuel consumption is eliminated, the mark goes out auto- switch is “ON”) display (Type 1) matically.
Page 119 Instruments and controls Odometer/Tripmeter Engine coolant temperature Refuel as soon as possible. Type 1 E00521201095 display E00521400625 Type 1 Type 2 This indicates the engine coolant temper- Type 1 Type 2 ature. Type 2 If the coolant becomes hot, “ ” will blink.
Page 120 Instruments and controls The display setting can be changed to the pre- When the ignition switch is switched from Average fuel consumption display ferred units (km or miles). “ACC” or “LOCK” to “ON”, the mode set- E00521700758 This displays the average fuel consumption from Refer to “Changing the function settings ting is automatically switched from manual the last reset to the present time.
Page 121 Instruments and controls When the ignition switch is switched from The memory of the auto reset mode or man- Be conscious that when maintaining the momenta- “ACC” or “LOCK” to “ON”, the mode set- ual reset mode for the average fuel consump- ry fuel consumption above the average fuel con- ting is automatically switched from manual tion display is erased if the battery is discon-...
Page 122 Instruments and controls Interrupt display screen (when the ig- If you press the multi-information meter switch, Other interrupt displays the display screen switches to the screen that was The operation status of each system is displayed on nition switch is “ON”) the information screen.
Page 123 Instruments and controls Twin Clutch SST control If fuel is added with the ignition switch in When the fuel is reduced further to about 5 litres, the “ON” position, the fuel gauge may incor- the information screen switches to the fuel remain- mode display screen* rectly indicate the fuel level.
Page 124 At that time, when the ignition switch is To modify the display settings, have it adjus- switched from “OFF” to “ON”, the warning ted at a MITSUBISHI MOTORS Authorized display is displayed for a few seconds on the Service Point.
Page 125 OFF. tion will be displayed. If you accidentally reset the display, we rec- ommend you to consult a MITSUBISHI MOTORS Authorized Service Point. Changing the function settings (when Type 1 the ignition switch is “ON”)
Page 126 Instruments and controls 4. Select the item to change on the menu screen 1. Press and hold the multi-information meter CAUTION and change to the desired setting. Refer to switch for about 2 seconds or more to switch the following items for further details on the from the setting mode screen to the menu For safety, stop the vehicle before operat- operation methods.
Page 127 Instruments and controls Manual reset mode The initial (default) setting is “Auto reset 3. Press and hold the multi-information meter mode”. switch for about 2 seconds or more to dis- When the average fuel consumption and aver- play “AVG UNIT” (fuel consumption dis- age speed are being displayed, if you hold play unit setting).
Page 128 Instruments and controls The distance and speed units are also switched in 2. Lightly press the multi-information meter 1. Press and hold the multi-information meter the following combinations to match the selected switch for about 2 seconds or more to switch switch to select “...
Page 129: Multi-Information Display
JAPA- switch to switch in sequence from A (lan- E00523300442 The language used in MITSUBISHI Multi-Commu- NESE → ENGLISH → GERMAN → guage cooperation enabled) → M (language nication System (MMCS) (if so equipped) or the FRENCH →...
Page 130 Instruments and controls Operation sound setting NOTE 2. Lightly press the multi-information meter switch to select “ALARM” (rest time setting). E00523400573 The memory of the operation sound setting You can turn off the operation sounds of the multi- is erased if the battery is disconnected, and it information meter switch and daytime dipper button.
Page 131 Instruments and controls 4. Lightly press the multi-information meter 2. Lightly press the multi-information meter 1. Press and hold the multi-information meter switch to select the time until the display. switch for about 2 seconds or more to switch switch to select (changing the turn-sig- 5.
Page 132 Instruments and controls 1. Press and hold the multi-information meter • Average fuel consumption and average switch for about 2 seconds or more to switch speed reset mode: A (Auto reset) from the setting mode screen to the menu • Fuel consumption display unit: L/100 km screen.
Page 133: Indication Lamp, Warning Lamp, And Information Screen Display List
Instruments and controls Indication lamp, warning lamp, and information screen display list E00523700013 Indication and warning lamp list E00523800694 1- Adaptive Front lighting System (AFS) OFF indication lamp* ® p. 3-37, 11- Seat belt warning lamp ® p. 2-20 12- Supplement Restraint System (SRS) warning lamp ® p. 2-40 3-49 2- Position lamp indication lamp ®...
Page 134 • An extremely strong electromagnetic wave is received from a source such as an illegal radio set, a spark from a wire, or a radar station. • Abnormal voltage or a static electricity discharge is generated by the operation of installed electrical equipment (including after-market parts). If the warning display appears many times, we recommend you to consult a MITSUBISHI MOTORS Authorized Service Point. 3-26...
Page 135 Instruments and controls Warning display list (when the ignition switch is “OFF”) E00524000710 Screen type 1 Screen type 2 Cause Solution (Reference) You have forgotten to turn off the lamps. Refer to “Lamps (headlamps, fog lamp, etc.) auto-cut- out function” on page 3-43. The security alarm system is operating.
Page 136 Instruments and controls Screen type 1 Screen type 2 Cause Solution (Reference) There is a fault in the keyless operation system. Refer to “Keyless operation system” on page 1-07. 3-28...
Page 137 Instruments and controls Warning display list (when the ignition switch is “ON”) E00524100795 Screen type 1 Screen type 2 Cause Solution (Reference) There is a fault in the keyless operation system. Refer to “Keyless operation system” on page 1-07. 3-29...
Page 138 The brake fluid level in the reservoir has fallen Immediately stop the vehicle in a safe place. to a low level. We recommend you to consult a MITSUBISHI There is a fault in the brake system. MOTORS Authorized Service Point.
Page 139 2-20. There is a fault in the fuel system. We recommend you to consult a MITSUBISHI MOTORS Authorized Service Point. You are driving with the parking brake still ap- Release the parking brake. Refer to “Brake warn- plied.
Page 140 Cause Solution (Reference) There is a fault in the charging system. Immediately stop the vehicle in a safe place. We recommend you to consult a MITSUBISHI MOTORS Authorized Service Point. Refer to “Charge warning display” on page 3-39. There is a fault in the SRS airbag or the preten- We recommend you to have it checked.
Page 141 The electronically controlled 4WD system is hot. Refer to “Electronically controlled 4WD system” on page 4-46. Problem with one of the systems without a spe- We recommend you to consult a MITSUBISHI cific message. MOTORS Authorized Service Point. The fuel additives are running low.
Page 142 On vehicles equipped with 4N14 engine, imme- creased excessively. diately have your vehicle checked by a MITSUBISHI MOTORS Authorized Service Point. Refer to “Engine oil level warning display” on page 3-41. More than specified limit water has accumula- On vehicles equipped with 4HK engine, stop ted in the fuel filter.
Page 143 Instruments and controls Other interrupt displays (when the ignition switch is “ON”) E00524200611 The operation status of each system is displayed on the information screen. Refer to the appropriate page for the system for further details. Screen type 1 Screen type 2 System operation status Reference When “2WD”...
Page 144 Instruments and controls Screen type 1 Screen type 2 Solution We recommend you to have it checked. Refer to “Service reminder” on page 3-16. The setting for rest interval can be changed. Screen type 1 Screen type 2 Solution Stop the vehicle in a safe place, turn off the engine, and take a rest. Use this display as rough guide for taking rests during a long drive.
Page 145: Indication Lamps
Instruments and controls Indication lamps Front fog lamp indication NOTE lamp* If the engine is cold, the diesel pre- E00501600100 heat indication lamp is on for a lon- E00501900350 Turn-signal indication lamps/ This lamp illuminates while the front ger time. Hazard warning indication fog lamps are on.
Page 146: Warning Lamps
Instruments and controls Warning lamps Check engine warning lamp CAUTION E00502601553 E00502400147 This lamp is a part of an onboard diag- • The brake warning lamp Brake warning lamp nostic system which monitors the emis- does not illuminate when sions, engine control system or A/T con- E00502502067 the parking brake is applied This lamp illuminates when the ignition...
Page 147: Information Screen Display
Im- Type 1 the system inspected by a mediately park your vehicle in MITSUBISHI MOTORS Au- a safe place and we recommend thorized Service Point as soon you to have it checked. as possible. Accelerator pedal...
Page 148 The vehicle should be brought to a halt in sult a MITSUBISHI MOTORS Authorized the following manner when brake per- Service Point. formance has deteriorated.
Page 149 Instruments and controls Charge warning display Oil pressure warning display Engine oil level warning display* E00524800242 E00524900256 E00526700102 Type 1 Type 1 Type 1 Type 2 Type 2 Type 2 If there is a fault with the charging system, the warn- If the engine oil pressure drops while the engine is On vehicles equipped with 4HK engine, when the ing display is displayed on the information screen...
Page 150: Combination Headlamps And Dipper Switch
On vehicles equipped with 4N14 engine, im- Headlamps and other lamps go on Headlamps ediately have your vehicle checked by a MITSUBISHI MOTORS Authorized Service Type 2 NOTE Point. Rotate the switch to turn on the lamps.
Page 151 The daytime running lamp can be deactivated. ity of the automatic on/off control can be ad- For further information, we recommend you justed. For further information, please con- to consult a MITSUBISHI MOTORS Author- tact your MITSUBISHI MOTORS Author- ized Service Point. ized Service Point.
Page 152 (The warning is also displayed on the For further information, we recommend you multi-information display.) to consult a MITSUBISHI MOTORS Author- The buzzer stops in the following manner. ized Service Point. • Turn the lamp switch to the “OFF” posi- On vehicles equipped with MITSUBISHI tion.
Page 153 For further information, please contact your MITSUBISHI MOTORS Author- ized Service Point. 4. The headlamps will come on in the low- On vehicles equipped with MITSUBISHI beam setting for about 30 seconds. After the NOTE Multi-Communication System (MMCS), headlamps go off, the headlamps can be...
Page 154: Headlamp Levelling
• The coming home light function can be deactivated. For further information, please contact your MITSUBISHI MOTORS Author- ized Service Point. On vehicles equipped with MITSUBISHI Multi-Communication System (MMCS), screen operations can be used to make the adjustment. Refer to the separate own- er’s manual for details.
Page 155 Instruments and controls Headlamp automatic levelling system warning dis- : Full luggage loading Switch position 0- Driver only/Driver + 1 front play passenger Switch position 0- Driver only/Driver + 1 front Switch position 1- 5 passengers (including driv- passenger Type 1 Switch position 1- Driver + 1 front passenger + Switch position 2- 5 passengers (including driv- 2 passengers on third seat...
Page 156: Turn-Signal Lever
For further information, we recommend matically come on and illuminate the road in the di- you to consult a MITSUBISHI MOTORS rection in which the vehicle is being turned, there- Authorized Service Point.
Page 157: Adaptive Front Lighting System (Afs)
When the ignition switch is turned off, the sta- However, the lamps can be set before driving you to consult a MITSUBISHI MOTORS tus of the “AFS OFF” switch is held in mem- to illuminate with just a small amount of steer- Authorized Service Point.
Page 158: Hazard Warning Flasher Switch
Instruments and controls NOTE Hazard warning flasher switch Fog lamp switch If the “AFS OFF” indication lamp flashes E00506600772 E00506700034 Front fog lamp switch* Use the hazard warning flasher switch when the ve- while you are driving, stop the vehicle in a hicle has to be parked on the road for any emergency.
Page 159: Wiper And Washer Switch
Instruments and controls In case of vehicles with Daytime Running Turn the knob once in the “ON” direction to turn Wiper and washer switch Lamp, the front fog lamps can be operated on the front fog lamps. Turn the knob once more in E00507101218 even if the lamp switch is set to the “OFF”...
Page 160 If the blades are frozen to the windscreen or rear For further information, we recommend you Slow window, do not operate the wipers until the ice has to consult a MITSUBISHI MOTORS Author- melted and the blades are freed, otherwise the wip- Fast ized Service Point.
Page 161 Instruments and controls Have the vehicle checked at a MITSUBISHI MIST- Misting function CAUTION MOTORS Authorized Service Point. The wipers will operate once. • When the wipers operate at a constant in- With the ignition switch in the “ON” posi- OFF- terval despite changes in the extent of rain.
Page 162 For further information, we recom- When the wipers are not in operation or in intermit- mend you to consult a MITSUBISHI tent operation, by pulling the lever towards you, MOTORS Authorized Service Point.
Page 163 For further information, we recommend you - The wiper operates continuously about 6 seconds later. to consult a MITSUBISHI MOTORS Author- for several seconds then operates • Vehicles for Russia, Kazakhstan and Uk- ized Service Point.
Page 164: Headlamp Washer Switch
Instruments and controls Headlamp washer switch* Precautions to observe when using wip- Wiper de-icer switch* ers and washers E00507800247 E00507700129 The headlamp washer can be operated with the ig- The rear window demister switch can be operated E00510000025 nition switch in the “ON” or “ACC” position and If the moving wipers become blocked by ice when the engine is running.
Page 165: Rear Window Demister Switch
Instruments and controls Rear window demister switch When cleaning the inside of the rear win- Horn switch dow, use a soft cloth and wipe gently along E00507901072 E00508000318 the heater wires, being careful not to damage The rear window demister switch can be operated Press the steering wheel on or around the “...
Page 167 Starting and driving Economical driving...............4-02 Brake assist system...............4-54 Driving, alcohol and drugs............4-02 Emergency stop signal system............4-54 Safe driving techniques..............4-03 Anti-lock brake system (ABS).............4-55 Running-in recommendations............4-04 Power steering system..............4-57 Parking brake................4-07 Active stability control (ASC)*............4-58 Parking..................4-08 Cruise control*................4-60 Steering wheel height adjustment..........4-09 Reversing sensor system*.............4-65 Inside rear-view mirror..............4-09 Rear-view camera*...............4-68...
Page 168: Economical Driving
Starting and driving Economical driving Speed Driving, alcohol and drugs At higher vehicle speed, more fuel is consumed. E00600100789 E00600200070 For economical driving, there are some technical re- Drunk driving is one of the most frequent causes of Avoid driving at full speed. Even a slight release of quirements that have to be met.
Page 169: Safe Driving Techniques
Starting and driving Safe driving techniques Carrying children in the vehicle Never leave your vehicle unattended with the E00600300446 Driving safety and protection against injury cannot key and children inside the vehicle. Children be fully ensured. However, we recommend that may play with the driving controls and this you pay extra attention to the following: could lead to an accident.
Page 170: Running-In Recommendations
Starting and driving Running-in recommendations E00600402193 During the running-in period for the first 1,000 km (620 miles), it is advisable to drive your new vehicle using the following precautions as a guideline to aid long life as well as future economy and performance. Do not race the engine at high speeds.
Page 171 Starting and driving Vehicles with A/T Shift point Speed limit 15 km/h (9 mph) gear 50 km/h (30 mph) gear 85 km/h (53 mph) gear 120 km/h (74 mph) gear gear 130 km/h (81 mph) 130 km/h (81 mph) gear Vehicles with CVT Shift point Speed limit...
Page 172 Starting and driving Vehicles with Twin Clutch SST Shift point Speed limit In sports mode “D” drive operation 20 km/h (12 mph) position 45 km/h (28 mph) position 70 km/h (43 mph) position 95 km/h (59 mph) position position 110 km/h (68 mph) 130 km/h (81 mph) position 4-06...
Page 173: Parking Brake
Starting and driving Parking brake NOTE CAUTION Apply sufficient force to the parking brake E00600501634 To park the vehicle, first bring it to a complete lever to hold the vehicle stationary after the Before driving, be sure that the parking stop, fully engage the parking brake.
Page 174: Parking
Starting and driving Parking NOTE CAUTION If your vehicle is equipped with A/T, CVT E00600601358 To park the vehicle, fully engage the parking or Twin Clutch SST, be sure to apply the park- If the brake warning lamp does not extin- brake, and then move the gearshift lever to 1 ing brake before moving selector lever (A/T guish when the parking brake is fully re-...
Page 175: Steering Wheel Height Adjustment
Starting and driving Where you park Steering wheel height adjustment Inside rear-view mirror E00600700352 E00600800366 1. Release the tilt lock lever while holding the Adjust the rear-view mirror only after making any WARNING steering wheel up. seat adjustments so you have a clear view to the 2.
Page 176: Outside Rear-View Mirrors
Starting and driving To reduce the glare Outside rear-view mirrors 1. Place the lever (A) to the same side as the mir- ror whose adjustment is desired. The lever (A) at the bottom of the mirror can be E00600900628 To adjust the mirror position used to adjust the mirror to reduce the glare from the headlamps of vehicles behind you during night E00601000479...
Page 177 Starting and driving After placing the ignition switch in the “LOCK” po- If you move a mirror by hand or it moves af- CAUTION sition, it is possible to retract and extend the mir- ter hitting a person or object, you may not be rors using the mirror retractor switch for about 30 able to return it to its original position using Do not drive the vehicle with the mirror...
Page 178: Ignition Switch
Ignition switch 20 minutes. Functions can be modified as stated below. E00601401630 [For vehicles equipped with keyless operation Consult a MITSUBISHI MOTORS Author- system] ized Service Point. For information on operations for vehicles equip- On vehicles equipped with MITSUBISHI ped with the keyless operation system, refer to...
Page 179 For details, we recommend you to con- lector lever (A/T or CVT) or gearshift lever (Twin ted, release the key and it will automatically return sult a MITSUBISHI MOTORS Author- Clutch SST) to the “P” (PARK) position, and then to the “ON” position.
Page 180: Steering Wheel Lock
Starting and driving Steering wheel lock Starting and stopping the engine CAUTION E00601500429 E00620600256 [For vehicles equipped with keyless operation Do not turn the key to the “START” posi- Tips for starting system] tion while the engine is running. Doing so For information on operations for vehicles equip- Do not operate the starter motor continuous- could damage the starter motor.
Page 181 Starting and driving 7. Turn the ignition key to the “START” posi- CAUTION [Except for vehicles equipped with keyless oper- tion without depressing the accelerator pedal, ation system] and release it when the engine starts. Never attempt to start the engine by push- The starting procedure is as follows: ing or pulling the vehicle.
Page 182 Starting and driving 5. On vehicles equipped with M/T, place the 7. Turn the ignition key to the “START” posi- NOTE gearshift lever in the “N” (Neutral) position. tion without depressing the accelerator pedal, For diesel-powered vehicles, if the tempera- On vehicles equipped with Twin Clutch and release it when the engine starts.
Page 183: Diesel Particulate Filter (Dpf)
Under certain driving conditions, howev- If the DPF warning display subsequently stays on, er, the DPF is not able to burn away all of the trap- contact a MITSUBISHI MOTORS Authorized Serv- Type 1 ped PM and, as a result, an excessive amount of ice Point.
Page 184: Turbocharger Operation
DPF warning display and check engine warn- 4- Turbo fin ing lamp illuminate. Have the system inspected at a 5- Turbine MITSUBISHI MOTORS Authorized Service Point. 6- Exhaust gas CAUTION Continuing to drive with the DPF warn- ing display and check engine warning lamp illuminating could result in engine trouble and DPF damage.
Page 185: Auto Stop & Go (As&G) System
Starting and driving Auto Stop & Go (AS&G) system* While depressing the brake pedal, fully de- NOTE press the clutch pedal and place the gearshift The brake booster becomes inoperative and E00627400064 lever in the “N” (Neutral) position. The Auto Stop & Go (AS&G) system automatical- the pedal effort will increase when the en- ly stops and restarts the engine without operating gine is stopped automatically.
Page 186 Starting and driving gine will not stop automatically even if the ve- • Check engine warning lamp is illumina- CAUTION hicle is stopped. ted or the “ ” display/indicator is blinking • Driver’s seat belt is not fastened If the Auto Stop & Go (AS&G) system oper- •...
Page 187 Starting and driving Automatically restarting the engine NOTE CAUTION E00627600079 If the “Auto Stop & Go (AS&G) OFF” Depress the clutch pedal while the gearshift lever is switch is pressed to deactivate the Auto Stop In the following cases, the engine will re- in the “N”...
Page 188: Manual Transmission
If it is hard to shift into 1 , depress the & Go (AS&G) system is malfunctioning and will clutch pedal again; the shift will then be eas- not operate. ier to make. We recommend you to consult a MITSUBISHI MOTORS Authorized Service Point. 4-22...
Page 189 Starting and driving NOTE CAUTION Except for vehicles for Russia, Kazakhstan and Ukraine, the gearshift indicator shows rec- Do not pull up the pull-ring (A) when mov- ommended gearshift points for fuel-efficient ing the gearshift lever to any position oth- driving.
Page 190 Starting and driving Possible driving speed E00610801337 Avoid shifting down at high speed, as this may cause excessive engine speed (the tachometer needle into the red zone) and damage the engine. Petrol-powered vehicles Shift point Speed limit gear 50 km/h (30 mph) 90 km/h (56 mph) gear gear...
Page 191: Automatic Transmission Invecs-Ii Sports Mode 6A/T (Intelligent & Innovative Vehicle Electronic Control System Ii)
Immediately have your vehicle checked by electronic control system. While depressing the brake pedal, move the a MITSUBISHI MOTORS Authorized Service selector lever through the gate. Point. Selector lever operation If you need to move the vehicle, shift the selector Move the selector lever through the gate.
Page 192 Starting and driving 3. Insert a straight blade (or minus) screwdriver 6. Insert a straight blade (or minus) screwdriver Selector lever positions (Main gate) with a cloth over its tip into notch (A) or the in the shiftlock release hole (B). Shift the se- E00603800569 cover.
Page 193 Starting and driving NOTE WARNING CAUTION If your vehicle is equipped with shift pad- dles, you can shift into sports mode with Always keep your right foot on the brake Upward shifts do not take place automat- shift paddles when the selector lever is in the pedal when shifting into or out of “N”...
Page 194 Starting and driving When driving away on a slippery road, push When a malfunction occurs in the A/T CAUTION the selector lever forward into the “+ (SHIFT E00615100208 UP)” position. This causes the transmission If malfunction occurs in the A/T while Type 1 to shift into the 2 gear which is better for...
Page 195 Starting and driving Operation of the A/T When travelling down steep grades, the computer CAUTION may automatically select a lower gear. This func- E00604200586 tion assists engine braking efforts, reducing the Do not race the engine with brake pedal need for using the service brakes. CAUTION pressed when the vehicle is stationary.
Page 196: Automatic Transmission Invecs-Iii Sports Mode 6Cvt (Intelligent & Innovative Vehicle Electronic Control System Iii)
Starting and driving NOTE Automatic transmission The selector lever (A) has 2 gates; the main gate (B) and the manual gate (C). On a slope, be sure to apply the parking INVECS-III Sports Mode 6CVT brake before moving the selector lever to the (Intelligent &...
Page 197 5. Turn the ignition switch to the “ACC” posi- tioning. Immediately have your vehicle checked by tion. a MITSUBISHI MOTORS Authorized Service Move the selector lever through the gate. Point. NOTE If you need to move the vehicle, shift the selector For vehicles with the keyless operation sys- lever as follows.
Page 198 Starting and driving 6. Insert a straight blade (or minus) screwdriver 5. Shift the selector lever to the “N” (NEU- Selector lever positions (Main gate) in the shiftlock release hole (B). Shift the se- TRAL) position while pressing the shift-lock E00602400210 lector lever to the “N”...
Page 199 Starting and driving NOTE WARNING CAUTION If your vehicle is equipped with shift pad- dles, you can shift into sports mode with Always keep your right foot on the brake Upward shifts do not take place automat- shift paddles when the selector lever is in the pedal when shifting into or out of “N”...
Page 200 Starting and driving Sports mode display Type 2 CAUTION E00612200282 In sports mode, the currently selected position is dis- this case, take one of the following proce- played on the multi-information display. dures. • Slow down your vehicle. Type 1 Type 2 •...
Page 201 Starting and driving Operation of the CVT DRIVING DOWNHILL CAUTION When travelling down steep grades, the computer E00602600267 may automatically select a lower shift position. Do not race the engine with brake pedal This function assists engine braking efforts, reduc- CAUTION pressed when the vehicle is stationary.
Page 202: Twin Clutch Sst (Sport Shift Transmission)
Starting and driving NOTE Twin Clutch SST The gearshift lever (A) has 2 gates; the main shift gate (B) and the manual shift gate (C). On a slope, be sure to apply the parking (Sport Shift Transmission)* brake before moving the selector lever to the E00620900057 “P”...
Page 203 Starting and driving WARNING Always depress the brake pedal when shifting the gearshift lever into the other position from the “P” (PARK) or “N” (NEUTRAL) position. Never put your foot on the accelerator ped- al while shifting the gearshift lever from the “P”...
Page 204 To correct this situa- MITSUBISHI MOTORS Authorized Service Point tion, the following procedure must be performed. as soon as possible.
Page 205 Starting and driving NOTE NOTE WARNING When the engine is cold, upshifts occur at a When continuously driving on closed circuit higher vehicle speed than when the engine is tracks or at other locations where the engine Never move the gearshift lever to the “N” warm.
Page 206 Starting and driving Twin Clutch SST control mode switch NOTE Manual shift E00621400176 If the Twin Clutch SST control mode switch E00621600178 When the ignition switch is set to the “ON” posi- Using the gearshift lever (A) or the shift paddles is continuously pushed after a control mode tion, operate the Twin Clutch SST control mode (B), shifting can be performed manually.
Page 207 Starting and driving Shifting using the gearshift lever NOTE CAUTION E00621700052 After manual shifting is selected using the gearshift lever, shifting up and down can al- Sudden engine braking and rapid acceler- Selecting manual shifting so be performed using the shift paddles. ation can cause the vehicle to skid.
Page 208 Starting and driving Shifting using the shift paddles Shifting up Returning to “D” range operation E00621800109 Each time the + (SHIFT UP) shift paddle is pulled, When the gearshift lever is in the “D” (DRIVE) po- the transmission shifts up 1 gear. sition, pull the + (SHIFT UP) shift paddle towards Selecting manual shifting you for 2 seconds or more to return to “D”...
Page 209 1. Depress the brake pedal and stop the vehicle checked by a MITSUBISHI MOTORS Authorized in a safe place. Service Point. 2. Place the gearshift lever in the “P” (PARK)
Page 210 Starting and driving Uphill/downhill driving CAUTION CAUTION E00622200139 Use the gearshift lever in the correct shift DRIVING UPHILL If the warning display is shown, such position in accordance with driving condi- The Twin Clutch SST may not upshift to a higher as when the vehicle does not accelerate tions.
Page 211 Starting and driving Parking CAUTION CAUTION E00622400014 To park the vehicle, first bring it to a complete • If the vehicle is continuously driven at Do not keep the vehicle in a stopped posi- stop, fully engage the parking brake, and then low speeds using the tendency of the tion on an uphill slope by depressing the move the gearshift lever to the “P”...
Page 212: Electronically Controlled 4Wd System
The temperature of the Twin Clutch SST fluid is system* have the vehicle checked by a MITSUBISHI high. E00604900293 MOTORS Authorized Service Point as soon as pos- Refer to “Warning display” on page 4-43 and fol- The electronically controlled 4WD system is a 4- sible.
Page 213 If the indicator continues blink- After a few seconds, the information screen returns ing for more than about 5 minutes, have from the drive mode display to the previous screen. the vehicle inspected at a MITSUBISHI Drive mode Display MOTORS Authorized Service Point.
Page 214: 4-Wheel Drive Operation
4WD system and the safe- cations. ty device has activated. Have an inspec- Not only does this ensure better handling on dry, tion made by a MITSUBISHI MOTORS NOTE paved roads but also permits better traction when Authorized Service Point.
Page 215 Starting and driving After driving on rough roads, check each CAUTION WARNING part of the vehicle and wash it thoroughly with water. Refer to the “Inspection and main- When attempting to rock your vehicle out Avoid sudden braking, sudden accelera- tenance following rough road operation”...
Page 216: Inspection And Maintenance Following Rough Road Oper- Ation
Starting and driving Driving through water Inspection and maintenance Cautions on handling of 4-wheel E00618900050 following rough road operation drive vehicles If the electrical circuits become wet, further opera- tion of the vehicle will be impossible; therefore, E00606700338 E00606800397 After operating the vehicle in rough road condi- avoid driving through water unless absolutely nec- Tyres and wheels tions, be sure to perform the following inspection...
Page 217: Braking
Starting and driving Braking CAUTION CAUTION E00607001380 All the parts of the brake system are critical to safe- Always use tyres of the same size, same Do not tow 4-wheel drive vehicles with ty. We recommend you to have the vehicle type, and same brand, and which have no the front or rear wheels on the ground checked at regular intervals according to the serv-...
Page 218: Hill Start Assist
Starting and driving Hill start assist* WARNING WARNING E00628000096 The hill start assist makes it easy to start off on a If the power assist is lost or if either Do not leave any objects near the brake steep uphill slope by preventing the vehicle from brake hydraulic system stops working pedal or let a floor mat slide under it;...
Page 219 MITSUBISHI while stopping for approximately 2 seconds. MOTORS Authorized Service Point as 4. Depress the accelerator pedal and the hill Warning display soon as possible.
Page 220: Brake Assist System
Starting and driving Brake assist system When the brake assist system is in use, you Emergency stop signal system may feel as if the depressed brake pedal is E00627000291 E00626000018 soft, the pedal moves in small motions in con- The brake assist system is a device assisting drivers This is a device that reduces the possibility of rear junction with the sound of the ABS opera- who cannot depress the brake pedal firmly when it...
Page 221: Anti-Lock Brake System (Abs)
Starting and driving • The brake pedal is released. Anti-lock brake system (ABS) When the ABS is activated, you may feel the • The hazard warning flasher switch is brake pedal pulsation and the vibrations of E00607100834 pressed. the vehicle body and steering wheel. You Environmental conditions can have an effect on •...
Page 222 “ON” position and goes off a few seconds later. ing lamp/display illuminate at the same time Never install a limited-slip differential, which is not MITSUBISHI genuine parts, Warning lamp as the ABS may not function normally. CAUTION...
Page 223: Power Steering System
Starting and driving NOTE Power steering system Rear The ABS warning lamp and brake warning E00607400156 When the engine is stopped, the power steering sys- lamp illuminate at the same time and the warn- tem will not function and it will require greater man- ing displays appear alternately on the infor- ual effort to operate the steering wheel.
Page 224: Active Stability Control (Asc)
Starting and driving Active stability control (ASC)* NOTE Stability control function An operation noise may be emitted from the E00619100017 E00616700155 The stability control function is designed to help The Active Stability Control (ASC) takes overall engine compartment in the following situa- the driver maintain control of the vehicle on slip- control of the anti-lock brake system, traction con- tions.
Page 225 Starting and driving NOTE When the ASC is deactivated, the display/indica- CAUTION tor will turn on. To reactivate the ASC, momentari- When moving out of mud, sand or fresh ly press the “ASC OFF” switch; the display/indi- snow, pressing the accelerator pedal may not When display/indicator blinks, ASC is cator is turned off.
Page 226: Cruise Control
Starting and driving ASC warning display Cruise control* CAUTION E00619400544 E00609100623 If an abnormal condition occurs in the system, the Cruise control is an automatic speed control system The system may be malfunctioning. following display/indicator will turn on. that keeps a set speed. It can be activated at about Park your vehicle in a safe place and stop 40 km/h (25 mph) or more.
Page 227 Starting and driving Cruise control switches To activate 2. Accelerate or decelerate to your desired speed, then press and release the “COAST E00609301039 1. With the ignition switch in the “ON” posi- SET” switch (B) when the “CRUISE” indica- tion, press the “ON OFF” switch (A) to turn tion lamp is illuminated.
Page 228 Starting and driving When you reach your desired speed, release the Accelerator pedal When you reach your desired speed, release the switch. Your new cruising speed is now set. switch. Your new cruising speed is now set. While driving at the set speed, use the accelerator pedal to reach your desired speed and then press the “COAST SET”...
Page 229 Starting and driving Brake pedal To temporarily increase or decrease Refer to “To resume the set speed” on page 4-64. While driving at the set speed, use the brake pedal, the speed which disengages the cruise control, then press the E00609600149 “COAST SET”...
Page 230 Press the “ON-OFF” switch to turn off When the Active Stability Control (ASC) the cruise control and have your vehicle starts operating. (if so equipped) inspected by a MITSUBISHI MOTORS Refer to “Active stability control (ASC)” on Authorized Service Point. page 4-58.
Page 231: Reversing Sensor System
Starting and driving Reversing sensor system* Corner and back sensor locations Vehicles without a towing bar There are two corner sensors (A) at the corners of The detection areas are within approximately E00615500303 the rear bumper, and two back sensors (B) in the 60 cm (A) from the corner sensors, 150 cm (B) This system operates when you are backing the ve- centre of the rear bumper.
Page 232 The reversing sensor system may not prop- ly. Have the vehicle inspected at a erly detect the following: MITSUBISHI MOTORS Authorized Service • Objects that are thin, such as wire Point. nets or ropes.
Page 233 Starting and driving NOTE Back sensor (vehicles without a towing bar) Changing the detection areas E00615800159 Only when the gearshift lever or selector lev- The detection areas can be changed as follows: Vehicle to obstacle dis- Warning display/sound er is in the “R” position, the reversing sensor tance cycle system can be operated or be stopped by us-...
Page 234: Rear-View Camera
Have vehicle inspected show both sides and the lower part of the rear bump- MITSUBISHI MOTORS Authorized Service Point. er, etc. When reversing, be sure to visually confirm safety Example: Corner sensor (left) mulfunctioning around the vehicle. Type 1...
Page 235 Check surroundings for safety. For details, please refer to the separate own- er’s manual for “MITSUBISHI Multi Com- munication System (MMCS)”. When the vehicle is tilting because of the num- ber of people in the vehicle, the weight and...
Page 236: Cargo Loads
If the lens becomes contami- We recommend you to use a genuine E00609901325 nated by water droplets, snow, mud or oil, MITSUBISHI roof carrier, since the brackets wipe off the contamination, taking care not Cargo loads precautions to be used have a special shape.
Page 237 Starting and driving Attaching the roof carrier Roof carrier precaution NOTE Slide each cover (B) towards the front of the vehi- To prevent wind noise or reduction in fuel cle to remove it. economy, remove the roof carrier when not CAUTION in use.
Page 238: Trailer Towing
356 mm relevant regulations in your area, consult a 68 mm , 70 mm MITSUBISHI MOTORS Authorized Service Point. (at laden condition) The regulations concerning the towing of a trailer may differ from country to country. You are ad- 540 mm , 562 mm vised to obey the regulations in each area.
Page 239 Starting and driving NOTE Overheating This will normally occur as a result of some me- The values under item 12 can be varied de- chanical failure. If your vehicle should overheat, pending on the loading condition of cargo or stop and check for a loose or broken water pump/ luggage.
Page 241 For pleasant driving Ventilators..................5-02 Cargo area cover*.................5-93 Automatic air conditioning............5-04 Assist grips...................5-94 Important operation tips for the air conditioning......5-09 Coat hook..................5-94 Air purifier..................5-09 Luggage hooks................5-94 LW/MW/FM digital tuning radio with CD player*.....5-10 LW/MW/FM digital tuning radio with CD changer*....5-24 To play tracks from USB device*..........5-39 ®...
Page 242: Ventilators
For pleasant driving Ventilators To close the ventilator, fully move the knob (A) to NOTE the inner side. The cool air from the ventilators may appear E00700100908 as a mist. This is due to moist air being suddenly cooled by the air conditioning. This will clear after a few moments.
Page 243 For pleasant driving Changing the mode selection Foot/Face position Foot position Air flows to the upper part of the passenger com- Air flows mainly to the leg area. E00700301301 To change the position and amount of air flowing partment, and flows to the leg area. from the ventilators, turn the mode selection dial.
Page 244: Automatic Air Conditioning
For pleasant driving NOTE Automatic air conditioning With the mode selection dial between the E00702400383 The air conditioning can only be used while the en- “ ” and “ ” positions, air flows mainly gine is running. to the leg area. With the mode selection dial Control panel between the “...
Page 245 For further information, we recommend you to con- If high cooling performance is desired, or sult a MITSUBISHI MOTORS Authorized Service if the outside air is dusty or otherwise con- Point. taminated use the recirculation position.
Page 246 For pleasant driving Enable automatic air control: There is a sound each time the switch is pressed. NOTE If the mode selection dial or blower speed se- If a problem is detected in the air condition- lection dial is turned to the “AUTO” posi- ing system, the air conditioning operation in- tion, the air selection switch is also control- dication lamp (A) blinks.
Page 247 For pleasant driving When the setting is changed, a sound is emit- 1. Set the blower speed selection dial to the “AU- If the blower speed selection dial, air condi- ted and the indication lamp flashes. TO” position. tioning switch, mode selection dial, or air se- •...
Page 248 For pleasant driving For ordinary demisting For quick demisting For vehicles with the Auto Stop & Go (AS&G) system, if the mode selection dial is Perform the following settings to prevent misting set to the demister position shown in the illus- of the windscreen and door windows, and to heat tration, the Auto Stop &...
Page 249: Important Operation Tips For The Air Conditioning
For pleasant driving Important operation tips for the The new refrigerant HFC-134a in your vehicle will Air purifier not harm the ozone layer. air conditioning E00708400561 We recommend you to recover and recycle the re- An air filter has been incorporated into the air con- E00708300762 frigerant for reuse.
Page 250: Lw/Mw/Fm Digital Tuning Radio With Cd Player
For pleasant driving LW/MW/FM digital tuning radio Volume and tone control panel If the SOUND switch (4) is pushed and held for more than 2 seconds during the audio adjust mode, E00708600693 with CD player* it will change to “Hold” mode. The selected audio E00708501859 mode will be held until the SOUND switch (4) is The audio system can only be used when the igni-...
Page 251 For pleasant driving FIELD (Sound field selection) FADER (Front/Rear balance control) 1. Turn the SOUND switch (4) to select the de- Turn the SOUND switch (4) to balance volume sired sound field. from the front and rear speakers. 2. Press the SOUND switch (4) to set the audio system to the selected sound field.
Page 252 For pleasant driving Radio control panel and display E00708900771 1- PWR (On-Off) switch 5- SEEK (Up-seek) button 2- AM/FM (FM/MW/LW selection) button 6- SEEK (Down-seek) button 3- Memory select buttons 7- FM (FM1/FM2/FM3) indicator 4- TUNE switch 8- ST (Stereo) indicator 5-12...
Page 253 For pleasant driving To listen to the radio To enter frequencies into the memory NOTE E00716100831 E00709000522 Disconnecting the battery terminal erases all 1. Press the PWR switch (1) or the AM/FM but- the radio frequencies stored in the memory. Manual setting ton (2) to turn ON the radio.
Page 254 For pleasant driving Radio data system (RDS) E00709200276 1- PWR (On-Off) switch 8- SEEK (Down-seek) button 2- AM/FM (FM/MW/LW selection) button 9- CT (Clock time) indicator 3- Memory select buttons 10- RDS (Radio data system) indicator 4- TP (Traffic program) button 11- TP (Traffic program identification) indicator 5- PTY (Program type) button 12- PTY (Program type) indicator...
Page 255 For pleasant driving AF (Alternative Frequencies) function If there are no frequencies broadcasting the same 16. WEATHER (Weather information) programming, the radio searches a frequency broad- 17. FINANCE E00720900074 The AF function finds a station broadcasting the casting the regional programming. The radio suc- 18.
Page 256 For pleasant driving NOTE NOTE Traffic information E00721600182 If the SEEK button (7 to 8) is pressed, the ra- After selecting a mode, you can leave the func- The radio will automatically tune in to traffic infor- dio will try to find out another broadcast of tion setup mode by taking either of the fol- mation broadcasts while receiving FM broadcasts the same program type as currently selected.
Page 257 For pleasant driving The TP search function can be turned ON and OFF. Refer to “Function setup mode” on page 5-17. Emergency broadcasts TP-S E00721700112 PI-S Language of PTY display 1. Press the TUNE switch (6) for 2 seconds or longer to select the function setup mode.
Page 258 For pleasant driving 2. Press the TUNE switch (6) repeatedly to se- The setting will be shown on the display. • Press the TUNE switch (6) for at least 2 lect the mode you wish to change. seconds. The order is: AF → CT → REG → TP-S → •...
Page 259 For pleasant driving CD control panel and display E00709500774 1- AM/FM button 13- FOLDER switch 2- CD (CD mode changeover) button (Track up) button 3- PWR (On-Off) switch (Track down) button 4- PAGE (Title scroll) button 16- CD indicator 5- DISP (Display) button 17- FOLDER indicator 6- RPT (Repeat) button 18- TRACK (Track number) indicator...
Page 260 For pleasant driving To listen to a CD To listen to a music CD To listen to an MP3 CD This CD player allows you to play MP3 (MPEG Au- E00709601886 1. Insert disc with label facing up. dio Layer-3) files recorded on CD-ROMs, CD-Rs When a disc is inserted, the CD indicator (recordable CDs), and CD-RWs (rewritable CDs) (16) will come on and the CD player will be-...
Page 261 For pleasant driving NOTE Folder selection CAUTION While listening to a disc on which CD-DA (CD-Digital Audio) and MP3 files have both Attempting to play a file not in the MP3 In the order been recorded, you can switch between read- format which has a “.mp3”...
Page 262 For pleasant driving Folder up NOTE To find the start of each track on a disc for playback Turn the FOLDER switch (13) clockwise until the Press the SCAN button (10). “SCAN” will appear With a disc that contains both CD-DA and desired folder number appears on the display.
Page 263 For pleasant driving CD text MP3 titles The display can show up to 12 characters. If a folder name, track name, or item of ID3 tag The CD player can display disc and track titles for The CD player can display folder and track titles information has more than 12 characters, discs with converted disc and track title informa- for discs with converted folder and track informa-...
Page 264: Lw/Mw/Fm Digital Tuning Radio With Cd Changer
For pleasant driving LW/MW/FM digital tuning radio Volume and tone control panel NOTE E00708600707 The SUB LEVEL can only be adjusted on ve- with CD changer* hicles with a premium sound system. E00708501862 On vehicles without a premium sound sys- The audio system can only be used when the igni- tem, when you press the SOUND switch (4), tion switch is in the “ON”...
Page 265 For pleasant driving 2. Press the SOUND switch (4) to set the audio BALANCE (Left/Right balance control) Acoustic char- Details system to the selected sound field. Turn the SOUND switch (4) to balance volume acteristics from the left and right speakers. The optimum acoustic character- Sound field Details...
Page 266 For pleasant driving Radio control panel and display E00708900784 1- PWR (On-Off) switch 5- SEEK (Up-seek) button 2- AM/FM (FM/MW/LW selection) button 6- SEEK (Down-seek) button 3- Memory select buttons 7- FM (FM1/FM2/FM3) indicator 4- TUNE switch 8- ST (Stereo) indicator 5-26...
Page 267 For pleasant driving To listen to the radio To enter frequencies into the memory NOTE E00716100844 E00709000548 Disconnecting the battery terminal erases all 1. Press the PWR switch (1) or the AM/FM but- the radio frequencies stored in the memory. Manual setting ton (2) to turn ON the radio.
Page 268 For pleasant driving Radio data system (RDS) E00709200289 1- PWR (On-Off) switch 8- SEEK (Down-seek) button 2- AM/FM (FM/MW/LW selection) button 9- CT (Clock time) indicator 3- Memory select buttons 10- RDS (Radio data system) indicator 4- TP (Traffic program) button 11- TP (Traffic program identification) indicator 5- PTY (Program type) button 12- PTY (Program type) indicator...
Page 269 For pleasant driving AF (Alternative Frequencies) function If there are no frequencies broadcasting the same 17. FINANCE programming, the radio searches a frequency broad- 18. CHILDREN E00720900162 The AF function finds a station broadcasting the casting the regional programming. The radio suc- 19.
Page 270 For pleasant driving NOTE NOTE Traffic information E00721600124 If the SEEK button (7 to 8) is pressed, the ra- After selecting a mode, you can leave the func- The radio will automatically tune in to traffic infor- dio will try to find out another broadcast of tion setup mode by taking either of the fol- mation broadcasts while receiving FM broadcasts the same program type as currently selected.
Page 271 For pleasant driving The TP search function can be turned ON and OFF. Refer to “Function setup mode” on page 5-31. Emergency broadcasts TP-S E00721700125 PI-S Language of PTY display 1. Press the TUNE switch (6) for 2 seconds or longer to select the function setup mode.
Page 272 For pleasant driving 2. Press the TUNE switch (6) repeatedly to se- 3. Select the desired setting for each mode to be NOTE lect the mode you wish to change. turned ON and OFF as shown below. After selecting a mode, you can leave the func- The order is: AF →...
Page 273 For pleasant driving CD control panel and display E00709500787 1- AM/FM button 16- CD insertion slot 2- CD (CD mode changeover) button 17- FOLDER switch 3- PWR (On-Off) switch (Track up) button 4- LOAD indicator (Track down) button 5- LOAD button 20- CD indicator 6- PAGE (Title scroll) button 21- FOLDER indicator...
Page 274 For pleasant driving To listen to a CD To set discs 2. The autochanger will select the lowest-num- bered empty slot and switch to loading stand- E00709602229 The CD can be loaded or ejected by pressing the by mode. LOAD button (5) or the eject button (15) even if 3.
Page 275 For pleasant driving NOTE To listen to a music CD To listen to an MP3 CD This autochanger allows you to play MP3 (MPEG If you press the eject button (15) while the Audio Layer-3) files recorded on CD-ROMs, display is showing “LOAD DISC No. (1-6)”, CD-Rs (recordable CDs), and CD-RWs (rewritable the loading standby mode will be cancelled CDs) in ISO9660 Level 1/Level 2, Joliet, and Ro-...
Page 276 For pleasant driving NOTE To fast-forward/reverse the disc CAUTION While listening to a disc on which CD-DA Fast-forward (CD-Digital Audio) and MP3 files have both Attempting to play a file not in the MP3 The disc is fast-forwarded while the button been recorded, you can switch between read- format which has a “.mp3”...
Page 277 For pleasant driving Track up NOTE NOTE The disc will skip as many songs as the number of With a disc that contains both CD-DA and In the all discs random mode, if an MP3 CD times the button (18) is pushed. MP3 files, the repeat mode causes only files has been loaded in the autochanger, the au- The display window will display the track number...
Page 278 For pleasant driving CD text MP3 titles When there is no title information to be dis- played, the display shows “NO TITLE”. The autochanger can display disc and track titles The autochanger can display folder and track titles The display can show up to 12 characters. If for discs with converted disc and track title informa- for discs with converted folder and track informa- a folder name, track name, or item of ID3 tag...
Page 279: To Play Tracks From Usb Device
For pleasant driving To play tracks from USB device* E00756100048 You can connect your iPod or USB memory device to the USB input terminal and play music files stor- ed in the iPod or USB memory device. See the following section for the types of connecta- ble devices and supported files.
Page 280 For pleasant driving iPod control panel and display E00756200166 1- AM/FM button (Fast-forward) button 2- CD (Mode change) button 10- DISC UP button 3- PWR (On-Off) button 11- FOLDER switch 4- PAGE (Title scroll) button 12- TRACK (Track up/down) button 5- DISP (Title display) button 13- i (iPod) indicator 6- RPT (Repeat) button...
Page 281 For pleasant driving To play from an iPod To adjust the volume and tone, refer to “To If the side of the button is pressed once while a adjust the volume” on pages 5-10, 5-24 and track is playing, playback returns to the start of that E00756300037 1.
Page 282 For pleasant driving To play the same track repeatedly Album title → Track name → Artist name → Nor- The following explains how to prepare for voice op- mal display eration and play the tracks. E00756700028 Press the RPT button (6) during playback to show Preparation for voice operation “RPT”...
Page 283 For pleasant driving NOTE NOTE 7. The system exits the voice recognition mode If you say “Artist <name>,” you can skip and starts playback. If you say “No” to three or all album titles ut- step 3. tered by the system, the voice guide will say “Album not found, please try again”...
Page 284 For pleasant driving NOTE NOTE 7. The system exits the voice recognition mode If you say “Playlist <playlist>,” you can skip and starts playback. If you say “No” to three or all genres uttered step 3. by the system, the voice guide will say If the device has no playlist, the voice guide “Genre not found, please try again”...
Page 285 For pleasant driving USB control panel and display E00758100172 1- AM/FM button 10- DISC UP button 2- CD (Mode change) button 11- SCAN button 3- PWR (On-Off) button 12- FOLDER switch 4- PAGE (Title scroll) button 13- TRACK (Track up/down) button 5- DISP (Title display) button 14- U (USB) indicator 6- RPT (Repeat) button...
Page 286 For pleasant driving To play from a USB memory device NOTE Folder selection E00762500034 To adjust the volume and tone, refer to “To In the order 1. Press the PWR button (3) to turn on the au- adjust the volume” on pages 5-10, 5-24 and dio system.
Page 287 For pleasant driving NOTE The audio randomly selects tracks from all folders : The file number increases by Press When the DISC UP button (10) is pressed, and plays the selected tracks. one. the selected folder is played from the begin- To exit this mode, press the button again.
Page 288 For pleasant driving To switch the display Up to 10 characters are shown in the display Preparation for voice operation at once. If the title is cut off in the middle, E00759300012 To use the voice operation, press the SPEECH but- You can display titles with tag information.
Page 289: To Play Tracks From A Bluetooth ® Device (Vehicles With Bluetooth ® 2.0 Interface)
For pleasant driving ® To play tracks from a Bluetooth ® device (vehicles with Bluetooth 2.0 interface) E00759700032 You can wirelessly connect a digital audio player ® or cellular phone supporting Bluetooth to listen to the tracks on the connected device. ®...
Page 290 For pleasant driving ® Bluetooth device control panel and display E00762600149 1- CD (Mode change) button 8- DISC UP (Play) button 2- PWR (On-Off) button 9- SCAN button 3- PAGE (Title scroll) button 10- TRACK (Track up/down) button 4- DISP (Title display) button 11- B (Bluetooth ®...
Page 291 For pleasant driving To listen to tracks from a device con- To pause the playback (if supported by the device) To exit this mode, press the button again. E00762900025 ® nected via Bluetooth To play tracks in random order (if supported by To pause the playback, press the DISC DOWN but- E00762700166 ton (7).
Page 292 (RCA), refer to the separate own- tails, refer to the separate rear-seat display er’s manual for the rear-seat display or the owner’s manual.) MITSUBISHI Multi-Communication Sys- 3. To deactivate the external audio input mode, tem. press the AM/FM button (F) or the CD but- ton (D) to switch to another mode.
Page 293: To Listen To A Disc In The Rear-Seat Display
For pleasant driving To listen to a disc in the rear-seat Steering wheel audio remote CAUTION display (vehicles with rear-seat control switches* Do not operate the connected audio equip- display) E00710000681 ment while driving. The remote control switch is located on the left E00755100139 This could distract you and an accident side of the steering wheel.
Page 294 For pleasant driving Turning on the power To fast-forward/reverse the disc (music CDs only) NOTE To fast-forward/reverse the disc, press the fast-for- Press the power switch (3) to turn on the power. The track number increases continuously ward button (4) or the fast-reverse button (5). When you turn the power on, the mode that was se- while the button is pressed.
Page 295: Error Codes (Ipod)
For pleasant driving Error codes E00710101197 If an error code (1) appears in the display, take action in accordance with the table below. 5-55...
Page 296 Inside of audio system is hot. Internal protection against high temperatures. nutes. Communication error between external device Communication or power supply Consult a MITSUBISHI MOTORS Author- ERROR and audio equipment. error ized Service Point. Power supply error of external device.
Page 297 Connect a supported iPod. Remove the iPod. USB BUS PWR (Blink) An overcurrent or other power-supply error has occurred. Have the vehicle inspected at a MITSUBISHI MOTORS Authorized Service Point. If the iPod indicator illuminates, the iPod cannot be authen- Reconnect the iPod.
Page 298: Error Codes (Usb Memory Device)
For pleasant driving Error codes (USB memory device) E00763600117 Vehicles with Link System If an error code (1) appears in the display, take action in accordance with the table below. 5-58...
Page 299 Remove the USB memory device. USB BUS PWR (Blink) An overcurrent or other power-supply error has occurred. Have the vehicle inspected at a MITSUBISHI MOTORS Authorized Service Point. Have the vehicle inspected at a MITSUBISHI MOTORS U LSI ERROR (Blink) Internal device errors Authorized Service Point.
Page 300: Handling Of Compact Discs
For pleasant driving Handling of compact discs When storing compact discs, always store them in their separate cases. Never place com- E00723000382 pact discs in direct sunlight, or in any place Use only the type of compact discs that have where the temperature or humidity is high.
Page 301: Antenna
For pleasant driving ing properly and you may not be able to eject Antenna WARNING the compact disc. E00710500312 Operating the CD player in a manner oth- Roof antenna er than specifically instructed herein may Before listening to the radio, raise the antenna until result in hazardous radiation exposure.
Page 302: Digital Clock
For pleasant driving NOTE Digital clock* Select the automatic mode or the manual mode by performing the following operations: Be sure to remove the roof antenna in the fol- E00711800501 1. Press the PWR switch (A) to turn ON the au- lowing cases: dio system.
Page 303 For pleasant driving NOTE Automatic mode Set the time by pressing the various buttons as de- Although “PHONE” appears on the display, scribed below. The automatic adjustment mode can set the local the PHONE function is inoperative. 1. Keep the CLOCK button pressed until the time automatically by using the signal from local time display flashes.
Page 304: Link System
Bluetooth TOOTH SIG, INC. You have acquired a device that includes software 2.0 interface. licensed by MITSUBISHI MOTORS CORPORA- ® Some Bluetooth devices are not compatible TION from JOHNSON CONTROLS Inc (the auto- WARNING ®...
Page 305 For pleasant driving make receive hands-free If you press the button briefly while in voice NOTE calls ® p. 5-71 recognition mode, it will interrupt prompting When you press the SPEECH button to enter Phone book function ® p. 5-73 and allow voice command input.
Page 306 For pleasant driving For best performance and further reduction 6. When the voice guide says “English (French, 4. The voice guide will say “Confirmation of ambient noise, the vehicle windows Spanish, Italian, German, Dutch or Portu- prompts are <on/off>. Would you like to turn should be closed while engaging the voice rec- guese) selected,”...
Page 307 “Cancel” to quit the voice input mode and E00727500226 It takes about 2 to 3 minutes to complete the speak- this correct?” Answer “Yes.” then check with a MITSUBISHI MOTORS er enrollment process. Answer “No” to return to the password input Authorized Service Point.
Page 308 For pleasant driving NOTE Enabling and disabling the voice model and re- NOTE If you do not start the speaker enrollment proc- training Pairing is required only when the device is ess within 3 minutes of pressing the E00727600096 used for the first time. Once the device has You can turn a voice model registered with the SPEECH button, the speaker enrollment func- ®...
Page 309 For pleasant driving 2. Press the SPEECH button. The pairing code entered here is only used vice and register it as a device tag. Say the 3. Say “Setup”. ® name you want to register after the beep. for the Bluetooth connection certification.
Page 310 For pleasant driving NOTE swer “Yes” to continue and connect to the cel- 7. The voice guide will say “Deleted,” and then lular phone. You can connect to a music player at any the system will end the device deletion proc- Answer “No,”...
Page 311 For pleasant driving To make a call ® p. 5-71 NOTE please?” Say the number of the device tag you want to change. SEND function ® p. 5-72 If you press and release the SPEECH button Receiving calls ® p. 5-73 and say “Continue”...
Page 312 For pleasant driving ® name>.” If that person is the one you want to If the name you selected has matching data The Bluetooth 2.0 interface supports num- call, answer “Yes.” in the mobile phone book but no telephone bers (0 to 9) and characters (+, # and *). Answer “No,”...
Page 313 For pleasant driving For example, if during a call you need to simulate Switching between hands-free mode and private Names and telephone numbers can be changed lat- the press of a phone button as a response to an auto- er on. mode mated system, press the SPEECH button and speak E00761400036...
Page 314 For pleasant driving NOTE NOTE 3. The voice guide will say “Select one of the When the confirmation function is on, the following: new entry, edit number, edit When the confirmation function is on, after voice guide will say “<Location>. Is this cor- name, list names, delete, erase all, or import repeating the telephone number you have rect?”...
Page 315 For pleasant driving NOTE 10. The voice guide will say “Would you like to 5. The voice guide will say “Home, work, mo- ® import another contact?” bile or other?” If the Bluetooth 2.0 interface cannot recog- Answer “Yes” if you want to continue with Select and say the location where the tele- ®...
Page 316 For pleasant driving NOTE 1. Press the SPEECH button. 5. When the voice guide is done reading the 2. Say “Phone book.” list, it will say “End of list, would you like to Say “List names,” and the names registered 3.
Page 317 For pleasant driving You can delete all registered information from the ® For the connection settings on the cellular The Bluetooth 2.0 interface automatically con- vehicle phone book. phone side, refer to the instructions for the verts from text to voice the names registered in the 1.
Page 318 For pleasant driving If an error occurs during the data transfer, all transfer will be cancelled and the voice guide will say “Unable to complete the phone book import” and then the system will return to the main menu. If there are no contacts in the phone book, the voice guide will say “There are no con- tacts on the connected phone.”...
Page 319 For pleasant driving Enrollment commands E00732400193 Phrase English French Spanish Italian German Dutch Portuguese Russian 1 123456789 123456789 123456789 123456789 123456789 123456789 123456789 123456789 2 888 555 1212 888 555 1212 888 555 1212 888 555 1212 888 555 1212 888 555 1212 888 555 1212 888 555 1212...
Page 320: Usb Input Terminal
For pleasant driving USB input terminal* 3. Connect the connector cable (C) to the USB CAUTION memory device (B). E00761900015 You can connect your USB memory device or iPod Keep the lid of the floor console box to play music files stored in the USB memory de- closed while driving the vehicle.
Page 321 For pleasant driving 3. Connect the Dock connector (C) to the iPod Model name Condition CAUTION (B). Storage capacity of 256 USB memory device Keep the lid of the floor console box Mbytes or more closed while driving the vehicle. A lid or F/W Ver.1.1.1 or later iPod touch the contents of the floor console box...
Page 322: Sun Visors
For pleasant driving Do not connect to the USB input terminal Sun visors CAUTION any device (hard disk, card reader, memory E00711201094 reader, etc.) other than the connectable devi- If the lid of vanity mirror with lamp is ces specified in the previous section. The de- kept open for prolonged periods of time, vice and/or data may be damaged.
Page 323: Ashtray
For pleasant driving Ashtray* Moveable ashtray secure holder Cigarette lighter* The moveable ashtray can be fitted at the indicated E00711400422 E00711501390 The cigarette lighter can be used while the ignition position. switch is in the “ON” or “ACC” position. CAUTION Put out matches and cigarettes before they are placed in the ashtray.
Page 324: Accessory Socket
Pull it out and have the problem correc- accessories are 12 V accessories and that ted at MITSUBISHI MOTORS Author- the total power consumption does not ex- ized Service Point. ceed 120 W.
Page 325: Interior Lamps
For pleasant driving Interior lamps Room lamps Luggage area E00712101146 E00712000959 Front 1- (DOOR) The lamp illuminates when a door or the tailgate is opened. It goes off about 15 seconds after the door 1- Luggage room lamp or tailgate is closed. However, the lamp goes off im- 2- Room lamp (rear) mediately in the following cases: 3- Map &...
Page 326 The lamp illuminates when a door or the tailgate is When the key was used to start the engine, if MITSUBISHI MOTORS Authorized Service opened. It goes off about 15 seconds after the door the key is removed while the doors and tail- Point.
Page 327: Storage Spaces
E00713101390 activated. The time until the lamps automati- cally go off can be adjusted. For details and CAUTION support, consult your nearest MITSUBISHI MOTORS Authorized Service Point. Never leave lighters, cans of carbonated On vehicles equipped with MITSUBISHI drink, and spectacles in the cabin when...
Page 328 For pleasant driving To use the warming and cooling function* For detailed information on how to use the air conditioning, refer to “Automatic air con- The upper glove box can be used to keep its con- ditioning” on page 5-04. tents (e.g.
Page 329 For pleasant driving NOTE Card holder Type 2 There is a card holder inside the lower glove box. Upper and lower boxes are located inside the floor In vehicles equipped with the keyless opera- console box. tion system, the lower glove box can be The floor console box can also be used as an armrest.
Page 330 For pleasant driving Upper box Tissue holder To close, push until it locks. To open the upper box, lift the right release lever The tissue holder (C) is located on the underside of (A) and raise the lid. the floor console box lid. Type 1 Type 2 CAUTION...
Page 331: Cup Holder
For pleasant driving Quarter trim box* Cup holder For the front seat E00730800018 The cup holder is located in front of the floor con- E00714500381 The box for storing articles is located inside the lug- sole box. gage compartment. CAUTION Do not drink beverages while driving.
Page 332: Bottle Holder
For pleasant driving 2. Open the lid (A) while holding the side face Bottle holder For the second seat of the lid with your hand. There are bottle holders located on both sides. E00718200269 CAUTION Do not drink beverages while driving. This is distracting and could cause an ac- cident.
Page 333: Cargo Area Cover
For pleasant driving NOTE Cargo area cover* To change If the rear seat seatbacks make contact with There are 2 installation holes (B) for the cargo area E00715500551 the cargo area cover, move back the cargo cover. area cover. To use The cargo area cover could break if it sup- 1.
Page 334: Assist Grips
For pleasant driving Assist grips Coat hook Luggage hooks E00732800184 E00725600513 E00715700292 The assist grips (located above the doors on the There is a coat hook on the rear seat assist grip of There are 4 hooks located on the floor and side headliner) are not designed to support body weight.
Page 335 For emergencies If the vehicle breaks down............6-02 Emergency starting...............6-02 Engine overheating...............6-04 Bleeding the fuel system (For diesel-powered vehicles equipped with Twin Clutch SST)..........6-06 Removal of water from the fuel filter (For diesel-pow- ered vehicles equipped with Twin Clutch SST).......6-06 Tools and jack................6-08 How to change a tyre..............6-09 Towing..................6-19 Operation under adverse driving conditions.........6-22...
Page 336: If The Vehicle Breaks Down
For emergencies If the vehicle breaks down Emergency starting 2. Set the parking brake firmly on each vehicle. Put an A/T, CVT or Twin Clutch SST in “P” E00800101212 E00800502561 (PARK) or a M/T in “N” (Neutral). Turn off If the vehicle breaks down on the road, move it to If the engine cannot be started because the battery the ignition switch.
Page 337 For emergencies Lift up the front of the engine cover to re- 2400 models For vehicles equipped with Twin Clutch SST lease the 4 grommets (A) and remove the cov- 7. Connect one end of the other jumper cable to 3000 models the negative (-) terminal of the booster bat- tery, and the other end to the engine block of...
Page 338: Engine Overheating
For emergencies Engine overheating CAUTION WARNING E00800602360 When the engine is overheating, the information If the battery has to be charged while fit- Take care not to get the jumper cable screen in the multi-information display will be in- ted in the vehicle, disconnect the vehicle caught in the cooling fan or other rotat- terrupted and the engine coolant temperature warn- side negative (-) terminal connected to the...
Page 339 For emergencies 5. Check the coolant level in the reserve tank (A). Diesel-powered vehicles WARNING Do not open the bonnet while steam is com- Petrol-powered vehicles ing from the engine compartment. It could cause steam or hot water to spurt out, causing burns.
Page 340: Bleeding The Fuel System
For emergencies 6. Fill the reserve tank with coolant as needed. Bleeding the fuel system (For Removal of water from the fuel (Refer to the “Maintenance” section.) diesel-powered vehicles equipped filter (For diesel-powered with Twin Clutch SST) vehicles equipped with Twin CAUTION Clutch SST) E00800700309...
Page 341 For emergencies 3. Move the duct (C) to the front of the vehicle. 5. Check the position of the fuel filter (E). CAUTION Be sure to carefully clean away any water drained out because any fuel mixed with the water could ignite and cause a fire. NOTE Up to 350 cc drains.
Page 342: Tools And Jack
For emergencies 11. Check to be sure that the fuel filter indicator Tools and jack Tools display illuminates when the ignition switch E00800900633 is turned to “ON”, and that it goes off when the engine is started. If in doubt, we recom- Storage mend you to consult a specialist for necessa- The tools and jack are stowed on the right side of...
Page 343: How To Change A Tyre
For emergencies 2. Remove the fastening band (C) and remove 2. Extend the jack and firmly secure it. How to change a tyre the tools. E00801202376 Before changing a tyre, first stop your vehicle in a safe, flat location. 1. Park the vehicle on level and stable ground, free of loose pebbles, etc.
Page 344 When the tread wear indicators appear, designed specially for your vehicle from the tyre must be replaced. your MITSUBISHI MOTORS Author- NOTE Refer to “Wheel condition” on page 8-13. ized Service Point.
Page 345 For emergencies Refer to “Split tailgate: To open” on page 3. Raise the lower gate until it locks properly in 1-31. position with a click. Refer to “Split tailgate: To close” on page 1-31. 4. Lift up the tyre hanger (B) at the section indi- cated by the arrow in the diagram, remove it from the hook (C), lower it, and then take the tyre off the tyre hanger.
Page 346 For emergencies 2. Insert the wheel nut wrench in the hole and 5. Take out the standard spare wheel from the lower the standard spare wheel by turning it spare tyre hanger. anticlockwise. Except on vehicles with a T155/90D16 size spare wheel 1.
Page 347 For emergencies jacking point closest to the tyre you wish to 3. Rotate the jack by hand until the flange por- Slowly rotate the wheel nut wrench until the change. tion (B) fits in the groove (C) at the top of tyre is raised slightly off the ground surface.
Page 348 For emergencies 5. Remove the wheel nuts with the wheel nut Normal wheel and temporary spare wheels WARNING wrench, then take the wheel off. Initially tighten the wheel nuts until the ta- pered part (A) of the nuts lightly touches Be sure to position the tyres the correct the wheel hole seats (B) enough to keep way when putting them on the vehicle.
Page 349 For emergencies wheel enough to keep the tyre from wob- (Achieved by applying force of 350 to 420 N CAUTION bling. at end of wheel nut wrench supplied with ve- hicle) Never apply oil to either the wheel bolts or the nuts, or they will tighten too much. NOTE Flange nuts can be temporarily used on the steel wheel, but return to the original wheel...
Page 350 If you find any damage on a spare tyre, do not use the tyre and con- tact a MITSUBISHI MOTORS Author- ized Service Point. 2. Lift up the tyre hanger (A) and hang it on the hook (B).
Page 351 For emergencies Except on vehicles with a T155/90D16 size spare 5. Install the cover (A). wheel 1. Put the tyre on the spare tyre hanger with the wheel surface facing downwards. CAUTION To store the tools and jack After storing the spare wheel, check that the spare tyre hanger is securely locked E00803800037 Reverse the removing procedure when storing the...
Page 352 3. Push the underside (F) of the wheel cover in- deeply into the notch provided in the wheel cover, MITSUBISHI MOTORS Authorized Service to the wheel. and pry the cover away from the wheel. Using the Point.
Page 353: Towing
If your vehicle needs to be towed If you need to tow your vehicle, we recommend This vehicle must not be towed by a tow that you contact a MITSUBISHI MOTORS Author- truck using sling lift type equipment ized Service Point or tow truck company.
Page 354 For emergencies NOTE If your vehicle is to be towed by another vehicle CAUTION For vehicles equipped with the Auto Stop & 1. The front towing hook (A) is located as Go (AS&G) system, press the “Auto Stop & shown in the illustration. Secure the tow rope [For 2WD vehicles equipped with the Ac- Go (AS&G) OFF”...
Page 355 For emergencies 4. Turn on the hazard warning lamps if required If your vehicle tows another vehicle 4. Always attach the tow rope to the towing by law. (Follow the local driving laws and hook. Otherwise, the instructions are the 1.
Page 356: Operation Under Adverse Driving Conditions
For emergencies Operation under adverse driving Depressing the brake pedal during travel on snowy or icy roads may cause tyre slippage conditions and skidding. Tyres may slip if the ability of E00801702629 the tyres to grip the road surface lessens. This may make it more difficult to stop the On a flooded road vehicle with normal braking operations.
Page 357 Vehicle care Vehicle care precautions...............7-02 Cleaning the interior of your vehicle..........7-02 Cleaning the exterior of your vehicle...........7-03...
Page 358 Vehicle care Vehicle care precautions Cleaning the interior of your NOTE Do not use cleaners, conditioners, and protec- E00900100548 vehicle In order to maintain the value of your vehicle, it is tants containing silicons or wax. E00900200220 necessary to perform regular maintenance using the Such products, when applied to the instru- After cleaning the interior of your vehicle with wa- proper procedures.
Page 359 Vehicle care NOTE Cleaning the exterior of your CAUTION If genuine leather is wet with water or is wash- vehicle ed in water, wipe off water as quickly as pos- When washing the under side of your ve- E00900700108 sible with a dry, soft cloth. If left damp, mil- hicle or wheel, be careful not to injure If the following is left on your vehicle, it may dew may grow.
Page 360 Do not wax your vehicle in direct sunlight. You Small cracks and scratches in the paint coat should with tape. should wax after the surfaces have cooled. be touched up as soon as possible with MITSUBISHI touch-up paint to prevent corrosion. 7-04...
Page 361 Vehicle care Check body areas facing the road or the tyres care- Aluminium wheels* NOTE fully for damage to the paint caused by gravels, E00901500347 To clean the inside of the rear window, al- 1. Remove dirt using a sponge while sprinkling etc.
Page 362 Vehicle care Never spray or splash water on the electrical com- ponents in the engine compartment, as this may cause damage. Do not bring the nearby parts, the plastic parts and so on into contact with sulphuric acid (battery elec- trolyte) which may crack, stain or discolour them.
Page 363 Maintenance Service precautions...............8-02 Catalytic converter................8-02 Bonnet...................8-03 Engine oil..................8-04 Engine coolant................8-06 Washer fluid.................8-08 Brake fluid/Clutch fluid*..............8-08 Power steering fluid..............8-09 Battery..................8-09 Tyres.....................8-11 Parking brake break-in..............8-15 Wiper blade rubber replacement...........8-15 General maintenance..............8-17 For cold and snowy weather............8-17 Fusible links..................8-18 Fuses.....................8-18 Replacement of lamp bulbs............8-23...
Page 364: Service Precautions
Always use We recommend you to have the periodic inspection ensure proper catalyst operation and prevent possi- automotive jack stands. and maintenance performed by a MITSUBISHI ble catalyst damage. Improper handling of components and MOTORS Authorized Service Point or another spe- materials used in the vehicle can endan- cialist.
Page 365: Bonnet
Maintenance Bonnet CAUTION E01000302454 After inserting the support bar into the To open slot, make sure the bar supports the bon- 1. Pull the release lever towards you to unlock net securely from falling down on to your the bonnet. head or body.
Page 366: Engine Oil
Maintenance NOTE Engine oil 3000 models MIN. MAX. If this does not close the bonnet, release it E01000402569 from a slightly higher position. To check and refill engine oil Do not press down firmly on the bonnet as do- ing so could damage it. For vehicles equipped with the security Petrol-powered vehicles alarm system, if you drive with the bonnet...
Page 367 Maintenance The engine oil used has a significant effect on the Recommended engine oil viscosity CAUTION engine’s performance, service life and startability. Be sure to use oil of the recommended quality and Petrol-powered vehicles In diesel-powered vehicles equipped with appropriate viscosity. M/T, when burning away and removing All engines consume a certain amount of oil during soot accumulated in the DPF, fuel can...
Page 368: Engine Coolant
Use engine oil conforming to the following FULL classification: • ACEA classification: “For service C1, C2, C3 or C4” • JASO classification: “For service DL-1” If those classifications are not available, con- tact a MITSUBISHI MOTORS Authorized Service Point. 8-06...
Page 369 It can MITSUBISHI Genuine Coolant has excellent pro- Do not open the radiator cap (B) while also cause damage to the cooling system if tection against corrosion and rust formation of all the engine is hot.
Page 370: Washer Fluid
Maintenance Washer fluid Brake fluid/Clutch fluid* Use “BASF Glysantin Alu Protect Premium/G30 E01000700539 E01000800631 or G33” or equivalent. Open the washer fluid reservoir cap and check the The brake fluid and the clutch fluid share the reser- This coolant has excellent protection against corro- level of washer fluid with the dipstick.
Page 371: Power Steering Fluid
Clean the filler cap before removing and close the cap securely after maintenance. Fluid type Use “Genuine MITSUBISHI Power Steering Flu- id” or “ATF DEXRON III/DEXRON II”. The electrolyte level must be between the specified limit on the outside of the battery. Replenish with distilled water as necessary.
Page 372 Maintenance Check the electrolyte level at least once every 4 Type A WARNING weeks, depending on the operating conditions. If the battery is not used, it will discharge by itself The battery electrolyte is extremely caus- with time. tic. Do not allow it to come in contact Check it once every 4 weeks and charge with low with your eyes, skin, clothing, or the pain- current as necessary.
Page 373: Tyres
Maintenance Tyres CAUTION E01001300255 Do not bring the nearby parts, the plastic parts and so on into contact with sulphu- WARNING ric acid (battery electrolyte) which may crack, stain or discolour them. Driving with tyres that are worn, dam- If they are in contact, wipe off with soft aged or improperly inflated can lead to a cloth, chamois or the like and an aqueous loss of control or blow out of the tyres...
Page 374 Maintenance Tyre inflation pressures E01001402319 Up to 5 passengers Up to max. load At trailer towing Item Tyre size Front Rear Front Rear Front Rear 2.2 bar (32 psi) [220 kPa] 215/70R16 100H 2.2 bar (32 psi) [220 kPa] 2.3 bar (33 psi) [230 kPa] 2.5 bar (36 psi) [250 kPa] Normal tyre 2.2 bar (32 psi) [220 kPa]...
Page 375 Maintenance Wheel condition Tyre rotation CAUTION E01001800931 E01001901317 Tyre wear varies with vehicle conditions, road sur- Always use tyres of the same size, same face conditions and individual driver’s driving hab- type, and same brand, and which have no its. To equalize the wear and help extend tyre life, wear differences.
Page 376 Contact a MITSUBISHI MOTORS Authorized A temporary spare tyre can be fitted tem- Snow tyres Service Point before putting on tyre chains. The porarily in place of a tyre that has been re- max.
Page 377: Parking Brake Break-In
This procedure is described in the vehicle service blade further to remove it. that they do not damage the disc wheel or manual and can be carried out by a MITSUBISHI body. MOTORS Authorized Service Point. Do not install a tyre chain on an emergen- cy wheel which is compact in size.
Page 378 Maintenance NOTE the retainers are correctly aligned as you at- 5. Push the wiper blade until the hook (B) en- tach them. gages securely with the stopper (A). Do not allow the wiper arm to fall onto the window glass; it could damage the glass. 4.
Page 379: General Maintenance
MITSUBISHI MOTORS Au- thorized Service Point for assistance. Additional equipment It is a good idea to carry a shovel or a short-han-...
Page 380: Fusible Links
Maintenance Fusible links Fuses 1. Open the personal box and pull to remove it. E01002900564 E01003002090 The fusible links will melt to prevent a fire if a Fuse block location large current attempts to flow through certain elec- trical systems. To prevent damage to the electrical system due to In case of a melted fusible link, we recommend shortcircuiting or overloading, each individual cir-...
Page 381 Maintenance Passenger compartment (RHD vehicles) 2. Move the rod (A) on the left side of the low- 4. Remove the lower glove box fastener, and er glove box to the left side of the box. then remove the lower glove box. The fuse blocks in the passenger compartment are located behind the lower glove box at the position shown in the illustration.
Page 382 Maintenance Engine compartment Passenger compartment fuse location (LHD) Passenger compartment fuse location (RHD) In the engine compartment, the fuse block is loca- ted as shown in the illustration. Main fuse block Main fuse block Sub fuse block Sub fuse block 1- Push the knob.
Page 383 Maintenance Engine compartment fuse location table Capaci- Capaci- Symbol Electrical system Symbol Electrical system ties ties Engine compartment fuse location Door locks 20 A Heated door mirror 7.5 A Radio 15 A AC power supply 15 A 25 (20) Control unit relay 7.5 A Power seats Interior lamps...
Page 384 Maintenance Some fuses may not be installed on your ve- Sym- Sym- hicle, depending on the vehicle model or spec- Electrical system paci- Electrical system paci- ifications. ties ties The table above shows the main equipment Headlamp Alternator 7.5 A corresponding to each fuse.
Page 385: Replacement Of Lamp Bulbs
Maintenance NOTE 2. Remove the fuse puller (A) from the inside Replacement of lamp bulbs of the fuse box in the engine compartment. If any system does not function but the fuse E01003100488 corresponding to that system is normal, there Before replacing a bulb, ensure the lamp is off.
Page 386 3- Headlamps, low beam: 51 W (HB4) signal lamp (on outside rear-view mirror). 4- Front fog lamps* : 55 W (H11) Contact a MITSUBISHI MOTORS Author- NOTE 5- Position lamps: 5 W (W5W) ized Service Point when there is a need for re-...
Page 387 NOTE *: Front of the vehicle An LED, not a bulb, is used in the centre con- sole down lamp. Contact a MITSUBISHI MOTORS Authorized Service Point when there is a need for repair or replacement. *: Front of the vehicle...
Page 388 Maintenance 4. While holding down the tab (D), pull out the 2. Turn the cap (B) anticlockwise to remove it. socket (E). Headlamps (high-beam, except for ve- *: Front of the vehicle hicles with high intensity discharge headlamps) 5. To install the bulb, perform the removal 3.
Page 389 Maintenance 4. While holding down the tab (D), pull out the Bending lamps (Adaptive Front light- socket (E). ing System (AFS)) (for vehicles equip- ped with high intensity discharge head- lamps) E01008800190 1. When replacing the bulb on the right side of the vehicle in the case of diesel-powered ve- hicles equipped with M/T, remove the bolt (A) holding down the washer tank spout and...
Page 390 Maintenance 2. Turn the cap (B) anticlockwise to remove it. 4. While holding down the tab (D), pull out the bulb (E). Position lamps *: Front of the vehicle E01003700976 1. When replacing the bulb on the left side of the vehicle in the case of 2200 models and 3.
Page 391 Maintenance 2. When replacing the bulb on the right side of 4. Remove the bulb from the socket. 2. Turn the socket (A) anticlockwise and re- the vehicle in the case of diesel-powered ve- move it. hicles equipped with M/T, remove the bolts (B) holding down the reservoir tank and move the reservoir tank.
Page 392 Maintenance Contact a MITSUBISHI MOTORS Authorized 3. While holding down the tab (D), pull out the Service Point when there is a need for repair or re- socket (E). placement. Side turn-signal lamps (on outside rear- view mirror)* E01003900431 NOTE An LED, not a bulb, is used in the side turn- signal lamps (on outside rear-view mirror).
Page 393 Maintenance 2. Remove the cover after you remove each of 4. Remove the socket and bulb assembly (C) to- CAUTION the 4 clips (A) by inserting a screw driver in- gether by turning it anticlockwise and then re- to the clip groove and levering it towards the move the bulb by pulling it out.
Page 394 An LED, not a bulb, is used in the stop lamp/ E01004201223 1. Remove the screws (A), and then remove the tail lamp. Contact MITSUBISHI lamp unit. MOTORS Authorized Service Point when there is a need for repair or replacement. 3. Remove the bulb from the socket. Reversing lamps E01004400286 1.
Page 395 (B) aside and remove the lens. NOTE An LED, not a bulb, is used in the high-moun- ted stop lamp. Contact a MITSUBISHI MOTORS Author- ized Service Point when there is a need for re- pair or replacement. Licence plate lamps E01004600679 1.
Page 396 Maintenance 2. While holding down the tab (A), pull out the Room lamp (rear)/luggage room lamp bulb. E01005300442 1. Insert a minus screwdriver with the end cov- ered with a cloth or other object into the cut out area of the lens to wedge out the lens. Map &...
Page 397 Centre console down lamp E01008700072 NOTE An LED, not a bulb, is used in the centre con- sole down lamp. Contact a MITSUBISHI 3. To install the bulb, perform the removal MOTORS Authorized Service Point when steps in reverse. there is a need for repair or replacement.
Page 399 Specifications Vehicle labeling................9-02 Vehicle dimensions...............9-05 Vehicle performance..............9-07 Vehicle weight................9-08 Engine specifications..............9-15 Electrical system................9-16 Tyres and wheels................9-17 Fuel consumption.................9-18 Refill capacities................9-20...
Page 400: Vehicle Labeling
Specifications Vehicle labeling Please use this number when ordering replacement Vehicle information code plate* parts. The vehicle information code plate is riveted as E01100102844 shown in the illustration. Vehicle identification number The vehicle identification number is stamped on the bulkhead as shown in the illustration. 1- Model code 2- Engine model code, Exterior code...
Page 401 Specifications Please use this number when ordering replacement Vehicle identification number plate 3000 models parts. (RHD vehicles only) The vehicle identification number is stamped on the plate riveted to the left front corner of the instru- ment panel pad. It is visible from outside of the ve- hicle through the windscreen.
Page 402 Specifications For vehicles equipped with Twin Clutch SST *: Front of the vehicle 9-04...
Page 403: Vehicle Dimensions
Specifications Vehicle dimensions E01100202409 Front track 1.540 mm Overall width 1.800 mm Front overhang 990 mm Wheel base 2.670 mm Rear overhang 1.005 mm Overall length 4.665 mm Petrol-powered vehicles 215 mm 185 mm Ground clearance (unladen) Diesel-powered vehicles Twin Clutch SST 176 mm, 180 mm : Vehicles equipped with the high ground clearance suspension 9-05...
Page 404 Specifications Without roof rails 1.680 mm, 1.695 mm Overall height (unladen) With roof rails 1.720 mm, 1.735 mm Rear track 1.540 mm Body 5.75 m Minimum turning radius Wheel 5.3 m : Vehicles equipped with the high ground clearance suspension 9-06...
Page 405: Vehicle Performance
Specifications Vehicle performance E01100302035 Petrol-powered vehicles 184 km/h (114 mph) 2000 models 180 km/h (112 mph) Maximum speed 2400 models 190 km/h (118 mph) 3000 models 200 km/h (124 mph) Diesel-powered vehicles 200 km/h (124 mph), 183 km/h (113 mph) Maximum speed 2200 models Twin Clutch SST...
Page 406: Vehicle Weight
Specifications Vehicle weight E01100404447 Petrol-powered vehicles 2000 models (M/T) Without heavy duty suspension With heavy duty suspension Item M-line H-line M-line H-line 1.425 kg, Without optional parts 1.455 kg 1.445 kg 1.475 kg 1.460 kg Kerb weight 1.514 kg, With full optional parts 1.517 kg 1.534 kg 1.537 kg...
Page 407 Specifications 2000 models (CVT) Without heavy duty sus- With heavy duty suspen- Item pension sion M-line H-line M-line H-line M-line H-line 1.480 kg, Without optional parts 1.485 kg 1.500 kg 1.505 kg 1.560 kg 1.565 kg 1.490 kg Kerb weight 1.547 kg, With full optional parts 1.547 kg...
Page 408 Specifications 2400 models (M/T) 5 persons Item With heavy duty suspension 7 persons Without heavy duty suspension M-line H-line Without optional parts 1.530 kg 1.555 kg 1.550 kg, 1.560 kg 1.585 kg, 1.595 kg Kerb weight With full optional parts 1.592 kg 1.626 kg 1.612 kg, 1.627 kg...
Page 409 Specifications 2400 models (CVT) 5 persons Item 7 persons Without heavy duty suspen- With heavy duty suspension sion 1.560 kg, 1.590 kg Without optional parts 1.540 kg, 1.570 kg 1.615 kg, 1.625 kg 1.590 kg Kerb weight 1.636 kg, 1.667 kg With full optional parts 1.616 kg, 1.637 kg 1.677 kg, 1.692 kg...
Page 410 Specifications Front 1.150 kg Maximum axle weight Rear 1.300 kg, 1.440 kg With brake 1.600 kg Maximum towable weight Without brake 750 kg Maximum trailer-nose weight 80 kg Maximum roof load 80 kg Seating capacity 5 persons : In case of trailer towing NOTE Trailer specifications indicate the manufacturer’s recommendation.
Page 411 Specifications 5 persons 7 persons Without heavy duty suspen- With heavy duty suspension Item sion With brake 2.000 kg Maximum towable weight Without brake 750 kg Maximum trailer-nose weight 100 kg Maximum roof load 80 kg : H-line : In case of trailer towing NOTE Trailer specifications indicate the manufacturer’s recommendation.
Page 412 Specifications NOTE Trailer specifications indicate the manufacturer’s recommendation. 9-14...
Page 413: Engine Specifications
Specifications Engine specifications E01100602403 Petrol-powered vehicles Item 2000 models 2400 models 3000 models Engine model 4B11 4B12 6B31 No. of cylinders 4 in line 4 in line 6-V (60°) Total displacement 1.998 cc 2.360 cc 2.998 cc Bore 86.0 mm 88.0 mm 87.6 mm Stroke...
Page 414: Electrical System
Specifications Electrical system E01100802173 Petrol-powered vehicles 2400 models Diesel-powered Item vehicles 2000 models 3000 models Except for Clear Clear Tec FFV Tec FFV models models Voltage 12 V Type (JIS) 75D23L 80D26L 95D31L, T-105 Battery Capacity (5HR) 52 Ah 55 Ah 64 Ah, 73 Ah Alternator capacity 120 A...
Page 415: Tyres And Wheels
Tyres and wheels E01100902712 Tyre 215/70R16 100H 225/55R18 97H, 225/55R18 98V, P225/55R18 97H Size 16x6 1/2 JJ 18x7 J Wheel Offset 38 mm NOTE Contact your MITSUBISHI MOTORS Authorized Service Point for details on the combination used on your vehicle. 9-17...
Page 416: Fuel Consumption
Specifications Fuel consumption E01101100603 Petrol-powered vehicles Combined Urban conditions Extra-urban conditions Item Fuel consumption Fuel consumption Fuel consumption (g/km) (L/100 km) (L/100 km) (L/100 km) 178, 192 7.7, 8.1 10.0, 10.5 6.4, 6.8 2000 models 179, 188 7.7, 8.1 9.9, 10.3 6.4, 6.8 10.6 5 persons...
Page 417 Specifications Diesel-powered vehicles Combined Urban conditions Extra-urban conditions Item Fuel consumption Fuel consumption Fuel consumption (g/km) (L/100 km) (L/100 km) (L/100 km) 5 persons 159, 155 6.0, 5.8 7.5, 7.1 7 persons 162, 159 6.1, 6.0 7.6, 7.3 2200 models 5 persons 7 persons Twin Clutch SST...
Page 418: Refill Capacities
Specifications Refill capacities E01101303505 Petrol-powered vehicles 2000 models, 2400 models 3000 models 9-20...
Page 419 Specifications Diesel-powered vehicles Except for vehicles equipped with Twin Clutch SST Vehicles equipped with Twin Clutch SST 9-21...
Page 420 Brake fluid DOT 3 or As required DOT 4 Clutch fluid Washer fluid 4.5 litres — Genuine MITSUBISHI Power Steering Fluid or Power steering fluid As required ATF DEXRON III/DEX- RON II : if so equipped : similar high quality ethylene glycol based non-silicate, non-amine, non-nitrate and non-borate coolant with long life hybrid organic acid technology...
Page 421 Specifications Item Quantity Lubricants 2000 models DIA QUEEN SUPER 7.5 litres Petrol-powered vehicles [includes 2400 models LONG LIFE COOL- 0.65 litre in the reserve tank] ANT PREMIUM or 3000 models 9.5 litres equivalent Engine coolant 8.3 litres Diesel-powered vehicles [includes BASF Glysantin Alu Pro- 2200 models Twin Clutch...
Page 423 Alphabetical index To listen to a disc in the rear-seat display 5-53 Central door locks 1-28 Auto Stop & Go (AS&G) system 4-19 Charge warning lamp 3-39 Automatic transmission Check engine warning lamp 3-38 Fluid 9-20 Child restraint 2-23 4-wheel drive operation 4-48 Selector lever operation 4-25,4-30 Child-protection rear doors 1-31 Selector lever position 4-26...
Page 424 Alphabetical index Electrical system 9-16 Front room lamp 5-85 Heated seats 2-08 Electronic immobilizer (Anti-theft starting sys- Bulb capacity 8-25 High-mounted stop lamp tem) 1-03 Replacement 8-34 Replacement 8-33 Electronically controlled 4WD system 4-46 Front seat 2-05 Hill start assist 4-52 Emergency starting 6-02 Front turn-signal lamps Hinges and latches lubrication 8-17...
Page 425 Alphabetical index Replacement 8-33 Refill capacities 9-20 Link System 5-64 Removal of water from the fuel filter 6-06 Lubricants 9-20 Replacement of lamp bulbs 8-23 Luggage hooks 5-94 Reversing lamps Parking 4-08 Luggage room lamp 5-87 Bulb capacity 8-24 Parking brake 4-07 Bulb capacity 8-25 Replacement 8-32 Parking brake break-in 8-15...
Page 426 Alphabetical index Starting 1-16,1-20 Gearshift lever 4-36 Fluid 8-08,9-20 Steering Gearshift lever position display 4-38 Switch 3-51,3-55 Power steering fluid 8-09,9-20 Gearshift lever positions 4-38 Washing 7-03 Power steering system 4-57 Manual shift 4-40 Waxing 7-04 Steering wheel height adjustment 4-09 Tyres 8-11 Weatherstripping 8-17 Steering wheel lock 1-16,1-20,4-14...

Mitsubishi OUTLANDER Owner's Manual

General Information

Locking and Unlocking

Seats and Seat Belts

Table of Contents

Table of Contents

Table of Contents

For Emergencies

Maintenance

Quick Links

Chapters

Related Manuals for Mitsubishi OUTLANDER

Summary of Contents for Mitsubishi OUTLANDER

Table of Contents
