BrioConnect™ Gateway
Quick Start Guide
Rev. 1.1
04/04/2018

Advertisement

Table of Contents
loading

Related Manuals for Briowireless BrioConnect

Summary of Contents for Briowireless BrioConnect

  • Page 1 BrioConnect™ Gateway Quick Start Guide Rev. 1.1 04/04/2018...

  • Page 2: Table Of Contents

    Initial setup ............................6 Device configuration ..........................9 4.1. Configure the APN using the local web interface ................. 9 4.2. Device registration on the cloud ....................12 LED ..............................14 Support..............................15 www.briowireless.com Copyright © 2018 Briowireless Inc. All rights reserved.

  • Page 3: Document Revision History

    BrioConnect™ Gateway – Quick Start Guide 1. Document revision history Revision Date Comments 2018-04-02 First release 2018-04-04 Minor update www.briowireless.com Copyright © 2018 Briowireless Inc. All rights reserved.

  • Page 4: Overview

    The purpose of this document is to get the user up and running as quick as possible. Please refer to the complete User Manuel for more details on the product. The pictures below show both the front and back panels of the BrioConnect™ device. Diversity antenna...

  • Page 5: Package Contents

    BrioConnect™ Gateway – Quick Start Guide 2.1. Package Contents BrioConnect™ device ships with the following content: BrioConnect™ Gateway • Mounting bracket • Antennas (x2) • Power Adapter • Figure 2-3. BrioConnect™ accessory kit www.briowireless.com Copyright © 2018 Briowireless Inc. All rights reserved.

  • Page 6: Initial Setup

    BrioConnect™ Gateway – Quick Start Guide 3. Initial setup 1. Close the WiFi of the laptop. 2. Connect a regular Ethernet cable (not crossover) from the Brioconnect™ to a laptop. To the laptop Figure 3-1. Ethernet connection 3. Insert the 3FF Micro-SIM Card with the contacts facing up as shown below. A “click” will be felt when the SIM card has been fully inserted.
  • Page 7 4. Connect antennas to the device. Diversity antenna Main (some models) antenna Figure 3-3. Antennas installation 5. Power on the BrioConnect™ using the supplied power supply Power supply adapter Figure 3-4. Powering the device www.briowireless.com Copyright © 2018 Briowireless Inc. All rights reserved.
  • Page 8 6. Wait about 2 minutes for the unit to boot and to receive an IP address from the DHCP server. The STAT LED will turn green when the boot is finish. STAT LED: Orange (booting up) Green (CPU running) Figure 3-5. Led indicators www.briowireless.com Copyright © 2018 Briowireless Inc. All rights reserved.

  • Page 9: Device Configuration

    This section walks the user through connecting the gateway for the first time. The initial configuration of the BrioConnect™ unit will be done locally using the web page interface. Later on, it will be possible to manage the device remotely via a cloud-based device management platform provided freely by Briowireless.
  • Page 10 BrioConnect™ Gateway – Quick Start Guide The browser may show a warning indicating that the brioconnect.io is not secure due to a problem in the verification of the certificate issuer's authority. The figure below shows a warning message on Chrome web browser.
  • Page 11 BrioConnect™ Gateway – Quick Start Guide 2- An APN needs to be configured to allow the BrioConnect™ to register to the cellular network. On the local web interface, click on the Mobile Setting sub menu and enter the APN in the Access Point Name field as shown in the following screen.

  • Page 12: Device Registration On The Cloud

    Briowireless Cloud is a free solution that allows users to access, control and maintain their devices from a remote location. For the BrioConnect™ device to be used with the cloud, it needs to be registered with the user’s account. The device doesn’t necessarily need to be connected to cellular during the registration process.
  • Page 13 3- The user information including an email and a password needs to be entered. The association of the BrioConnect™ with the user’s account is made through the unit serial number (SN) and product key that are printed on a label attached on the back of the unit. The following is an example of a label.

  • Page 14: Led

    LINK There is no cellular connection, or in case of connection error. Twice periodically 2G cellular access Flashing 3 times periodically 3G Cellular access 4 times periodically 4G (LTE) Cellular access www.briowireless.com Copyright © 2018 Briowireless Inc. All rights reserved.

  • Page 15: Support

    BrioConnect™ Gateway – Quick Start Guide 6. Support support@briowireless.com For online support or to download the latest version of this document, go to: https://briowireless.com/product/BrioConnect-gateway/ www.briowireless.com Copyright © 2018 Briowireless Inc. All rights reserved.
