ASSEMBLY

To hire an authorized service technician to assemble the elliptical, call 1-800-445-2480.
Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the
packing materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included tool(s), assembly requires a Phillips screwdriver
wrench , and a rubber mallet
As you assemble the elliptical exerciser, use the drawings below to identify small parts. The number in parenthe-
ses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The
number following the parentheses is the quantity needed for assembly. Note: If a part is not in the hardware
kit, check to see if it has been preassembled.
M8 Split
Star Washer
(112)–8 Washer (90)–3
M4 x 16mm
M4 x 14mm Round Head
Screw (104)–8 Screw (101)–8
Hub Screw (87)–8
M8 x 69mm Button
Bolt (80)–1
.
Wave Washer
(111)–2
M4 x 32mm
Round Head
Screw (105)–6
M8 x 23mm Shoulder
Screw (115)–4
M10 x 127mm Button Screw (83)–2
M8 Washer M8 Jamnut
(88)–6
M4 x 45mm
Screw (108)–2
M8 x 23mm Button
Screw (84)–4
M10 x 80mm Carriage
5
, an adjustable
M10 Locknut
(79)–5 (81)–2
M6 x 20mm Button
Screw (77)–4
M8 x 43mm Button
Bolt (78)–4
Bolt (82)–2
