- Page 1 Cybex Personal Entertainment Monitor Model CP-20794 Owner’s Manual Cardiovascular Systems Part Number LT-20889 Rev A www.cybexinternational.com...
- Page 3 Cybex logo are registered trademarks of Cybex International, Inc. DISCLAIMER: Cybex International, Inc. makes no representations or warranties regarding the contents of this manual. We reserve the right to revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such revisions or changes.
-
Page 5: Table Of Contents
Table of Contents Front Pages Table of Contents........ i 1 Safety Safety Notice Items ......1-1 Important Safety Instructions..... 1-2 2 Technical Specifications Specifications ........2-1 3 Operation Remote Control ........3-1 Installing the Remote Control Batteries 3-1 Using the Remote Control ....3-1 Using the Television ...... - Page 6 This page intentionally left blank...
-
Page 7: Safety Notice Items
1-1 – Safety Notice Items IMPORTANT INFORMATION WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER. -
Page 8: Important Safety Instructions
1-2 – IMPORTANT SAFTEY INSTRUCTIONS Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with safety being the highest priority. However, improper use can result in personal injury and / or property damage. Read these instructions. -
Page 9: Technical Specifications
2 – Technical Specifications Specifications Screen Type: TFT-LCD. Screen Size: 15” (38 cm) (diagonal) 4:3 format. Width: 14.5” (37 cm). Height: 13.5” (34 cm). Depth: 2.0” (5 cm). Weight of Product: 7.9 lbs. (3.6 kg). Shipping Weight: 9.25 lbs. (4.2 kg). Console Features: Power/Standby status LED, Power/Standby button. - Page 10 This page intentionally left blank...
-
Page 11: Operation
3 -- - Operation REMOTE CONTROL Installing the Remote Control Batteries Remove the battery cover from the remote control and install 2 x AAA size batteries (provided) inside the compartment. The diagram inside the battery compartment shows the correct way to install the batteries. Using the Remote Control To use the remote control, point it towards the sensor located on the front bottom of the monitor. - Page 12 Input – Press to change the input source. Choices are: RF or Composite. PMODE - Press to cycle through Picture Modes. Choices are: User, Standard, Vivid or Bright. SMODE - Press to cycle through Sound Modes. Choices are: User, Voice, Concert or Jazz. SLEEP - Set timer to activate sleep mode.
-
Page 13: Using The Television
Using the Television Switching On The monitor will turn on automatically when you start using the fitness equipment. The power indicator LED will change from RED to GREEN when “on”. The monitor can also be turned on using the remote control. NOTE: When you stop using the fitness equipment, the monitor will shut off when the fitness equipment shuts down. -
Page 14: Picture Menu
Picture Menu In the Picture Menu you can adjust the Picture Mode, Contrast. Brightness, Sharpness, Color, Tint, Aspect Ratio and access the Hotel Menu. Picture Mode Select the Picture Mode. Choices are User, Standard, Vivid or Bright. Contrast Increase or decrease the Contrast. (Available only in User Mode). Brightness Increase or decrease the Brightness. -
Page 15: Hotel Menu
Hotel Menu In the Hotel Menu you can set the default channel settings to be used at power up. Settings include Password, Source Set, Channel Set, Input and Output. NOTE: The Hotel Menu can only be accessed by entering the password. Password Set Set or reset the password used to access the Hotel Menu. -
Page 16: Audio Menu
Audio Menu In the Audio Menu you can adjust the Audio Mode, Audio Language, Bass, Treble and Balance. Audio Mode Set the Audio Mode. Choices are User, Voice, Concert or Jazz. Audio Language Set the Audio Language. Subject to availability from the Broadcaster or Cable Company. Bass Increase or decrease the Bass. -
Page 17: Preventative Maintenance
4 -- - Preventative Maintenance CARING FOR YOUR PRODUCT Cleaning 1. Switch off your monitor and unplug it from the wall socket. 2. As needed, dust off the panel with a soft dry cloth. The screen can be cleaned with computer screen wipes or other non abrasive, moist, disposable wipes, such as “Gym Wipes”. - Page 18 This page intentionally left blank...
-
Page 19: Set Up And Assembly
5 -- - Set Up and Assembly NOTE: The monitor must be installed on a Cybex mounting bracket. See installation instructions that came with your product. 1. Read and understand all instructions thoroughly before setting up the monitor. NOTE: Each step number in the assembly instructions tells you what you will be doing. The lettered steps following each step number describe the procedure required. -
Page 20: Install Monitor
WARNING: To prevent injury, this apparatus must be securely attached to the mounting bracket in accordance with these installation instructions. NOTE: The monitor must be installed on a Cybex mounting bracket. See installation instructions that came with your product for detailed installation instructions. -
Page 21: Setup Menu
Setup Menu In the setup menu you adjust the TV settings for first time use. Tuning Band Select Tuning Band. Choices are Air, Cable STD, Cable HRC, Cable IRC or Cable Auto. DTV Signal Displays signal strength. Auto Ch Search Auto search the NTSC and ATSC TV signals. -
Page 22: Feature Menu
Feature Menu In the Feature Menu you can adjust the following. Time Set, Sleep Timer, Advanced Video Menu, Password Set, Parental Control, NTSC CC, ATSC CC and Digital Closed Caption. Time Set Set the Time Zone, Year, Date and Time Sleep Timer Set the Sleep Timer. -
Page 23: Customer Service
Hours of phone service are Monday through Friday from 8:00 a.m. to 6:00 p.m. Eastern Standard Time. For Cybex customers living in the USA, contact Cybex Customer Service at 888-462-9239. For Cybex customers living outside the USA, contact Cybex Customer Service at 508-533-4300 or fax 508-533-5183. -
Page 24: Troubleshooting
Troubleshooting PLEASE READ AND FOLLOW THE SAFETY INSTRUCTIONS IN CHAPTER 1 OF THIS MANUAL BEFORE ATTEMPTING ANY MAINTENANCE. No Power • Check to make sure that the AC Plug is properly plugged into the AC socket. • Check to make sure that the AC Plug is properly plugged into the AC adaptor. •...
