- Page 1 PL360/460 Cradle Quick Reference Guide...
-
Page 2: Warranty
An implied license exists only for equipment, circuits, and subsystems contained in Symbol products. Symbol and the Symbol logo are registered trademarks of Symbol Technologies, Inc. Other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies and are hereby acknowledged. -
Page 3: Equipment Supplied
Quick Reference Guide Introduction The PhaserLink 360/460 cradle acts as a stand, host communication interface, and charger for the Phaser scanner. For convenience, the cradle can sit on a desktop or be mounted on a wall. The cradle receives data from the scanner via connectors in the bottom of the scanner and the top of the cradle. - Page 4 Parts Charging Indicator Scanner Support Tab Charging/Communication Contacts COM 2 Wall-mounting Socket 1 PL360/460 Cradle COM 1 Power Port Wall-mounting Socket 2...
-
Page 5: Connecting To The Host
Quick Reference Guide Connecting to the Host There are three ports on the bottom of the cradle. COM 2 COM 1 connects to the host computer; COM 2 is used for daisy-chaining multiple cradles together; and, the Power Port supplies power to the cradle. Daisy-Chaining The cradle supports daisy-chaining when connected to a serial NOTE... -
Page 6: Wall Mounting
Slight pressure upwards should not move the cradle. Place the Phaser scanner in the cradle. PL360/460 Cradle Fasten the screws into the wall where the cradle should hang leaving about 1/8” (.3 cm) of the screw outside the wall for... -
Page 7: Sending Data To The Host Computer
Quick Reference Guide Inserting Phaser in the Cradle Place the Phaser scanner in the cradle so that the top of the scanner sits in the larger part of the cradle and the metal contacts on the bottom of the scanner touch the contacts on the cradle. -
Page 8: Troubleshooting
All Symbol devices are designed to be compliant with rules and regulations in locations they are sold and are labeled as required. Any changes or modifications to Symbol Technologies equipment, not expressly approved by Symbol Technologies, could void the user's authority to operate the equipment. -
Page 9: Laser Devices
Quick Reference Guide Reduce or eliminate vibration. Reduce or eliminate direct pressure. Provide adjustable workstations. Provide adequate clearance. Provide a suitable working environment. Improve work procedures. Vehicle or Forklift Installation Position your device within easy reach. Be able to access your device without removing your eyes from the road. -
Page 10: Power Supply
PRODUCTO LASER DE LA CLASE 1 CLASE 2 LUZ LASER NO MIRE FIJAMENTE EL HAZ PRODUCTO LASER DE LA CLASE 2 SWEDISH / SVENSKA KLASS 1 LASERPRODUKT KLASS 1 KLASS 2 LASERLJUS STIRRA INTE MOT STRÅLEN LASERPRODUKT KLASS 2 KOREAN / PL360/460 Cradle... -
Page 11: Radio Frequency Interference Requirements-Fcc
Quick Reference Guide indicate the recycling marks on the batteries used in sales, giveaway or promotion. Contact a qualified Taiwanese recycler for proper battery disposal. Symbol Rechargeable Batteries Symbol rechargeable battery packs are designed and constructed to the highest standards within the industry. -
Page 12: Marking And European Economic Area (Eea)
Marking and European Economic Area (EEA) Statement of Compliance Symbol Technologies, Inc., hereby, declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A Declaration of Conformity may be obtained from http://www2.symbol.com/doc/. - Page 13 Quick Reference Guide Magyar: Az EU-ban vásárlóknak: Minden tönkrement terméket a Symbol vállalathoz kell eljuttatni újrahasznosítás céljából. A termék visszajuttatásának módjával kapcsolatos tudnivalókért látogasson el a http://www.symbol.com/environmental_compliance weboldalra. Nederlands: Voor klanten in de EU: alle producten dienen aan het einde van hun levensduur naar Symbol te worden teruggezonden voor recycling.
-
Page 14: Wall Mounting Template
Wall Mounting Template Center Line of Cradle Mounting Socket 2 Use 1/8” drill bit for the screw holes. Wall 11/16” PL360/460 Cradle 1 5/16” Wall Mounting Socket 1 3 1/2”... - Page 15 Quick Reference Guide This page is intentionally blank.
