Sylvania SRT22134 Owner's Manual

Color tv/vcr 13/19 inch
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S
MANUAL
COLOR TV/VCR
SRC22134
SRC22194
This Owner's Manual is made of
recycled paper.
As an E
S
NERGY
TAR
Partner, our company has
determined that this product meets
the E
S
®
guidelines for
NERGY
TAR
energy efficiency. E
S
NERGY
a U.S. registered mark.
®
If you need additional assistance for set-up or operating
®
is
TAR
after reading owner's manual, please call
TOLL FREE : 1-800-968-3429
(13 inch)
(19 inch)
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.
Please read before using this equipment

Advertisement

Table of Contents
loading

Related Manuals for Sylvania SRT22134

Summary of Contents for Sylvania SRT22134

  • Page 1 OWNER’S MANUAL COLOR TV/VCR SRC22134 SRC22194 This Owner’s Manual is made of recycled paper. ® As an E NERGY Partner, our company has determined that this product meets the E ® guidelines for NERGY ® energy efficiency. E NERGY a U.S. registered mark. (13 inch) (19 inch) INSTRUCCIONES EN ESPAÑOL INCLUIDAS.

  • Page 2: C Important Safeguards

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.
  • Page 3 EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECT RICAL CODE NEC - NATI O NAL EL ECTRI CAL CO DE S2 8 9 8 A 13.Outdoor Antenna grounding-If an outside antenna or cable system is connected to the TV/VCR, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges.

  • Page 4: C Precautions

    LOCATION For safe operation and satisfactory performance of your TV/VCR, keep the following in mind when selecting a place for its installation: • Shield it from direct sunlight and keep it away from sources of intense heat. • Avoid dusty or humid places. •...

  • Page 5: Table Of Contents

    C IMPORTANT SAFEGUARDS ... . .2 C PRECAUTIONS ......4 C FEATURES .

  • Page 6: C Features

    • Rotary 4-head Record/Playback System– heads ensure excellent picture quality and special effects playback. • Fast-forwards to start of next recording. Index Search– • View recorded program at slower Slow Motion– than normal speed. • Infrared remote control • Bilingual on screen menu display selectable in English or Spanish •...

  • Page 7: Operating Controls And Functions

    OPERATING CONTROLS AND FUNCTIONS This manual covers 13 " and 19 " . The operation of the two models are exactly the same except the appearance. 19 " model is illustrated in this manual. - TV/VCR FRONT PANEL - VIDEO - REMOTE CONTROL - [ SRC22134 ] WAKE-UP...
  • Page 8 - REAR VIEW -* Press to rewind the tape, or to view REW button– the picture rapidly in reverse during playback mode. (Rewind Search) button– • Press to select a mode from a particular menu. (for example: LANGUAGE or USER’S SET UP) Press to begin playback.

  • Page 9: C Preparation For Use

    PREPARATION FOR USE ANTENNA/CABLE CONNECTIONS From Cable System or Satellite Dish Satellite Box or Cable Box O UT (Not supplied) From Cable System 75-ohm Coaxial Cable (Not supplied) VHF/UHF COMBINED ANTENNA The VHF/UHF Rod Antenna (supplied with 13” model only) is detachable. Insert the stem of the antenna into the hole on the upper-back portion of the TV/VCR.Connect the VHF/UHF Rod Antenna or VHF/UHF Combination Antenna to the ANT.

  • Page 10: External Input Mode

    TO RECORD A SCRAMBLED/UNSCRAMBLED CHANNEL 1) Set the TV/VCR channel selector to the output channel of the Cable Converter Box or Satellite Box. (Example: CH3) 2) Select the channel to record from your Cable Converter Box or Satellite Box. EXTERNAL INPUT MODE When using an external input signal (another VCR or video camera), connect the player’s audio/video out- put cables to the AUDIO IN/ VIDEO IN jacks of...

  • Page 11: Clock Set Up (Auto / Manual)

    TO SELECT A DESIRED CHANNEL You can select the desired channel by using the CHANNEL K or L button or directly pressing the number buttons on the remote control. Note for using the number buttons: • When selecting cable channels which are higher than 99, press the +100 button first, then, press the last two digits.

  • Page 12: Channel Set Up Again

    Select “SETTING CLOCK” Press the MENU button on the remote control. Press the PLAY/K or STOP/L button to point to “SET- TING CLOCK”. Then, press the F.FWD/B button. Select “MANUAL CLOCK SET” Press the PLAY/K or STOP/L but- ton to point to “MANUAL CLOCK SET”.

  • Page 13: Selecting The Language

    Select “CHANNEL SET UP” Press the MENU button on the remote control. Press the PLAY/K or STOP/L but- ton to point to “CHANNEL SET UP”. Then, press the F.FWD/B button. Select “ADD/DELETE CH” Press the PLAY/K or STOP/L but- ton to point to “ADD/DELETE CH”.

  • Page 14: C Tv Operation

    WATCHING A TV PROGRAM Turn on the TV/VCR Press the POWER button to turn on the TV/VCR. Select the channel number Press the CHANNEL K or L button to select your desired channel number or press the number buttons on the remote control. Remember: If the TV/VCR is connected to a cable box or satellite box, the TV/VCR must be on CH3 or CH4, then the channel to be viewed must be selected...

  • Page 15: Closed Caption System

    CLOSED CAPTION SYSTEM You can view specially labeled (cc) TV programs, movies, news, pre-recorded tapes with either a dia- logue caption or text display. By choosing the caption mode, you CAPTION mode: can watch dramas, movies and news while captioning the dialogues and the contents of news.
  • Page 16 Select your desired item Press the PLAY/K or STOP/L but- ton to point to your desired item. Then, press the F.FWD/B button to select [BLOCK] or [VIEW]. • When you select the rating category and turn it [BLOCK], the higher rating will turn [BLOCK] automatically.

  • Page 17: Fm Mode (Src22134 Only)

    CHANGE ACCESS CODE To change access code, follow the steps. Press the MENU button so that the TV/VCR SETUP display appears on the TV screen. Press the PLAY/K or STOP/L but- ton to point to "V-CHIP SET UP". Then, press the F.FWD/B button. Use the number buttons to enter 4- digit access code.

  • Page 18: Normal Playback

    NORMAL PLAYBACK Make sure ... • TV/VCR power must be turned on. Insert a prerecorded tape If the erase-protection tab has been removed, the TV/VCR will start playback automatically. To begin playback Press the PLAY button. Note: If any menu is activated on the screen, the PLAY button does not function.

  • Page 19: Slow Motion

    NOTES: • Time Search can be set up to a maximum of 9 hours 50 minutes (9:50) by 10 minutes at a time. • This function will not operate in recording mode. In the example below: To watch a program that is 2 hours, 50 minutes from the present tape position, in either direction.

  • Page 20: Vertical Hold Control

    VERTICAL HOLD CONTROL In the Pause/Still mode only, when the picture begins to vibrate vertically, stabilize the picture by pressing the CHANNEL K or L button. NOTE: If there are video noise lines on the screen, see Tracking Adjustment section. STILL PICTURE You can view a still picture on the TV screen during playback (the Still mode).

  • Page 21: Otr (One Touch Recording)

    OTR (One Touch Recording) This function enables you to set the recording length simply by pressing the REC/OTR button on the VCR. 1)Begin OTR by pressing the REC/OTR button on the VCR repeatedly until the desired recording length appears. Recording stops when 0:00 is reached.

  • Page 22: Timer Program Extension

    For every day recording : To record a TV program at the same time on the same channel every day. (Example: Monday through Sunday) Press the STOP/L (down) but- ton until “EVRY DAY” appears. Then, press the F.FWD/B button. For weekly recording : To record a TV program at the same time on the same channel every week.

  • Page 23: Hints For Automatic Timer

    TO CANCEL AN AUTOMATIC TIMER RECORDING • After setting a program; 1)Press the POWER button. 2)Repeat steps [1] ~ [2] under TIMER RECORD- ING, page 21, and select a program you want to cancel. 3)Press the T-PROG. CLEAR button. 4)Press the MENU button on the remote control to return to TV mode.

  • Page 24: Sleep Timer

    Select “TV” or “TAPE” Press the PLAY/K or STOP/L but- ton until it points to “TV/TAPE”. Press the F.FWD/B or REW/s button, and select [TV] or [TAPE]. Set wake up time Press the PLAY/K or STOP/L but- ton until it points to “TIME”. Press the F.FWD/B or REW/s button until your desired wake up time appears.

  • Page 25: C On Screen Display

    To check the Counter, Clock and Channel number on the TV screen, press the DISPLAY button on the remote control. Each time you press the DISPLAY button on the remote control, the TV screen will change as follows: WHEN THE CLOSED CAPTION MODE IS OFF: •...

  • Page 26: C Troubleshooting Guide

    TROUBLESHOOTING GUIDE If you have followed the instructions contained in this manual and have difficulty in operating your TV/VCR, locate the PROBLEM in the left column below. Check the corresponding CORRECTIVE ACTION column to remedy the problem. PROBLEM No power. No picture and sound.

  • Page 27: C Specifications

    GENERAL SPECIFICATIONS CRT : 13 or 19 inch in-line gun, 90˚ deflection tube Television system : NTSC-M Closed caption system :§15.119/FCC Video Heads : Rotary four-head Tape width : 1/2 inch Tape speed SP : 33.40mm/sec. LP : 16.67mm/sec. SLP : 11.12mm/sec.

  • Page 28: Panel Delantero

    CONTROLES DE OPERACIÓN Y SUS FUNCIONES ......28 CONEXIONES DE ANTENA/CABLE ..30 MODO DE ENTRADA EXTERNA .

  • Page 29: Panel Trasero

    (Por ejemplo: Para ajustar el reloj o establecer un pro- grama de temporizador) [ Control remoto ] 7 Botón de televisor/modulación de frecuencia (TV/FM) (SRT22134) – Establece el modo FM. 7 (Botón de expulsión (EJECT) (SRT22194)– Púlselo en el modo de parada para expulsar la cinta del televisor/videograbadora.
  • Page 30 22 Botón de pausa/imagen fija (PAUSE/STILL)– Púlselo para detener temporalmente la cinta durante la grabación o para ver una imagen fija durante la repro- ducción. 23 Botón de silenciamiento (MUTE)– Silencia el sonido. Púlselo de nuevo para recuperar el sonido. 24 Botón de retorno de canal (CHANNEL RETURN)–...

  • Page 31: Modo De Entrada Externa

    MODO DE ENTRADA EXTERNA Cuando utilice una señal de entrada externa (otra videograbadora o una videocámara), conecte los cables de salida de audio/vídeo del equipo de reproducción a las tomas AUDIO IN/VIDEO IN de su televisor/videograbadora. Y luego pulse el botón CHAN- NEL K o L hasta que “AUX”...
  • Page 32 Get it fixed, at your home or ours! For repair of major brand appliances in your own home… no matter who made it, no matter who sold it! 1-800-4-MY-HOME lawn equipment and electronics for repair, call for the location of your nearest Sears Parts & Repair Center. For the replacement parts, accessories and owner’s manuals that you need to do-it-yourself, call Sears PartsDirect 1-800-366-PART...
