OWNER'S
MANUAL
13-INCH COLOR TV/VCR
W6313CC
This Owner's Manual is made of
recycled paper.
As an E
S
NERGY
TAR
Partner, our company has
determined that this product meets
the E
S
®
guidelines for
NERGY
TAR
energy efficiency. E
S
NERGY
a U.S. registered mark.
®
If you need additional assistance for set-up or operating
®
is
TAR
after reading owner's manual, please call
TOLL FREE : 1-800-968-3429
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.
Please read before using this equipment

Advertisement

Table of Contents
loading

Related Manuals for Sylvania W6313CC

Summary of Contents for Sylvania W6313CC

  • Page 1 OWNER’S MANUAL 13-INCH COLOR TV/VCR W6313CC This Owner’s Manual is made of recycled paper. ® As an E NERGY Partner, our company has determined that this product meets the E ® guidelines for NERGY ® energy efficiency. E NERGY a U.S. registered mark.

  • Page 2: C Important Safeguards

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.
  • Page 3 EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECT RICAL CODE NEC - NATI O NAL EL ECTRI CAL CO DE S2 8 9 8 A 13.Outdoor Antenna grounding-If an outside antenna or cable system is connected to the TV/VCR, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges.

  • Page 4: C Precautions

    LOCATION For safe operation and satisfactory performance of your TV/VCR, keep the following in mind when selecting a place for its installation: • Shield it from direct sunlight and keep it away from sources of intense heat. • Avoid dusty or humid places. •...

  • Page 5: Table Of Contents

    C IMPORTANT SAFEGUARDS ... . .2 C PRECAUTIONS ......4 C FEATURES .

  • Page 6: C Features

    • Infrared remote control • Bilingual on screen menu display selectable in English or Spanish • This shows the elapsed record- Real time counter– ing or playback time in hours, minutes, and sec- onds. The “–” indication will appear when the tape is rewound further than the tape counter position “0:00:00”.

  • Page 7: Operating Controls And Functions

    OPERATING CONTROLS AND FUNCTIONS - TV/VCR FRONT PANEL - AUDIO VIDEO 2 3 4 - REMOTE CONTROL - WAKE-UP POWER /SLEEP +100 MENU DISPLAY MUTE PLAY STOP RECORD SPEED T-PROG. GAME CLEAR COUNTER RESET POWER VOLUME CHANNEL STOP/EJECT 5 6 7 8 VIDEO input jack–...
  • Page 8 - REAR VIEW - Press to rewind the tape, or to view REW button– the picture rapidly in reverse during playback mode. (Rewind Search) button– • Press to select a mode from a particular menu. (for example: LANGUAGE or USER’S SET UP) Press to begin playback.

  • Page 9: C Preparation For Use

    PREPARATION FOR USE ANTENNA/CABLE CONNECTIONS From Cable System or Satellite Dish Satellite Box or Cable Box O UT (Not supplied) From Cable System 75-ohm Coaxial Cable (Not supplied) VHF/UHF COMBINED ANTENNA The VHF/UHF Rod Antenna (supplied) is detach- able. Insert the stem of the antenna into the hole on the upper-back portion of the TV/VCR.Connect the VHF/UHF Rod Antenna or VHF/UHF Combination Antenna to the ANT.

  • Page 10: External Input Mode

    TO RECORD A SCRAMBLED/UNSCRAMBLED CHANNEL 1) Set the TV/VCR channel selector to the output channel of the Cable Converter Box or Satellite Box. (Ex. CH3) 2)Select the channel to record from your Cable Converter Box or Satellite Box. EXTERNAL INPUT MODE When using an external input signal (another VCR or video camera), connect the player’s audio/video out- put cables to the AUDIO IN/ VIDEO IN jacks of...

  • Page 11: Clock Set Up (Auto / Manual)

    TO SELECT A DESIRED CHANNEL You can select the desired channel by using the CHANNEL K or L button or directly pressing the number buttons on the remote control. Note for using the number buttons: • When selecting cable channels which are higher than 99, press the +100 button first, then, press the last two digts.

  • Page 12: Channel Set Up Again

    Select “SETTING CLOCK” Press the MENU button on the remote control. Press the PLAY/K or STOP/L button to point to “SET- TING CLOCK”. Then, press the F.FWD/B button. Select “MANUAL CLOCK SET” Press the PLAY/K or STOP/L but- ton to point to “MANUAL CLOCK SET”.

  • Page 13: Selecting The Language

    Select “CHANNEL SET UP” Press the MENU button on the remote control. Press the PLAY/K or STOP/L but- ton to point to “CHANNEL SET UP”. Then, press the F.FWD/B button. Select “ADD/DELETE CH” Press the PLAY/K or STOP/L but- ton to point to “ADD/DELETE CH”.

  • Page 14: C Tv Operation

    WATCHING A TV PROGRAM Turn on the TV/VCR Press the POWER button to turn on the TV/VCR. Select the channel number Press the CHANNEL K or L button to select your desired channel number or press the number buttons on the remote control. Remember: If the TV/VCR is connected to a cable box or satellite box, the TV/VCR must be on CH3 or CH4, then the channel to be viewed must be selected...

  • Page 15: Closed Caption System

    CLOSED CAPTION SYSTEM You can view specially labeled (cc) TV programs, movies, news, pre-recorded tapes with either a dia- logue caption or text display. By choosing the caption mode, you CAPTION mode: can watch dramas, movies and news while captioning the dialogues and the contents of news.

  • Page 16: Mpaa Rating Set Up

    Select your desired item Press the PLAY/K or STOP/L but- ton to point to your desired item. Then, press the F.FWD/B button to select [BLOCK] or [VIEW]. • When you select the rating category and turn it [BLOCK], the higher rating will turn [BLOCK] automatically.

  • Page 17: Fm Mode

    FM MODE This function enables you to receive FM radio broad- casting. Set the FM mode Press the TV/FM button on the remote control. The radio frequency appears on the TV screen. Select the radio frequency you want to receive Press the CHANNEL K or L button until your desired radio frequency appears.

  • Page 18: Search

    Select “ALL” or “BLANK” Press the PLAY/K or STOP/L button to point to “REPEAT PLAY”. Press the F.FWD/B or REW/s button repeatedly until your desired selection [ALL] or [BLANK] appears. Exit the Repeat Play setting Press the MENU button on the remote control to return to the TV mode.

  • Page 19: Still Picture

    Begin Time Search By pressing the REW/s or F.FWD/B button, the TV/VCR will rewind or fast forward to the specified point. The time counts down as the searching progresses. When 0:00 is reached, the tape will start playback automatically. TO CANCEL THE TIME SEARCH at this point Press the STOP/EJECT button on the TV/VCR or the remote control.

  • Page 20: C Recording

    TWO DIFFERENT TAPE SPEEDS Before recording, select the tape speed from : SP mode (Standard Play) or SLP mode (Super Long Play). The table below shows the maximum recording/play- back time using T60, T120 or T160 tapes in each mode. Tape Speed Recording/Playback Time Type of tape...

  • Page 21: Timer Recording

    • When the REC/OTR button is pressed 18 times, the TV/VCR returns to the Normal Recording mode. • To stop the OTR operation, press the STOP button on the TV/VCR or on the remote control. • To show the remaining time, press the DISPLAY button on the remote control so that “OTR”...

  • Page 22: Timer Program Extension

    Set the channel number Press the PLAY/K or STOP/L but- ton until the desired channel num- ber appears. (Example: CH61) Then, press the F.FWD/B button. Remember: If your TV/VCR is connected to a cable or satellite box, you must set the TV/VCR to channel 3 or 4 to match the output channel of the box.

  • Page 23: Hints For Automatic Timer

    TO CORRECT A PROGRAM • While setting a program; press the REW/s but- ton to go back one step and enter the correct num- bers using the PLAY/K or STOP/L button. • After setting a program; 1)Press the POWER button. 2)Repeat steps [1] - [2] on page 21.

  • Page 24: Sleep Timer

    Select “WAKE UP TIMER” Press the WAKE-UP/SLEEP button on the remote control once, and confirm “ON/OFF” is pointed. Press the F.FWD/B or REW/s button until [ON] appears. Select “TV” or “TAPE” Press the PLAY/K or STOP/L but- ton until it points to “TV/TAPE”. Press the F.FWD/B or REW/s button, and select [TV] or [TAPE].

  • Page 25: C On Screen Display

    To check the Counter, Clock and Channel number on the TV screen, press the DISPLAY button on the remote control. Each time you press the DISPLAY button on the remote control, the TV screen will change as follows: WHEN THE CLOSED CAPTION MODE IS OFF: •...

  • Page 26: Troubleshooting Guide

    TROUBLESHOOTING GUIDE If you have followed the instructions contained in this manual and have difficulty in operating your TV/VCR, locate the PROBLEM in the left column below. Check the corresponding CORRECTIVE ACTION column to remedy the problem. PROBLEM No power. No picture and sound.

  • Page 27: C Specifications

    GENERAL SPECIFICATIONS CRT : 13 inch in-line gun, 90˚ deflection tube Television system : NTSC-M Closed caption system :§15.119/FCC Video Heads : Rotary two-head Tape width : 1/2 inch Tape speed SP : 33.40mm/sec. LP : 16.67mm/sec. SLP : 11.12mm/sec. Tuner channel TV VHF Low : #2~#6...

  • Page 28: Controles De Operación Ysus Funciones

    CONTROLES DE OPERACIÓN Y SUS FUNCIONES NOTA: No recomendamos utilizar mandos a distancia universales. No todas las funciones pueden ser controladas mediante un mando a distancia universal. Si decide utilizar un mando a distancia universal con esta unidad, tenga en cuenta que con el número de código dado tal vez no se pueda controlar la unidad.

  • Page 29: Panel Trasero

    - PANEL TRASERO - • Púlselo para introducir dígitos cuando establezca un programa. (Por ejemplo: Para ajustar el reloj o establecer un pro- grama de temporizador) 10 Botón de avance rápido (F.FWD)– Púlselo para avanzar rápidamente la cinta, o para ver la imagen en avance rápido durante el modo de reproducción.

  • Page 30: Conexiones De Antena/Cable

    Desde el cable coaxial o caja de emisiones vía Caja de CATV satélite de 75 ohm del o caja de emi- sistema de Cable siones vía satélite (no incluído) O UT Desde el sistema de Cable Cable coaxial de 75 ohm (no incluído) ANTENA COMBINADA DE VHF/UHF La antena de varilla de VHF/UHF (incluído) es desmontable.

  • Page 31: Preparación De Canales Por Primera Vez

    PREPARACIÓN DE CANALES POR PRIMERA VEZ 1) Enchufe el cable de alimentación del televisor/videograbadora en una toma de CA estándar. NOTA: Si aparezcan algunos digitos en el rincón de la pantalla, pulse el botón POWER sin desenchufar el cable de alimentación. 2) Pulse el botón POWER para encender el televisor/videograbadora.

  • Page 32: Limited Warranty

    FUNAI CORP. will repair this SYLVANIA product, free of charge in the USA in the event of defect in materials or workmanship as follows: DURATION: PARTS: FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year from the date of original retail purchase.
