- Page 1 All manuals and user guides at all-guides.com instruction manual Dishwasher Model number：DW602XA...
- Page 2 All manuals and user guides at all-guides.com For detailed operating method read the corresponding content on the instruction manual. Switch on the appliance Press the On/Off button to switch on the appliance, Open the door. With each wash cycle. Compartment Fill the detergent dispenser For programmes with pre-wash only.
- Page 3 All manuals and user guides at all-guides.com Dear Customer, Please carefully read this manual before using the Control Panel...........2 dishwasher, it will help you to use and maintain the Dishwasher Features........3 dishwasher properly. Keep it to refer to it at a later date. Pass it on to any subsequent owner of the appliance.
- Page 4 All manuals and user guides at all-guides.com When using your dishwasher, follow the precautions listed below: This appliance must be grounded. In the event of a Improper connection of the equipment-grounding malfunction or breakdown, grounding will reduce conductor can result in the risk of an electric shock. the risk of anelectric shock by providing a path of Check with a qualified electrician or service least resistance of electric current.
- Page 5 All manuals and user guides at all-guides.com To get the best performance from your dishwasher, read all operating instructions before using it for the first time. 1 ON/OFF Button: To turn on/off the power supply. Display Window: Display program remaining time, delay time, fault codes, etc .
- Page 6 All manuals and user guides at all-guides.com Upper Basket Spray Arms Lower Basket Main Filter Detergent Dispenser Cup Shelf Cutlery Basket Coarse Filter Back View Rinse Aid Dispenser Drain pipe connector Inlet pipe connector...
-
Page 7: Rinse Aid Dispenser
All manuals and user guides at all-guides.com Before using your dishwasher for the first time: Fill the rinse aid dispenser Fill in detergent Rinse Aid Dispenser The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks. -
Page 8: Adjusting Rinse Aid Dispenser
All manuals and user guides at all-guides.com To open the dispenser, turn the cap to the "open" (left) arrow and lift it out. Pour the rinse aid into the dispenser, being careful not to overfill. Replace the cap by inserting it aligned with "open" arrow and turning it to the closed (right) arrow. Clean up any rinse aid spilled while during filling with an absorbent cloth to avoid excessive foaming during the next wash. -
Page 9: Concentrated Detergent
All manuals and user guides at all-guides.com Normally new pulverised detergent is without phosphate. Thus the water softener function of phosphate is not given. In this case we recommend to fill salt in the salt container even when ° the hardness of water is only 6 dH. If detergents without phosphate are used in the case of hard water often white spots appear on dishes and glasses. -
Page 10: Fill In Detergent
All manuals and user guides at all-guides.com Fill in Detergent Fill the detergent dispenser with detergent. The marking indicates the dosing levels , as illustrated on the right: The place of main wash cycle detergent placed , “ ” MIN means approximately 20g of detergent. The place of pre-wash cycle detergent placed , approximately 5g of detergent Please observe the manufacturers dosing and storage... - Page 11 All manuals and user guides at all-guides.com Consider buying utensils which are identified as dishwasher-proof. Use a mild detergent that is described as 'kind to dishes'. If necessary, seek further information from the detergent manufacturers. For particular items, select a program with as low a temperature as possible. To prevent damage, take glass and cutlery out of the dis hwasher as soon as possible after the program has ended.
- Page 12 All manuals and user guides at all-guides.com The upper basket is designed to hold more delicate and lighter dishware s uch as glasses, coffee and tea cups and saucers, as well as plates, small bowls and shallow pans (as long as they are not too dirty).
- Page 13 All manuals and user guides at all-guides.com The upper rack is for more delicate and lighter dishware such as glasses, coffee & tea cups, saucers, plates, bowls, and shallow pans (provided these are not too dirty). Position the dishes and cookware so that they do not get moved by the spray of water.
- Page 14 All manuals and user guides at all-guides.com Means: need to fill rinse into the Rinse-Aid Dispenser. Pre-wash 50℃ For the heaviest soiled loads, Pre-wash such as pots,pans,casserole wash 65℃ Intensive dishes and dishes that have 5/27.5 g Rinse been sitting with dried food Rinse on them for a while.
-
Page 15: Switch Off The Dishwasher
All manuals and user guides at all-guides.com Draw out the lower and upper basket, load the dishes and push them back. It is commended to load the lower bask et first, then the upper one (s ee the section entitled “... -
Page 16: Filter Assembly
All manuals and user guides at all-guides.com The filter prevents larger remnants of food or other objects from getting inside the pum. The residues may block the filter, in this case they must be removed. The filter system consists of a coarse filter,a flat (Main filter) And a microfilter(Fine filter). -
Page 17: Cleaning The Filter
All manuals and user guides at all-guides.com Remarks: - Inspect the filters for blocking after every time the dishwasher has been used. - By unscrewing the coarse filter, you can remove the filter system. Remove any food remnants and clean the filters under running water. The entire filter assembly should be cleaned once a week. - Page 18 All manuals and user guides at all-guides.com After Every Wash When not in Use for a LongTime It is recommend that you run a was h cy cle with the After every wash, turn off the water supply to the dishwasher empty and then remove the plug from the appliance and leave the door slightly open so that socket, turn off the water supply and leave the door of...
- Page 19 All manuals and user guides at all-guides.com Improper connection of the equipment earthing conductor can result in the risk of an for personal safety: electric shock. DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG WITH THIS APPLIANCE. Check with a qualified electrician or service representative if you are in doubt whether the DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE EARTHING appliance is properly earthed.
-
Page 20: Water Outlet
All manuals and user guides at all-guides.com How to Drain Excess Water From Hoses If the sink is 1000 higher from the floor, the excess water in hoses cannot be drained directly into the sink. It will be necessary to drain excess water from hoses into a bowl or suitable container that is held outside and lower than the sink. - Page 21 All manuals and user guides at all-guides.com Fuse blown, or the Replace fuse or reset circuit breaker. Remove any other circuit breaker acted appliances sharing the same circuit with the dishwasher Power supply is not Make sure the dishwasher is turned on and the door is turned on closed securely.
- Page 22 All manuals and user guides at all-guides.com The dishes were not See notes in " Loading the Dishwasher Baskets ". loaded correctly. The programme was Select a more intensive programme. not powerful enough. See" Wash Cycle Table . " Not enough detergent Use more detergent, or change your detergent.
- Page 23 All manuals and user guides at all-guides.com Height : 850mm Width : 600mm Depth : 600mm Voltage connected Load : see rating label Water pressure: 0.04-1.0MPa Hot water connection : max 60 ℃ Power supply: see rating label Capacity: 14 Place settings...
