a.
Read these instructions.
b. Keep these instructions.
c.
Follow all instructions.
d. Do not use this apparatus near water.
e.
Clean only with dry cloth.
f.
Do not block any ventilation openings.
accordance with the manufacturer's instructions.
g. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
h. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding-type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
i.
Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the appliance.
This document contains information proprietary to Rock-Ola
Manufacturing Corporation and may not be reproduced, published or
distributed in any form or disclosed in whole or in part without written
IMPORTANT SAFETY INSTRUCTIONS
authorization.
Part No. 62055
Slimline
Model SL-3 Set-Up and
Installation Guide
j.
Only use attachments/accessories specified by the
manufacturer.
k. Unplug this apparatus during lightning storms or when
unused for long periods of time.
l.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
Install in
damaged in any way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to rain
or moisture, does not operate normally, or has been
dropped.
WARNING: Terminals marked with the
lightening flash label are hazardous live.
The external wiring connected to these
terminals requires installation by an
instructed person or the use of ready-
made leads or cords.
Copyright ©2008
All Rights Reserved
Rock-Ola Manufacturing Corporation
2335 208th Street, Torrance, CA 90501
- 1 -
Advertisement
Table of Contents
Summary of Contents for Peavey Rock-ola Slimline SL-3
- Page 1 Part No. 62055 Slimline Model SL-3 Set-Up and Installation Guide IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Only use attachments/accessories specified by the manufacturer. b. Keep these instructions. k. Unplug this apparatus during lightning storms or when Follow all instructions. unused for long periods of time. d.
-
Page 2: Installing The Hard Drive
Introduction Installing the Hard Drive 1. Locate the four brass thumbscrews located in a small Rock-Ola® has teamed up with Peavey Electronics® to build envelope inside the literature package. Thread a the most powerful standard jukebox. Optional power amplifiers thumbscrew into the threaded holes on the sides of the can provide up to 3,500 Wrms for concert level sound in drive at each corner. -
Page 3: Major Component Locations
Major Component Locations 1. Touch Monitor 2. Credit Card Reader 3. Bill Acceptor 4. Cooling Fan 5. Router 6. Peavey 900 Power Amp (in compartment) 7. Power Distribution 8. RF Remote Receiver Assy 9. Control Amplifier 10. Power Strip 11. LED Controller 12. -
Page 4: Touchscreen Calibration
Second, if the CPE needs to be reset, the jukebox can cycle the power Power Up In order to locate a modem inside a wall mounted jukebox, a means of connecting two power cubes to the CPE Outlet is required. WARNING Use of adapters or removal of the grounding pin of A pigtail power cord is connected to the CPE power outlet... - Page 5 WARNING: Do NOT press the reset button on the back of the router unless directed to do so by AMI personnel. It has been programmed to operate with the AMI Entertainment Network and a reset will erase all of the settings. External Router if it determined to be advantageous to have the router outside the jukebox.
- Page 6 Hidden Reset Buttons Location Be sure the establishment knows the location of the hidden Reset buttons. The buttons are accessed from the rear of the cabinet, as shown in the illustration. Two small holes in the cabinet allow a small, pointed object, such as a toothpick or swizzle stick, to press the reset buttons through the holes.
- Page 7 Recommended Routine Maintenance of the Slimline Digital-Downloading Jukebox Heat is the biggest enemy of electronic components. Proper maintenance is essential for maximum earnings and reliability. It is very important to keep all cooling fans clean. Once dust and dirt is visible on a cooling fan, the airflow is reduced by at least 25%. There are several cooling fans in the Rock-Ola jukebox (see illustration, next page.) Recommended preventative maintenance: Routine Service.
-
Page 8: Cabinet Fan
CABINET FAN CPU FAN INSIDE POWER SUPPLY AMPLIFIER...
