Operating instructions.
1. Open the LCD display box, insert 4 AA batteries into the battery pack.
2. Open the battery door of each weighing pad, and insert 2 AA batteries into the
battery pack.
3. Power on each weighing pad by switching the small switch from '0' to '1' near the
handle of each pad.
4. The LED light next to the pad's handle should light up. If it looks dim or does not
light up, replace with 2 new AA batteries.
5. Make sure that the correct pad is positioned in front of the corresponding wheel: FR,
FL, RR, and RL - Front Right, Front Left, Rear Right, and Rear Left. The handle of
each weighing pad should be facing outward toward the side of the car.
LCD display format
Backlighting
Using the LCD Display
Display box battery level
indicator
ON/OFF
Tare
Function
