Item 41293
Assembly and Operating Instructions
©
Copyright 2003 by Harbor Freight Tools
artwork contained herein may be reproduced in any shape or form without the express written
consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353.
Thank you for choosing a Harbor Freight Tools product. For future reference, please complete the
owner's record below:
Model:____________________
Save the receipt, warranty and these instructions. It is important that you read this entire instruc-
tion sheet to become familiar with the unit before you begin using it.
Height:
Wheel Diameter: 22-3/4"
Weight:
Warning:
1. Read this instruction sheet completely before assembly or use of the Windmill.
2. Always wear ANSI approved safety goggles when working with tools and equipment.
3. Plan to locate the Windmill on a flat, level area. Installation of the Windmill should be in a
location where small children are either restricted or supervised. Never allow children to
climb on the Windmill.
4. The Windmill is for decorative purposes only. This unit is not designed for any other use.
Assembly of the Windmill:
Contents of the box is shown below with part numbers noted. Lay out all pieces on a flat working
surface. Check to make sure all parts are included and in good condition. Note: During initial
assembly, all screws and nuts should be installed only finger tight. Once the unit is fully as-
sembled, tighten down all screws and nuts.
Contents of Box Qty
Wheel (#1) 1
Shaft (#2A) 1
Rudder Extension (#2B) 2
Rudder (#2C) 1
Mast Head (#3) 1
Platform (#4) 1
Windmill
3491 Mission Oaks Blvd., Camarillo, CA 93011
®
. All rights reserved. No portion of this manual or any
Specifications
97-1/2" Base Dimensions:
Length of Ground Stakes: 15-1/2"
44 Lbs.
Contents of Box
Upper Leg Section (#5A)
Middle Leg Section (#5B)
Lower Leg Section (#5C)
Diagonal Brace (#6)
Upper Brace (#7)
Lower Brace (#8)
®
Purchase Date:______________________
Qty Contents of Box
4 Ground Stakes (#9)
4 Hardware Package *
4 *Includes:
16 2 Flat Washers - 1/2"
4 2 Cotter Pins
4 42 Screws 3/16" - 24 x 5/8"
42 Nuts 3/16" - 24
26-3/4" Square
Qty
4
1 Bag
