USER AND MAINTENANCE BOOK
USER AND MAINTENANCE BOOK
LIBRETTO USO E MANUTENZIONE
LIBRETTO USO E MANUTENZIONE
BEDIENUNGS- UND WARTUNGSANLEITUNG
BEDIENUNGS- UND WARTUNGSANLEITUNG
MANUAL DE INSTRUCCIONES PARA EL USO Y MANTENIMIENTO
MANUAL DE INSTRUCCIONES PARA EL USO Y MANTENIMIENTO
MANUEL D'UTILISATION ET DE MAINTENANCE
MANUEL D'UTILISATION ET DE MAINTENANCE
HANDLEIDING VOOR GEBRUIK EN ONDERHOUD
MANUAL DE USO E MANUTENÇÃO
VEJLEDNING OM BRUG OG VEDLIGEHOLDELSE
HEFTE FOR BRUK OG VEDLIKEHOLD
ANVÄNDAR- OCH UNDERHÅLLSHANDBOK
INSTRUKCJA OBSŁUGI I KONSERWACJI
INSTRUKCJA OBSŁUGI I KONSERWACJI
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ И ТЕХНИЧЕСКОМУ ОБСЛУЖИВАНИЮ
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ И ТЕХНИЧЕСКОМУ ОБСЛУЖИВАНИЮ
PŘÍRUČKA PRO POUŽITÍ A ÚDRŽBU
HASZNÁLATI ÉS KARBANTARTÁSI KÉZIKÖNYV
HASZNÁLATI ÉS KARBANTARTÁSI KÉZIKÖNYV
PRIROČNIK Z NAVODILI ZA UPORABO IN VZDRŽEVANJE
KULLANIM VE BAKIM K
KNJIŽICA O UPORABI I ODRŽAVANJU
NAUDOJIMO IR PRIEŽIŪROS KNYGELĖ
LIETOŠANAS UN TEHNISKĀS APKOPES GRĀMATIŅA
KASUTUS- JA HOOLDUSJUHEND
MANUAL DE UTILIZARE ŞI ÎNTREŢINERE
PRÍRUČKA PRE POUŽITIE A ÚDRŽBU
PRÍRUČKA PRE POUŽITIE A ÚDRŽBU
НАРЪЧНИК ЗА ИЗПОЛЗВАНЕ И ПОДДРЪЖКА
НАРЪЧНИК ЗА ИЗПОЛЗВАНЕ И ПОДДРЪЖКА
КЕРІВНИЦТВО З ЕКСПЛУАТАЦІЇ Й ТЕХНІЧНОГО ОБСЛУГОВУВАННЯ
KNJIŽICOM O UPOTREBI I ODRŽAVANJU
ΕΓΧΕΙΡΙΔΙΟ ΧΡΗΣΗΣ ΚΑΙ ΣΥΝΤΗΡΗΣΗΣ
KÄYTTÖ- JA HUOLTO-OHJE
i
TAPÇIĞI
使用和维护手册
使用和维护手册
CF 75
CF 75A
en
en
it
it
de
de
es
es
fr
fr
nl
pt
da
fi
no
sv
pl
pl
ru
ru
cs
hu
hu
sl
tr
hr
lt
lv
et
ro
sk
sk
bg
bg
uk
bs
el
zh
zh
Advertisement
Related Manuals for Master CF 75
Summary of Contents for Master CF 75
- Page 1 PRÍRUČKA PRE POUŽITIE A ÚDRŽBU PRÍRUČKA PRE POUŽITIE A ÚDRŽBU НАРЪЧНИК ЗА ИЗПОЛЗВАНЕ И ПОДДРЪЖКА НАРЪЧНИК ЗА ИЗПОЛЗВАНЕ И ПОДДРЪЖКА КЕРІВНИЦТВО З ЕКСПЛУАТАЦІЇ Й ТЕХНІЧНОГО ОБСЛУГОВУВАННЯ KNJIŽICOM O UPOTREBI I ODRŽAVANJU ΕΓΧΕΙΡΙΔΙΟ ΧΡΗΣΗΣ ΚΑΙ ΣΥΝΤΗΡΗΣΗΣ 使用和维护手册 使用和维护手册 CF 75 CF 75A...
- Page 2 IMPORTANT SETUP: ⌀ ½“ - ¾” N.G.: 7 mbar L.P.G.: 20 mbar RIGID Pression setting TUBE suggest: 30÷50 mbar ⌀ > 15 mm GAS REGULATOR Gas flow > 10 m Gas flow < 0,8 m < 0,8 m IMPORTANT ►en - STRICTLY COMPLY WITH ALL THE INDICATIONS IN THIS LABEL IN ORDER TO OBTAIN THE CORRECT OPERATION OF THE HEATER.
- Page 3 Vers. CE TECHNICAL DATA - DATI TECNICI - TECHNISCHE DATEN - DATOS TÉC- NICOS - DONNÉES TECHNIQUES - TECHNISCHE GEGEVENS - DADOS TÉCNICOS - TEKNISKE DATA - TEKNISET TIEDOT - TEKNISKE DATA - TEKNISKA DATA - DANE TECHNICZNE - ТЕХНИЧЕСКИЕ ДАННЫЕ - TECHNICKÉ...
- Page 4 Vers. NO CE TECHNICAL DATA - DATI TECNICI - TECHNISCHE DATEN - DATOS TÉC- NICOS - DONNÉES TECHNIQUES - TECHNISCHE GEGEVENS - DADOS TÉCNICOS - TEKNISKE DATA - TEKNISET TIEDOT - TEKNISKE DATA - TEKNISKA DATA - DANE TECHNICZNE - ТЕХНИЧЕСКИЕ ДАННЫЕ - TECHNICKÉ...
- Page 5 PICTURES - FIGURE - ABBILDUNGEN - FIGURAS - FIGURES - FIGUREN - FIGURAS - FIGURER - KUVAT - FIGURER - FIGURER - ILUSTRACJE - ИЛЛЮСТРАЦИИ - OBRÁZKY - ÁBRÁK - SLIKE - ŞEKİLLER - SLIKE - ILIUSTRACIJOS - ATTĒLI - JOONISED - IMAGINI - OBRÁZKY - СХЕМИ - МАЛЮНКИ...
- Page 6 PICTURES - FIGURE - ABBILDUNGEN - FIGURAS - FIGURES - FIGUREN - FIGURAS - FIGURER - KUVAT - FIGURER - FIGURER - ILUSTRACJE - ИЛЛЮСТРАЦИИ - OBRÁZKY - ÁBRÁK - SLIKE - ŞEKİLLER - SLIKE - ILIUSTRACIJOS - ATTĒLI - JOONISED - IMAGINI - OBRÁZKY - СХЕМИ - МАЛЮНКИ...
- Page 7 PICTURES - FIGURE - ABBILDUNGEN - FIGURAS - FIGURES - FIGUREN - FIGURAS - FIGURER - KUVAT - FIGURER - FIGURER - ILUSTRACJE - ИЛЛЮСТРАЦИИ - OBRÁZKY - ÁBRÁK - SLIKE - ŞEKİLLER - SLIKE - ILIUSTRACIJOS - ATTĒLI - JOONISED - IMAGINI - OBRÁZKY - СХЕМИ - МАЛЮНКИ...
- Page 8 PICTURES - FIGURE - ABBILDUNGEN - FIGURAS - FIGURES - FIGUREN - FIGURAS - FIGURER - KUVAT - FIGURER - FIGURER - ILUSTRACJE - ИЛЛЮСТРАЦИИ - OBRÁZKY - ÁBRÁK - SLIKE - ŞEKİLLER - SLIKE - ILIUSTRACIJOS - ATTĒLI - JOONISED - IMAGINI - OBRÁZKY - СХЕМИ - МАЛЮНКИ...
- Page 9 PICTURES - FIGURE - ABBILDUNGEN - FIGURAS - FIGURES - FIGUREN - FIGURAS - FIGURER - KUVAT - FIGURER - FIGURER - ILUSTRACJE - ИЛЛЮСТРАЦИИ - OBRÁZKY - ÁBRÁK - SLIKE - ŞEKİLLER - SLIKE - ILIUSTRACIJOS - ATTĒLI - JOONISED - IMAGINI - OBRÁZKY - СХЕМИ - МАЛЮНКИ...
- Page 10 PICTURES - FIGURE - ABBILDUNGEN - FIGURAS - FIGURES - FIGUREN - FIGURAS - FIGURER - KUVAT - FIGURER - FIGURER - ILUSTRACJE - ИЛЛЮСТРАЦИИ - OBRÁZKY - ÁBRÁK - SLIKE - ŞEKİLLER - SLIKE - ILIUSTRACIJOS - ATTĒLI - JOONISED - IMAGINI - OBRÁZKY - СХЕМИ - МАЛЮНКИ...
- Page 11 PARAGRAPH SUMMARY 1... DESCRIPTION 2... WARNINGS 3... UNPACKING 4... HANDLING 5... POSITIONING 6... CONNECTION TO THE GAS MAINS 7... CONNECTION TO THE ELECTRICITY MAINS 8... CONVERSION TO ANOTHER TYPE OF GAS 9... TYPE OF FUEL 10... SWITCH-ON 11... FAULT LIGHT 12...
- Page 12 tion manual is damaged or lost, please ••2.5. IMPORTANT: Improper use of request a duplicate from the authorised this heater can cause damage, injuries, technical support centre. burns, explosions, electric shock or endanger life. The first symptoms of suffocation by carbon monoxide are similar to those of flu with headache, ►►2.WARNINGS light-headedness...
- Page 13 ••2.16.The appliance must only be (maintenance, repairs, etc.) must be carried out by the authorised technical used as a hot air heater (heating mode) support centre to prevent any risks. or fan (ventilation mode). Follow these instructions scrupulously. ••2.9. IMPORTANT: The heater does ••2.17.Only use fuel, gas pressure val- not have gas regulators or pipes to ues, voltage and electrical frequency...
- Page 14 the heater is in operation or when it is ing properly at least once a year and/ powered on and not in operation. or as required. ••2.26.If you smell gas, switch the heater off immediately, stop the gas supply, disconnect the heater from the ►►3.UNPACKING electricity mains, provide fresh air by opening doors and windows and then...
- Page 15 ►►5.POSITIONING (Fig. 1) withstand a minimum weight of 200 kg. READ THE WARNINGS CAREFULLY There must be a positive angle between AND FOLLOW THE RECOMMENDA- the chains and a value that can ensure TIONS CONTAINED IN THIS INSTRUC- stability, in order to prevent dangerous os- TION MANUAL BEFORE AND DURING cillations.
- Page 16 ed on the data plate in order to prevent necessary to verify its perfect connection serious damage to the heater. of the grounding. The gas regulator must be installed out- side the building that needs to be heated We recommend using a 1,5 mm² (AWG and must guarantee a supply at a pres- 16) H07 type cable with length not exceed- sure in line with national regulations and...
- Page 17 it on the heater. Here below are the steps (Fig. 14). THIS COLLAR IS ONLY for the conversion to another combustible REQUIRED FOR G20-G25 GAS TYPES. gas: ►8.4.ADJUST THE OUTLET ►8.1.REMOVE THE VALVE AND PRESSURE FROM THE GAS VALVE NOZZLE SUPPORT CONNECTION CAUTION: THE ADJUSTMENT MUST PIPE, REMOVE THE NOZZLE CONDUCTED...
-
Page 18: Warning Light
completing the gas conversion, you will The heater can operate either in ventilation need to make sure the fittings and gas or heating mode. To start the ventilating pipe are firmly attached. mode, set the button to the “FAN” position •8.4.6.When the gas conversion has (Fig. -
Page 19: Cleaning The Heater
►►15.PUTTING THE HEATER REQUIRED TO COMPLETELY ISOLATE OUT OF SERVICE THE HEATER FROM THE MAINS POW- ER NETWORK (Fig. 24). If the heater is not used on the medium/ long term, disconnected it from the elec- tricity mains (Fig. 24) and protect it from humidity and dust. -
Page 20: Troubleshooting Faults
►►17.TROUBLESHOOTING FAULTS CAUSES SOLUTIONS The heater No voltage 1.Check the mains system doesn't work 2.Check the electrical connections 3.Authorised technical support centre Incorrect connection of 1.Connect the room thermostat correctly the room thermostat The heater Tripped room 1.Set the room thermostat at a temperature doesn't work in thermostat (optional lower than the room thermostat... - Page 21 ELECTRIC SYSTEM - IMPIANTO ELETTRICO - ELEKTRISCHE ANLAGE - INSTALACIÓN ELÉCTRICA - INSTALLATION ELECTRIQUE - ELEKTRI- SCHE INSTALLATIE - SISTEMA ELÉTRICO - EL-ANLÆG - SÄHKÖLAIT- TEISTO - ELEKTRISK ANLEGG - ELANORDNING - INSTALACJA ELEKTRYCZNA - ЭЛЕКТРОПРОВОДКА - ELEKTRICKÉ ZAŘÍZENÍ - ELEKT- ROMOS RENDSZER - ELEKTRIČNA NAPELJAVA - ELEKTRİK TESİSATI - ELEKTRIČNI UREĐAJ - ELEKTROS SISTEMA - ELEKTRISKĀ...
- Page 22 Switch - Interruttore - Schalter - Interruptor - Interrupteur - Schakelaar - Interruptor - Afbryder - Katkaisin - Bryter - Brytare - Włącznik - Включатель - Vypínač - Kapcsoló - Stikalo - Açma kapama düğmesi - Prekidač - Jungiklis - Slēdzis - Lüliti - Întrerupător - Vypínač - Прекъсвач - Вимикач - Prekidač...
- Page 23 GAS PLANT - IMPIANTO GAS - GASANLAGE - INSTALACIÓN DE GAS - SYSTÈME À GAZ - GASINSTALLATIE - SISTEMA DO GÁS - GAS-ANLÆG - KAASULAITTEISTO - GASSANLEGG - GASANORDNING - INSTALACJA GAZOWA - ГАЗОВАЯ СИСТЕМА - PLYNOVÉ ZAŘÍZENÍ - GÁZ HÁLÓZAT - PLINSKI SISTEM - GAZ TESİSATI - UREĐAJ NA PLIN - DUJŲ...
- Page 24 Gas inlet fitting - Raccordo entrata gas - Anschluss Gaszufuhr - Racor de entrada del gas - Raccord entrée gaz - Koppeling gasingang - Ligação da entrada de gás - Gastilførselssamling - Kaasun sisäänmenoliitos -Kobling gassinnløp - Kopplingsrör gasinlopp - Wlot gazu złączka - Вход газа ниппель...
- Page 25 ELECTRODES REGULATION - REGOLAZIONE ELETTRODI - REGULIE- RUNG DER ELEKTRODEN - REGULACIÓN DE LOS ELECTRODOS - REGU- LATION DES ELECTRODES - AFSTELLING ELEKTRODEN - REGULAÇÃO DE ELÉTRODOS - REGULERING AF ELEKTRODER - ELEKTRODIEN SÄÄTÖ - REGULERING AV ELEKTRODER - ELEKTRODREGLERING - REGULACJA ELEKTROD - РЕГУЛЯЦИЯ...
- Page 26 Produkt: - Изделие: - Výrobek: - Termék: - Izdelek: - Ürün: - Proizvod: - Gaminys: - Ierīce: - Toode: - Produsul: - Výro- bok: - Продукт: - Виріб: - Proizvod: - Προϊόν: - 产品: CF 75 We declare that it is compliant with: - Si dichiara che è conforme a: - Es wird als konform mit den folgenden Normen erklärt: - Se declara que está...
- Page 27 ►en - LIMITED WARRANTY AND AFTER-SALES SERVICE KEEP THIS LIMITED WARRANTY During the period of twelve (12) months starting from the date of purchase of this product, the manufacturer guarantees that the appliance, all of its parts, do not have flaws due to manufacturing or the materials used, as long as the appliance has been used following the instructions and maintenance indicated in the manual.
- Page 28 ►en - DISPOSAL OF THE PRODUCT -This product has been designed and manufactured with top-quality materials and components, which can be re-cycled and re-used. -When a crossed-wheely bin symbol is attached to the product, it means that the product is protected by the, 2012/19/UE European Directive.
- Page 29 NOTE:_____________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________...
