Thule 109 Mounting & Installation

Acura Integra, 4-dr, 90–93
Honda Integra, 4-dr, 90–93
Open door and gently pull down the rubber weather stripping.
Locate the protruding indicator marking found on the metal
strip.
Bracket mounts into the seam behind the black molding that
runs along the edge of the roof. Lining the bracket up with the
indicator markings, firmly press the bracket down into the seam
until it is seated all the way down into the channel. Repeat this
procedure to locate the other three mounting points.
IMPORTANT: REMEMBER TO FASTEN THE WEATHER STRIP
BACK IN PLACE AFTER FITTING THE LOAD CARRIER! *As
the distance between the load bars is short, ski boxes and
surfboards should not be fitted.
Honda Prelude 92–
Screw the load carrier into
position alternating
between the feet, and
maintaining constant
pressure on the bracket.
Thule System Kit 109
M A X
LOAD
75 Kg
Screw the load carrier into
position alternating
between the feet, and
maintaining constant
pressure on the bracket.
M A X
LOAD
60 Kg
111
22
/ 501-0109-07
350•3DF6
111
22
X= 275 mm
10 3 / inch
X
4
Front
856 mm / 33
910 mm / 35
111
*
300 mm
7
11 / inch
200 mm
8
7 7 / inch
8
IMPORTANT! As the distance between
the load bars is short, ski boxes and
surfboards should not be fitted.
111
*
500 mm
19 3 / inch
4
mm/inch
Rear
5 1
/ inch 846 mm / 33 / inch
8 4
mm/inch
7
/ inch
8
22
*
300 mm
11 7 / inch
8
22
