HARDWARE INSTALLATION GUIDE
ExtremeRouting SLX 9850-4
Hardware Installation Guide
9035474-02 Rev AA
June 2019

Advertisement

Table of Contents
loading

Related Manuals for Extreme Networks ExtremeRouting SLX 9850-4

Summary of Contents for Extreme Networks ExtremeRouting SLX 9850-4

  • Page 1 HARDWARE INSTALLATION GUIDE ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA June 2019...
  • Page 2 Legal Notice Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.

  • Page 3: Table Of Contents

    Installing a device on a four-post rack......................................32 Flush mount..............................................34 Recessed mount............................................37 Installing a device on a two-post rack......................................39 Flush mount..............................................41 Middle mount ..............................................43 Installing an SLX-9850-4 NEBS kit......................................44 Installing cable management combs ......................................54 ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 4 Precautions specific to the interface modules.................................... 97 Time and items required for installation and replacement..............................97 Inserting an interface module..........................................97 Removing or replacing an interface module.....................................100 Verifying interface module operation......................................101 Power Supply Modules.........................................103 ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 5 Breakout cables..............................................134 Verifying transceiver operation........................................134 Hardware Maintenance Schedule....................................135 Hardware maintenance schedule........................................135 ExtremeRouting SLX 9850 Technical Specifications............................137 System specifications............................................137 Ethernet..................................................138 LEDs..................................................138 Other..................................................139 Weight and physical dimensions........................................139 ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 6 Cautions................................................... 151 General cautions............................................151 Electrical cautions............................................152 Cautions related to equipment weight....................................154 Danger Notices..............................................154 General dangers............................................155 Dangers related to equipment weight....................................155 Electrical dangers............................................156 Laser dangers.............................................. 157 ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 7: Preface

    Getting Help..........................................8 • Providing Feedback to Us....................................9 ® This section discusses the conventions used in this guide, ways to provide feedback, additional help, and other Extreme Networks publications. Conventions This section discusses the conventions used in this guide. Notes, cautions, and warnings Notes, cautions, and warning statements may be used in this document.

  • Page 8: Command Syntax Conventions

    Training Extreme Networks offers product training courses, both online and in person, as well as specialized certifications. For more information, visit www.extremenetworks.com/education/. Getting Help If you require assistance, contact Extreme Networks using one of the following methods:...

  • Page 9: Subscribing To Service Notifications

    Providing Feedback to Us Quality is our first concern at Extreme Networks, and we have made every effort to ensure the accuracy and completeness of this document. We are always striving to improve our documentation and help you work better, so we want to hear from you! We welcome all feedback but especially want to know about: •...
  • Page 10 ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 11: About This Document

    • What is new in this document..................................16 Supported hardware and software The following tables list the major field-replaceable units (FRUs), and rack mount kits supported for the ExtremeRouting SLX 9850-4 and the ExtremeRouting SLX 9850-8 devices. NOTE This section only lists the system components that are software-dependent and the rack kits. It is not a comprehensive list of field-replaceable units (FRUs) or accessory kit items.

  • Page 12: Auto Level Support - Table 1

    17r.101a or lower 17r.1.01b 17r.2.00 or higher 32-bit Mgmt. Module (MM) 17r.101a or lower Supported Supported Not Supported 17r.1.01b Supported Supported Supported 64-bit Mgmt. Module (MM) 17r.2.00 or higher Not Supported Supported Supported ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 13 100G-QSFP28-LR4L-2KM - 100 GbE QSFP28 optic SLX-OS 16r.1.00 (LC), LR4-Lite, for distances up to 2 km over SMF 100G-QSFP28-CWDM4-2KM - 100 GbE QSFP28 optic SLX-OS 16r.1.00 (LC), CWDM4, for distances up to 2 km over SMF ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 14 10G-SFPP-ER - 10GBASE-ER SFP+ optic (LC), for up to SLX-OS 16r.1.00 40km over SMF 10G-SFPP-TWX-0101 - DIRECT ATTACHED SFPP SLX-OS 16r.1.01 ACTIVE COPPER,1M,1-PACK 10G-SFPP-TWX-0108 - DIRECT ATTACHED SFPP SLX-OS 16r.1.01 COPPER,1M,8-PACK ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 15 Long description XBR-SLX9850-4-NEBS-KIT SLX 9850 Network Equipment-Building System (NEBS) kit for 4-slot chassis. Includes air filter door, air filter, and cable management kit XBR-SLX9850-4-FLTR SLX 9850 air filter for 4-slot chassis ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 16: What Is New In This Document

    Long description XBR-SLX9850-4-CAB SLX 9850 Cable Management kit (included in the chassis) What is new in this document The document supports the current SLX-OS software release and contains the latest updates. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 17: Device Overview

    Device management options..................................20 Device slot numbering: port-side The ExtremeRouting SLX 9850-4 contains 4 slots for interface modules. Each slot is 1.5 rack units (RUs) in height. A maximum of 4 interface modules is supported per chassis. The serial number for the device is located at the top of the chassis.

  • Page 18: Device Slot Numbering: Nonport-Side

    The following figure shows the nonport-side view of the SLX 9850-4. The callouts in the figure correspond to the numbering of the fan modules when you enter the show slots command. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 19 The switch fabric modules are located behind the fans. There are six slots for the switch fabric modules. Numbering for the modules goes from left to right, with 1 on the far left and 6 on the far right. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 20: Device Management Options

    Use the serial ports to manage your device. The serial ports are located on the management module. The following figure shows the serial console ports. Use the console port for device management. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 21 Device management options FIGURE 4 Management module front panel Service Ethernet port, 10G/1G/100M USB port Auxiliary console port Console port USB port Management Ethernet port, 1G/100M/10M ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 22 ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 23: Preparing For The Installation

    Use the screws specified in the procedure. Using longer screws can damage the device. ESD precautions DANGER For safety reasons, the ESD wrist strap should contain a series 1 megaohm resistor. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 24: Lifting Precautions

    Laser Radiation. Do Not View Directly with Optical Instruments. Class 1M Laser Products. DANGER Use only optical transceivers that are qualified by Extreme Networks, Inc. and comply with the FDA Class 1 radiation performance requirements defined in 21 CFR Subchapter I, and with IEC 60825 and EN60825. Optical products that do not comply with these standards might emit light that is hazardous to the eyes.

  • Page 25: Time And Items Required For Installation

    ID, Refer to Initial Setup and Verification on page date and time, and additional system 57 for more information. parameters. Verify and back up the configuration. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 26: Quick Installation Checklists

    Environmental Requirements section in ExtremeRouting SLX 9850 Technical Specifications on page 137. • Electrical • Environmental • Rack • Thermal Gather network configuration parameters. • IP address: ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 27: Installation And Initial Configuration

    Interpreting interface module LEDs on page 77, Interpreting power supply module LEDs on page 80, Interpreting fan module LEDs on page 83, and Interpreting switch fabric module LEDs on page 84. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 28: Unpacking The Shipping Carton

    When removing the device from the packaging, be careful to not damage the ground lug that is located at the bottom rear of the device. Place the device so that the port side (front) has access to intake air. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 29: Shipping Carton Contents

    Cable management kit – China-RoHS Hazardous/Toxic Substance statement – Extreme documentation web pointer card – Power Cord Retainer Kit NOTE Power cords are not included. NOTE Rack mount kit is not included. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 30 ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 31: Mounting The Device

    Make sure the rack housing the device is adequately secured to prevent it from becoming unstable or falling over. DANGER Do not attempt to lift the Extreme Networks chassis. It is extremely heavy. Use a mechanical lifting device to lift the chassis. Four or more people are required to position the unpopulated chassis into the rack.

  • Page 32: Required Tools And Equipment

    Installing a device on a four-post rack Use part number XBR-SLX9850-4-4PRM-KIT to install the device on a four-post rack. Verify that the items listed below are included in the rack kit. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 33 Screw, 8-32 x .375 in., patch lock Left rail assembly (1) Nut retainer Right rail assembly (1) 10. Washer Screw, 8-32 x .312 in., flathead 11. Nut clip floating Screw, M6x1.0x12-in., square cone ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 34: Flush Mount

    Using the lift, raise the device to the correct level. If applicable, lock the wheels of the lift. Ensure that the device is oriented so that the front (port side) has access to intake air. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 35 Slide the device onto the rails of the rack mount kit in the four-post rack, ensuring that it remains supported during the transfer. FIGURE 6 Installing the two rails from the rack-mount kit ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 36 Installing a device on a four-post rack FIGURE 7 Installing the rack-mount kit to the four-post rack ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 37: Recessed Mount

    • If the four-post rack has rectangular, unthreaded holes, use 16 screws, 16 nuts, and 16 alignment washers from the rack- mount kit to attach the kit to the posts. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 38 Ensure that the device is oriented so that the front (port side) has access to intake air. Slide the device onto the rails of the rack mount kit in the four-post rack, ensuring that it remains supported during the transfer. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 39: Installing A Device On A Two-Post Rack

    Installing a device on a two-post rack Use part number XBR-SLX9850-4-2PRM-KIT to install the device on a two-post rack. Verify that the items listed below are included in the rack kit. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 40 Installing a device on a two-post rack FIGURE 11 Parts in XBR-SLX9850-4-2PRM-KIT Left ear bracket Screw, 8-32 x .312 in., flathead Right ear bracket Screw, 10-32 x .63-in., square cone Saddle Nut retainer ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 41: Flush Mount

    Prepare the device for mounting by attaching the lift to the device chassis. Using the lift, raise the device to the correct level. If applicable, lock the wheels of the lift. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 42 FIGURE 13 Attaching the device to the rack 10. Install any device modules (management modules, interface modules, switch fabric modules, fan modules, and power supply modules) that have not already been installed into the rack. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 43: Middle Mount

    Raise the device slightly above the level of the two saddles, and bring the chassis forward until the front plates touch the front of the rack, then lower the device until it rests on the saddles. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 44: Installing An Slx-9850-4 Nebs Kit

    Use the following instructions to install the SLX 9850 NEBS two-post rack kit with a mid-mount . Use this kit XBR-SLX9850-4-NEBS-KIT to help direct airflow away from the rack area. Verify that the items listed below are included in the NEBS Kit. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 45 Velcro strap (8) Right cable comb assembly (1) Screw, 10-32 x .63-in., square cone washer (10) Air filter (1) Screw, 8-32 x .312 in., flathead (20) Chassis door (1) Nut retainer (6) ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 46 Installing an SLX-9850-4 NEBS kit Procedure to install: Before starting the NEBS kit installation, the bezel needs to be removed. FIGURE 17 Chassis installed on 2-post mid-mount rack with bezel ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 47 Installing an SLX-9850-4 NEBS kit Locate the 6 screws that holds the bezel to be removed prior to starting NEBS kit installation. FIGURE 18 Bezel screws to be removed Screw ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 48 Installing an SLX-9850-4 NEBS kit Remove the 6 screws. FIGURE 19 Removing the screws holding the bezel ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 49 Installing an SLX-9850-4 NEBS kit Locate the position where the six ball studs will be installed FIGURE 20 Ball studs to be installed ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 50 Installing an SLX-9850-4 NEBS kit Install the 6 ball studs using a 1/4" Hex socket driver. FIGURE 21 Ball studs installed Ball studs ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 51 Installing an SLX-9850-4 NEBS kit Install the left cable comb assembly and the right cable comb assembly. FIGURE 22 Installing cable comb assemblies ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 52 Installing an SLX-9850-4 NEBS kit Use 6 screws, 6 nuts, and 6 alignment washers from the rack mount kit to attach the cable combs to the posts. FIGURE 23 Cable comb assemblies installed Screw ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 53 Installing an SLX-9850-4 NEBS kit Snap the door onto chassis ball studs. FIGURE 24 Installing the chassis door ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 54: Installing Cable Management Combs

    You can install the cable management combs shipped with the chassis without service interruption for simple cable management. If installing cable management combs, remove the chassis mount screws, and install the cable combs shown in the diagram below. Reinstall the chassis mount screws when done. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 55 FIGURE 26 Installing cable management combs on the SLX 9850-4 chassis For more information about cable management, refer to the Managing cables on page 127 under the Transceivers and cables section of this guide. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 56 ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 57: Initial Setup And Verification

    Verify that the device operates correctly. • Check the LEDs to verify operation of module components in the device. Refer to Interpreting management module LEDs page 75, Interpreting interface module LEDs on page 77, ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 58: Items Required

    To provide power to the device, follow the steps in the following sections. To find power supply requirements for the device, refer to the power supply specifications section in the ExtremeRouting SLX 9850 Technical Specifications on page 137. Complete the following steps to provide power to the chassis. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 59: Connecting An Ac Power Cord

    Connecting an AC power cord To connect an AC cord to the power supply module, complete the following steps. Attach the chassis ground lug to the chassis ground. Chassis ground lug ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 60 Power supply receptacle Route the cable so it will be out of the way when connected to the power source. Plug the other end of the cable into the power source. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 61: Connecting A Dc Power Cord

    Slide the tubing over the #2 AWG power supply wire. Crimp the #2 AWG power supply wire into the power lug. Slide the tubing over the lug to the brown strip closest to the power lug holes. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 62 The DC return must be isolated from the chassis ground (DC-I) when making connections to the power supply. FIGURE 29 DC power supply DC power lug 1 DC power lug 2 ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 63: For Nebs-Compliant Installation With Ac And Dc

    To establish a serial connection to the console port on the device, complete the following steps. Verify that the device is powered on by verifying that all power LED indicators on the management, interface, power supply, and fan modules display a steady green light. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 64 Access the device using a terminal emulator application (such as HyperTerminal in a Windows environment or Tip in a UNIX environment). Disable any serial communication programs running on the workstation (such as synchronization programs). ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 65 (.), and the underscore (_) only. Passwords are case-sensitive, and they are not displayed when you enter them on the command line. For more information on passwords, refer to Extreme SLX-OS Security Configuration Guide for the SLX 9850 Router. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 66: Configuring A Static Ip Address

    If you are provided an IPv6 prefix with a /65 to /128 netmask, assign the addresses according to your network administrator's direction, and do NOT follow this procedure. NOTE SLX platforms without redundant management modules only need to configure the M 1 interface. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 67 The MAC addresses are used to create the IPv6 SLAAC address for the following mapping: • MM1 MAC - IPv6 address for interface M 1 • MM2 MAC - IPv6 address for interface M 2 • Stack MAC - IPv6 address for chassis virtual-ipv6 ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 68: Establishing An Ethernet Connection

    After using a serial connection to configure the IP addresses for the device, you can connect the active management module to the local area network (LAN). NOTE Connecting interface modules to a private network or VLAN is recommended. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 69: Customizing The Chassis And Host Names

    • A Telnet session using the chassis management IP address. Log in to the device using admin as your login name. If you have not changed the default password, use password. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 70: Configuring The Dns Service

    You should set the clock only if there are no NTP servers configured. Time synchronization from NTP servers overrides the local clock. Log in to the device using an account that has the admin role. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 71: Time Zones

    By default, this value is LOCL, which uses the local clock as the clock server. device(config)# ntp server "132.163.135.131" To display the NTP server IP address, use the show ntp status command. If you are in global configuration mode, enter do before the show command. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 72: Setting The Time Zone

    A Telnet session using the chassis management IP address. Log in to the device using admin as your login name. If you have not changed the default password, use password for password. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 73: Backing Up The Configuration

    Power off the chassis by disconnecting all power cords to the power supplies or switching off the rack power source. Note that power supply LEDs will continue to flash green briefly after disconnecting power until the power supply is completely off. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 74: Installing Cable Management Kit

    The device is not fully functional until it reboots. This command should be run as part of any planned power outages. Installing cable management kit For more information about cable management, refer to Managing cables on page 127. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 75: Monitoring The Device

    Interpreting management module LEDs Refer to the following figure and table to interpret the LED patterns on the management module. The LED patterns may temporarily change during device diagnostic tests. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 76 LED. If These LEDs correspond to the there is no SFM installed in that SFMs that are located behind each slot, no action is required. management module. Since the ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 77: Interpreting Interface Module Leds

    The following two figures show the power and status LEDs in the interface modules. FIGURE 33 Front panel LEDs for the 36-port 100GbE, 60-port 40GbE, or 240-port 10GbE flex-speed interface module Status Power ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 78 LED for the port in the top row LED for the port in the bottom row LED for the port in the center row (directly above the LED) ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 79 Module is operational. No action is required. Ethernet for 72-port 10GbE/1GbE Steady green Port is online (connected to an No action is required. interface module external device) but has no traffic. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 80: Interpreting Power Supply Module Leds

    Interpreting power supply module LEDs Refer to the following illustrations and table to interpret the LED patterns on the power supply module. The LED patterns may temporarily change during device diagnostic tests. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 81 Interpreting power supply module LEDs FIGURE 37 AC Power supply module LEDs LED 1 - AC in good LED 2 - AC out good ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 82 Output voltage is out of range If this condition persists, replace the power supply assembly. LED 2: Yellow LED 1: Green Over-temperature warning or fan error Check the fan. LED 2: Flashing Yellow/Green ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 83: Interpreting Fan Module Leds

    Fan assembly has power. No action is required. Status (Fan) No light (LED is off) Fan assembly is either healthy or Ensure that the fan assembly has does not have power. power. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 84: Interpreting Switch Fabric Module Leds

    There is also a label on the bottom center of the chassis that shows the SFM locations behind the fan modules. If the fan module is removed, you can check the LEDs on the SFM, as shown in the following figure. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 85 No light (LED is off) Module is either not operational or Ensure that the module is firmly does not have power. seated, that both ejectors (arms on the side of the module) are pushed ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 86 Module is faulty or initializing. Check the module status by entering the show slots command. If LED remains amber, consult the device supplier. Green Module is operational. No action is required. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 87: Management Modules

    Service Ethernet port, 10G/1G/100M USB port Auxiliary console port Console port USB port Management Ethernet port, 1G/100M/10M For description of the LEDs, refer to Interpreting management module LEDs on page 75. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 88: Precautions Specific To The Management Modules

    Connect the ESD ground strap to the chassis as shown in the following figures. You can connect the strap to the connection on either the front or back of the chassis. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 89 ESD ground strap connection points FIGURE 42 ESD ground strap chassis connection - front ESD ground strap connection point ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 90: Time And Items Required For Installation And Replacement

    The replacement procedure for the management module takes approximately 30 minutes. The following items are required for the management module replacement: • ESD grounding strap • Workstation or laptop computer • Serial cable ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 91: Removing A Management Module

    Remove any cables connected to the module. Unscrew the captive screws from both ejectors using the #2 Phillips screwdriver. Rotate both ejectors simultaneously outward, away from the center of the module. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 92: Installing A Management Module

    Complete the following steps to insert a management module. Refer to the illustration provided in Removing a management module page 91. Unpack the new management module and remove it from the anti-static bag. Inspect the module for damage. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 93: Verifying Management Module Operation

    Enter the following commands and note any error conditions: • show system - Displays information about each component in the system. • show slots - Displays the current status of the components in each slot of the chassis. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 94 ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 95: Interface Modules

    The following figure shows the port numbering when the module is set to 40GbE. For 10GbE, a single Ethernet port on the module is converted into four ports. For example, a breakout cable on the device to Port 1 would convert that port to Ports 1, 2, 3, and 4. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 96 The following figure shows the port numbering for the 72-port 10GbE/1GbE interface module. FIGURE 49 Port numbering for the 72-port 10GbE/1GbE interface module For a description of the module LEDs, refer to Interpreting interface module LEDs on page 77. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 97: Precautions Specific To The Interface Modules

    SFP+ or QSFP28 transceivers (as needed) • Optical and copper cables (as needed) Inserting an interface module Review Precautions specific to the interface modules on page 97 before replacing an interface module. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 98 Do not place your fingers into the side of the module. Align the flat side of the interface module inside the top and bottom rail guides in the slot. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 99 The interface module will not function unless the captive screws are tightened. 10. Install the transceivers and cables in the interface module. 11. Group and route the cables using a cable management comb. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 100: Removing Or Replacing An Interface Module

    Do not place your fingers into the side of the module. If you are replacing an interface module, unpack the new interface module and insert into the chassis using the procedure in Inserting an interface module on page 97 ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 101: Verifying Interface Module Operation

    - Displays the current status of each interface module. • show system - Displays information of each component in the system. • show slots - Displays the current status of the components in each slot of the chassis. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 102 ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 103: Power Supply Modules

    11. For a description of the power supply module LEDs, refer to Interpreting power supply module LEDs on page 80. The following figure shows the components of the AC power supply. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 104 Power supply module overview FIGURE 51 AC power supply module AC In LED Handle DC Out LED Securing latch AC power cable receptacle The following figure shows the components of the DC power supply. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 105: Power Input And Cable Options

    Power cables are not supplied with the SLX 9850 devices. Power supply numbering To see the power supply numbering in the chassis, refer to the Device slot numbering: port-side on page 17. There are six slots for power supplies. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 106: Precautions Specific To The Power Supply Module

    If the device is operating and will continue to operate during the replacement, check the power LEDs to verify that the minimum number of power supplies is functioning. Refer to the Technical Specifications to check your power requirements. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 107 Remove the power cord from the power supply AC connector. FIGURE 53 AC power supply Power supply AC connector Lift the latch on the lower part of the power supply to release the power supply from the chassis. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 108: Inserting An Ac Power Supply Module

    Insert the power supply into the slot. Make sure that the latch snaps into place in the chassis. Attach the power cord. Verify that the power LED on the power supply displays a steady green light. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 109: Removing A Dc Power Supply Module

    To insert a DC power supply module, complete the following steps. Unpack the new power supply and remove it from the anti-static bag. Inspect the power supply for damage. Insert the power supply into the slot. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 110: Verifying Power Supply Module Operation

    This PSU is offered to match airflow of the chassis. In summary, following are two HV PSU offerings made available for SLX 9850-4 . TABLE 26 HV PSU Input Voltage Air-flow Type Input Connector HV DC, 240V-380V DC Intake - NPI SAF-D Type & ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 111 Input AC voltage is out of range. • LED 1: Green and LED 2: Yellow - Output voltage is out of range ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 112: Connector Type

    SAF-D connector on PSU, power cord is latched at bottom of plug in connector picture. Unterminated wires enables full customization by the customers based on application (HVAC/HVDC) and country plug type. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 113 PSUs or Fans. PSUs and Fans must be added based on the customer power requirements. This arrangement allows assembling chassis as per customer requirements (HV PSU or 240V AC PSU). No new base director chassis P/Ns will be created that includes HV PSUs. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 114 ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 115: Fan Modules

    The ambient intake temperature of the system must be less than 35 deg C (95 deg F) at sea level to prevent overheating. If the ambient temperature is greater than 35 deg C, the module installation time must be reduced. Refer to the specific module removal and installation instructions in this guide for more details. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 116: Removing A Fan Module

    The fan needs to be replaced within 2 minutes if the ambient temperature exceeds 35 deg C (95 deg F). Grasp the handles and pull, sliding the fan from the chassis and supporting the fan from beneath as you remove it. FIGURE 58 Removing the fan module ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 117: Inserting A Fan Module

    If a site-specific interval cannot be determined by the site operator, the filter should be replaced on an interval of every 3 months. For more information about replacing the fan filter, refer to the NEBS manual for this device. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 118 ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 119: Switch Fabric Modules

    For information about the SFM LEDs on the fan module, refer to Interpreting switch fabric module LEDs on page 84. For information about the SFM LEDs on the management module, refer to Interpreting management module LEDs on page ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 120: Precautions Specific To The Switch Fabric Module

    In addition, wear a wrist grounding strap connected to chassis ground (if the device is plugged in) or a bench ground. Refer to ground strap connection points on page 88 for the location of the ESD jack. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 121: Time And Items Required For Replacement

    Open the ejectors on the top and bottom of the SFM by rotating them outward towards you. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 122: Inserting A Switch Fabric Module

    Complete the following steps to insert the switch fabric module (SFM) similar to the procedure and illustration for Removing a switch fabric module on page 121 . Unpack the new SFM and remove it from the anti-static bag. Inspect the SFM for damage. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 123 Place the connector covers on the connectors before shipment, or the connectors could be damaged. 13. Replace the fan module by following the steps in the Inserting a fan module on page 117. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 124: Verifying Switch Fabric Module Operation

    • show system • show environment sensor • show environment temp NOTE For details about these commands, refer to the Extreme SLX-OS Monitoring Configuration Guide for SLX 9850 Router. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 125: Transceivers And Cables

    Optical transceiver extraction tool (for 10 Gbps transceiver only) NOTE Most Extreme devices come with a transceiver extraction tool and holster. The extraction tool is designed to remove transceivers from modules where the space is limited. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 126: Precautions Specific To Transceivers And Cables

    All fiber-optic interfaces use Class 1 lasers. DANGER Use only optical transceivers that are qualified by Extreme Networks, Inc. and comply with the FDA Class 1 radiation performance requirements defined in 21 CFR Subchapter I, and with IEC 60825 and EN60825. Optical products that do not comply with these standards might emit light that is hazardous to the eyes.

  • Page 127: Managing Cables

    To insert an SFP+ transceiver, complete the following steps. NOTE Route cables to the side so that the line cards can be removed without disturbing the cables to the other line cards. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 128 If the transceiver uses a bail latch mechanism (10 GbE transceivers only), ensure that the bail (wire handle) is in the unlocked position, grasp the transceiver, and push it into the port until firmly seated. Close the bail to latch the transceiver in the slot. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 129: Replacing An Sfp+ Transceiver

    You may damage the cable as well as the transceiver. Replacing an SFP+ transceiver Complete the following steps to remove and then install a new SFP+ transceiver. Remove any cables that are inserted into the transceiver. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 130 If transceiver has a pull tab, grasp the pull tab and pull the transceiver straight out from the port. NOTE Grasp the pull tab near the body of the transceiver to reduce the chances of bending the pull tab. As the transceiver may be hot, avoid touching it. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 131: Installing A Qsfp28 Transceiver

    QSFP28 must be replaced. • Some QSFP28 transceivers have an integrated cable attached. You do not need to install a separate cable. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 132 QSFP28 transceiver. You may damage the cable as well as the transceiver. Organize cables to avoid covering LEDs and air vents so that LCs can be removed. Refer to Managing cables on page 127 for more information. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 133: Replacing A Qsfp28 Transceiver

    The following figure uses a generic interface module. Your interface module might look different. FIGURE 67 Replacing a QSFP28 optical transceiver into blade port Pull tab QSFP28 transceiver QSFP28 cable connector ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 134: Breakout Cables

    LED becomes solid green. When traffic is detected on the port, the light becomes blinking green. You can also enter the show interface status and show ip interface brief commands to verify proper transceiver operation. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 135: Hardware Maintenance Schedule

    The management, interface, and switch fabric modules are dedicated modules, which means that you must install them in ExtremeRouting SLX 9850 devices only. If you install these modules in another Extreme Networks device, or you install a module intended for another Extreme Networks device in an ExtremeRouting SLX 9850 device, the device and modules will not function properly.
  • Page 136 ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 137: Extremerouting Slx 9850 Technical Specifications

    SAF-D on HV Fan modules Three fan modules per chassis Cooling Front-to-back airflow System architecture Non-blocking fabric System processors 4 core, 8 thread x86 processor Port-to-port latency <4 microseconds for 64-byte packets ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 138: Ethernet

    Status (SFM) LED: No light (LED is off) - One or more SFM module is either not operational or does not have power. Amber - Module is faulty or initializing. Green - Module is operational. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 139: Other

    359 lb (162.84 kg) Including chassis, 2 management modules, 5 power supplies, 5 switch fabric modules, and 8 SLX9850-100Gx36 CQ-M interface modules: 503 lb (228.16 kg) ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 140: Environmental Requirements

    0.5 G, 5-500 Hz at 1.0 octave/minute Airflow SLX 9850-4 - Maximum: 2336 cmh (1375 cfm) SLX 9850-8 - Maximum: 4035 cmh (2375 cfm) Heat dissipation Refer to values under "Power consumption (maximum configuration)". ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 141: Power Supply Specifications (Per Psu)

    Configuration of SLX 9850-4: One 4-slot chassis with two management modules, six switch fabric modules, six power supplies, three fan modules, and eight 36-port 100GbE, 60-port 40GbE, or 240-port 10GbE flex-speed interface modules set in 60x40 mode. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 142: Power Consumption (Modules) (Typical Configuration)

    Maximum configuration is 100% traffic with fans operating normally. Ambient temperature 40 deg Module Maximum power consumption Management Module 100W Switch Fabric Module SLX 9850-4: 124 W SLX 9850-8: 220 W Fan module SLX 9850-4: 175 W ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 143: Data Port Specifications (Ethernet)

    Supports up to 288 1000-GbE ports with eight 36-port 100GbE, 60-port 40GbE, or 240-port 10GbE flex-speed interface modules Serial port specifications (pinout RJ-45) Signal Description Not supported Not supported Receive data Logic ground Not supported Transmit data Not supported Not supported ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 144: Serial Port Specifications (Protocol)

    Regulatory compliance (environmental) • 2011/65/EU - Restriction of the use of certain hazardous substance in electrical and electronic equipment (EU RoHS). • 2012/19/EU - Waste electrical and electronic equipment (EU WEEE). ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 145 30/2011/TT-BCT - Vietnam circular. • SJ/T 11363-2006 Requirements for Concentration Limits for Certain Hazardous Substances in EIPs (China). • SJ/T 11364-2006 Marking for the Control of Pollution Caused by EIPs (China). ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 146 ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 147: Regulatory Statements

    The standards compliance label on this device contains the CE mark which indicates that this system conforms to the provisions of the following European Council directives, laws, and standards: • Electromagnetic Compatibility (EMC) Directive 2014/30/EU • Low Voltage Directive (LVD) 2014/35/EU ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 148: China Rohs

    Class A device (Broadcasting Communication Device for Office Use): This device obtained EMC registration for office use (Class A), and may be used in places other than home. Sellers and/or users need to take note of this. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 149: Vcci Statement

    (VCCI). If this equipment is used in a domestic environment, radio disturbance might arise. When such trouble occurs, the user might be required to take corrective actions. Japan power cord English translation of above statement ATTENTION: Never use the power cord packed with your equipment for other products. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...
  • Page 150 ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 151: Cautions And Danger Notices

    Stellen Sie sicher, dass an der Vorderseite, den Seiten und an der Rückseite der Luftstrom nicht behindert wird. MISE EN GARDE Vérifiez que rien ne restreint la circulation d'air devant, derrière et sur les côtés du dispositif et qu'elle peut se faire librement. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 152: Electrical Cautions

    CAUTION For the NEBS-compliant installation of an Extreme Networks device , use a ground wire of at least 2 AWG. The ground wire should have an agency-approved crimped connector (provided with the device) attached to one end, with the other end attached to building ground.
  • Page 153 Kupferkabel mit einem Querschnitt von 33,6 cm² (2 AWG), VW-1-Kennzeichnung und mindestens 90oC Belastbarkeit bestehen. Die Installation dieses Geräts muss den NEC/CEC-Anforderungen entsprechen. Wenden Sie sich für Bestimmungen an Ihre Behörden vor Ort. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 154: Cautions Related To Equipment Weight

    Una advertencia de peligro indica condiciones o situaciones que pueden resultar potencialmente letales o extremadamente peligrosas. También habrá etiquetas de seguridad pegadas directamente sobre los productos para advertir de estas condiciones o situaciones. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 155: General Dangers

    DANGER Do not attempt to lift the Extreme Networks chassis. It is extremely heavy. Use a mechanical lifting device to lift the chassis. Four or more people are required to position the unpopulated chassis into the rack.

  • Page 156: Electrical Dangers

    Pour des raisons de sécurité, la dragonne ESD doit contenir une résistance de série 1 méga ohm. PELIGRO Por razones de seguridad, la correa de muñeca ESD deberá contener un resistor en serie de 1 mega ohmio. ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

  • Page 157: Laser Dangers

    Todas las interfaces de fibra óptica utilizan láser de clase 1. DANGER Use only optical transceivers that are qualified by Extreme Networks, Inc. and comply with the FDA Class 1 radiation performance requirements defined in 21 CFR Subchapter I, and with IEC 60825 and EN60825. Optical products that do not comply with these standards might emit light that is hazardous to the eyes.
  • Page 158 Rayonnement de laser. Ne regardez pas directement avec des instruments optiques. Produits de laser de classe 1M. PELIGRO Radiacion de Laser. No vea directamente con Instrumentos Opticos. Clase 1M de Productos de Laser. レーザ放射 光学器具で直接ビームを見ないこと クラス１ M レーザ製品 警告 ExtremeRouting SLX 9850-4 Hardware Installation Guide 9035474-02 Rev AA...

This manual is also suitable for:

Extremerouting slx 9850-8

Table of Contents
