Uniflame Sunbeam BC1712E Deluxe Owner's Manual

Portable electric grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
By UniFlame
WARNING
Model BC1712E Deluxe
Improper installation,
adjustment, alteration,
Portable Electric Grill
service or maintenance
can cause injury or
property damage.
Read the installation,
operation and
maintenance instructions
thoroughly before
installing or servicing
this equipment.
Failure to follow these
instructions could result
in fire or explosion,
which could cause
property damage,
personal injury, or death.
DANGER!
DO NOT use electric grill
for indoor cooking or
heating. NOT to be used
in or on boats or
recreational vehicles.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. IF YOU ARE
ASSEMBLING THIS UNIT FOR SOMEONE ELSE, GIVE THIS MANUAL TO
HIM OR HER TO SAVE FOR FUTURE REFERENCE.

Advertisement

Table of Contents
loading

Related Manuals for Uniflame Sunbeam BC1712E Deluxe

Summary of Contents for Uniflame Sunbeam BC1712E Deluxe

  • Page 1 By UniFlame WARNING Model BC1712E Deluxe Improper installation, adjustment, alteration, Portable Electric Grill service or maintenance can cause injury or property damage. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment. Failure to follow these...
  • Page 2 We then will ship your request as soon as possible. We appreciate and encourage customer feedback. Please contact us if you have any suggestions or comments regarding this product. Best Regards, UniFlame Corporation Customer Satisfaction Department BC1712E owner’s manual 1...

  • Page 3: Warning For Your Safety

    Owner’s Manual, Model BC1712E Portable Electric Grill IMPORTANT NOTICE: READ ALL INSTRUCTIONS PRIOR TO ASSEMBLY AND USE! IMPORTANT SAFEGUARDS WARNING FOR YOUR SAFETY 1. Read all instructions 1. DO NOT store or use 2. Do not touch hot surfaces. Use handles or knobs. gasoline or other 3.
  • Page 4 Owner’s Manual, Model BC1712E Portable Electric Grill Danger WARNING ELECTRIC SHOCK CAN KILL OR RESULT IN SERIOUS • Do not use 16 gauge INJURY. TO PREVENT ELECTRICAL SHOCK: extension cords. Use only with GFI (Ground Fault Interrupter) protected Damage to household circuit wiring and/or fire could Do not use grill when raining...
  • Page 5 Owner’s Manual, Model BC1712E Portable Electric Grill Do not use in an explosive atmosphere. Keep grill area clear and free from combustible materials, gasoline and other flammable vapors and liquids. Do not alter grill in any manner. When not in use, store grill in progected area and electric parts indoors. Grill functions best WITHOUT an extension cord.

  • Page 6: Illustrated Parts List

    Owner’s Manual, Model BC1712E Portable Electric Grill Illustrated parts list 1: Lid..…………………..………………..1 pc 2: Grill Bottom …………..……………..……. 1 pc 3.Cooking Grid ………………….……… 1 pc 55-12-844 55-12-849 55-12-854 5: Lid Handle.………..………………..……… 1pc 4.Side Handles ………………..………..…2pcs 6: Air Damper…………………...……… 1pcs 55-12-845 55-12-850 55-12-855 7: Legs ……………….……..…4pcs...
  • Page 7 Owner’s Manual, Model BC1712E Portable Electric Grill Assembly Instructions For Best Results Remove all contents from packaging, and make sure all parts are present before attempting to assemble! Tighten all bolt connections by hand first, then when the grill is fully assembled, go back and tighten.
  • Page 8 Owner’s Manual, Model BC1712E Portable Electric Grill ¨ [ ? ¡ ì ? ¨ a © À | ¨¬ 1 Step 3 Attach four legs (7) to grill bottom (2) by inserting as shown. Then secure the legs to the bottom using medium bolts (B), medium lock washers (J), medium washers (M), and medium wing nuts (F).
  • Page 9 Owner’s Manual, Model BC1712E Portable Electric Grill Step 5 Attach side handles (4) to grill bottom (2) using medium bolts (B), medium wing nuts (F), medium lock washers (J), and medium washers (M). Step 6 Attach bottom hinges (12) to grill bottom (2), using short bolts (C), heat-resistant washers (H), medium wing...
  • Page 10 Owner’s Manual, Model BC1712E Portable Electric Grill Step 8 Install the heating element (9), by inserting it into square hole in grill bottom (2), then securing with short bolts (C), medium wing nuts (F), medium lock washers (J), and medium washers (M). Step 9 Attach grill top (1) to grill bottom (2) at hinges using pins (O), and...
  • Page 11 Owner’s Manual, Model BC1712E Portable Electric Grill ¨ [ ? ¡ ì ? ¨ a © À | ¨¬ 4 Step 11 Insert cooking grid (3) into grill. Grid will rest on ledge inside grill bottom . Step 12 Plug cord (10) into exposed end of heating element.
  • Page 12 Owner’s Manual, Model BC1712E Portable Electric Grill Operating Instructions Make sure that controller knob is turned fully to the “off” position before plugging the controller into outlet. Settings on controller knob are indicated by triangular mark on electric controller. Use only properly grounded outlet. Before cooking on this grill for the first time, operate the grill for about 15 minutes with the lid closed and the grill turned on “high.”...

  • Page 13: Cleaning And Care

    Owner’s Manual, Model BC1712E Portable Electric Grill Cleaning and Care Caution: All cleaning and maintenance should be done when grill is cool. DO NOT clean any grill part in a self-cleaning oven. The extreme heat will damage the finish. Cleaning Burning-off the grill after every use (approx.
  • Page 14 Owner’s Manual, Model BC1712E Portable Electric Grill Barbecue Recipes Never-fail barbecue sauce Ingredients: ¼ cup Finely Chopped Onion 2 tablespoons Butter Or Margarine ¼ cup Brown Sugar, Firmly Packed 1 tablespoon Worcestershire Sauce ¼ teaspoon Hot Pepper Sauce Clove Garlic, Finely Chopped 1 cup Catsup ¼...
  • Page 15 Owner’s Manual, Model BC1712E Portable Electric Grill Hardcore Grilled Trout Ingredients: 1/4 cup lemon or lime juice 2 tablespoons melted butter 2 tablespoons vegetable oil 2 tablespoons chopped parsley 1 tablespoon hot sauce 1/2 teaspoon ground ginger 1/2 teaspoon salt 4 brook trout -- about 1 pound each Prepare: Combine lemon juice, margarine, oil, parsley, sesame seeds, hot sauce, ginger and salt.

  • Page 16: Year Limited Warranty

    1 YEAR LIMITED WARRANTY UniFlame Corporation warrants to the original retail purchaser of this grill that if it is assembled and operated in accordance with the printed instructions accompanying it then for a period of one (l) year from the date of purchase.
