Toastmaster TC21D3663 Specifications

Conveyor Toaster
TC21D
Standard Features:
• 10" wide conveyor belt
• Automatic cool-down feature
• Energy-saving standby mode
• Stainless steel exterior construction
• Air-cooled case construction
• Single-piece stainless steel crumb tray
• Damage resistant calrod heating elements
• All models toast bread, buns and bagels
• Convection air dries product faster
• Large, easy-to-operate dial controls
• Separate upper and lower heat
• Settings and conveyor belt speed
• High volume (900 slices per hour)
• Factory installed NEMA cord and plug
Featuring a 3" loading height to
accommodate a variety of product
thicknesses
Application:
TC21D Series Conveyor Toasters are
designed to uniformly toast breads,
buns, bagels, and muffins in large
quantities, using continuous feed
methods.
General Information:
Product Height:
• Extra-Tall 3" (76mm) high opening.
Conveyor Type:
• TC21D3 - Conveyor extends to
the end of the toasting chamber.
Product Loading:
• TC21D3 is equipped with a
loading rack that is angled to
feed the product into the
toaster continuously.
Product Delivery:
• TC21D3's are capable of rear-
exit pass through operation.
They are shipped as front-return
models, but can easily be
converted to rear-exit operation.
by following the supplied
instructions.
Toastmaster
Toll Free: 1-800-264-7827 • Telephone: 1-314-781-2777 • Toll Free Fax: 1-800-264-6666 • Fax: 314-781-3636
Safety:
Unique air flow design keeps case,
top, and sides cool. The unit is
equipped with an auto cool down
feature which allows the fan to cool
the outer skin when the unit is
turned off.
Construction:
Steel construction with a stainless
steel finish is used for durability. A
stainless steel full-length, slide out
crumb tray for easy clean-up. A
fiberglass return tray is included.
Electrical:
Available in 208V or 240V, 1-phase
only. Total rated input is 2.9 KW.
A factory installed 6 foot (1.8m)
cord is included.
®
10 Sunnen Dr. St. Louis, MO 63143• www.toastmastercorp.com
Foodservice Equipment
Job Item#
Models shown may ship UPS
Heating:
When control is set to "ON", top
and bottom tubular elements will
turn on to toast both sides of bread.
Lightness and darkness of the
product is achieved by adjusting the
top and bottom heat controls.
Standby position allows for energy
savings during non-peak periods.
Controls:
Rotary 3-position dial selects
ON / OFF/ STANDBY positions.
A conveyor speed dial controls the
belt speed. Heat dials control the
upper and lower heating elements.
Accessories:
• Fiberglass return tray.
• Angled loading rack.
(Supplied with TC21D3)
• Horizontal loading rack (optional)
• Stainless steel tray (optional)
fits models as an exit tray.
Warranty:
Warranty includes one year parts
and labor, on-site service. (USA
only) Call factory for warranty
authorization.
TC21D
