Summary of Contents for Sylvania SMPK2038
- Page 1 SMPK2038...
- Page 2 Portable Media Player Your Pocket Guide Install Software Get Connected Transfer Media Plug Your Ears & Enjoy...
-
Page 3: Table Of Contents
What’s in the blister? Know Your Player Well System Requirement Software Installation Connect & Charge Transfer Software Operation Language Selection Music Playback Edit Lyrics Repeat Mode EQ Mode Video Playback Photo Browse E-Book Records Game Technical Data Trouble Shooting 7 - 8 9 - 12... -
Page 4: What's In The Blister
What’s in the blister? What’s in the blister? Portable Media Player Earphone USB Cable Portable Media Player Your Pocket Guide Install Software Get Connected Transfer Media Plug Your Ears & Enjoy Your Pocket Guide CD-ROM containing: Media player driver for Windows®... -
Page 5: Know Your Player Well
Front View Bottom View General Previous button Music M button Next button Volume button Play/Pause button Movie USB port Earphone jack On/Off switch Images Press Power On/Off Switch the On/Off switch long Turn On/Off Hold Scroll through lists Select Option Return to previous menu long Hold... -
Page 6: System Requirement
System Requirement You’ll need a computer with: Windows® 98/98SE/ME/2000/XP/Vista Pentium Class or faster Processor CD-ROM Drive 64MB RAM 30MB free hard disk space USB Port... -
Page 7: Software Installation
Software Installation Software Utilities Installation Insert the CD into the CD ROM drive of your PC. Click Setup.exe to start driver installation. Follow the on-screen-menu to complete the installation. For Windows® 98/98SE users, please install the driver in the CD-ROM before downloading any files to your player . Click Close once you reach the... -
Page 8: Connect & Charge
Connect & Charge Connect Your player will be charged while being connected to PC through the USB cable. You will see the charging animation in the bottom right hand corner of the display. The player is fully charged when the charging animation stops. -
Page 9: Transfer
Transfer Get Your Player Connected Step 1: Set the Online Device of the player as USB Disk (Refer to Page 6), then connect it to your PC by USB cable. Once the connection is successfully made, the above screen display (1) would be shown. - Page 10 Step 3: Double click the Removable Disk icon. Note: Do not disconnect the USB cable once you click into the removable disk window. Such action may cause data loss or problems to the player. Drag and drop your media files into the removable disk.
-
Page 11: Software Operation
Software Operation Software Operation You can convert your favorite video file in any other format into the .AMV format with the help of the AMV converter Programs\MP3 Player Utilities 4.13\AMV Converter The converting progress is shown as below. - Page 12 Software Operation Enjoy Your AMV Movie To enjoy the converted movie on your PC, you can play it thru AMV player Programs\MP3 Player Utilities 4.13\AMV Player...
- Page 13 Software Operation Software Operation Your can enjoy songs from both PC and your player thru Media Manager Programs\MP3 Player Utilities 4.13\ Media Manager You can also convert your recorded .ACT voice into .WAV format thru the Media Manager...
-
Page 14: Software Operation
You are also allowed to format the memory of your player, or divide it into two partitions in MP3 Player Utilities 4.13\MP3 Player Disk Manager If the updated version is available, please use Programs\ MP3 Player Firmware Upgrade Tool to upgrade it. Software Operation... - Page 15 Setup Firmware Version Firmware Upgrade Exit...
-
Page 16: Music Playback
Music Playback Music Playback A-B repeat While playing music, you can press Press to select Replay Mode and then press to select Replay. The mark A is flashing on the display and wait for the setting. Press flashing stopped. Press to set mark B. -
Page 17: Edit Lyrics
Edit Lyrics You can copy the synchronous lyrics from internet, and create a new Text Document on your PC, paste them, and then select to save this document in the extension of .LRC shown as below. Edit Lyrics Then put both .LRC and .MP3 (or .WMA) files of the same song into the same folder in the removable disk. -
Page 18: Repeat Mode
Repeat Mode Repeat Mode Procedure: In PLAYING mode (1), press while playing music to enter the selection menu screen (2). Choose to enter the Repeat menu screen (3). 8 Repeat Modes are available: Normal, Repeat One, Folder, Repeat Folder, Repeat All, Random, Intro, Repeat and press A-B Repeat. -
Page 19: Eq Mode
EQ mode Listen to your music at its best Procedure: In PLAYING mode (1), press while playing music to enter the selection menu screen (2). Press to select Equalizer and press to enter the Equalizer menu screen (3). 7 EQ Modes are available: Natural, Rock, Pop, Classic, Soft, Jazz, DBB. -
Page 20: Video Playback
Video Playback Select Video on the main menu and press the video playback mode. You can select different movies by pressing and press Video Playback to enter to start playing. While enjoying video, you can press the movie, and press to move back to the previous movie or jump to the next one. -
Page 21: Photo Browse
Photo Browse Select Photo on the main menu and press enter the ROOT folder with listed photos under it. You can select different photos by pressing and press to view. During photo browse, you can switch to the previous or next photo by pressing too. -
Page 22: Ebook
Ebook Ebook Press to select Ebook on the main menu, and press to enter it. Press and press to enter it. Press again to return to previous page. While reading an article, press to bookmark the text. After entering Ebook, press Manual Play or Auto Play to select desire text file , be scrolled automatically according to the Auto Play Gap you preset. -
Page 23: Records
Voice Recording Press to select Record on the main menu, and press to enter it. Press to start it and press to save the recorded voice. To preset the format of the recorded voice file, you could select to go into Rec Type on the sub-menu of Recorder. -
Page 24: Game
Game Game Press to select and press Game confirm. RusBlock After entering the sub-menu, press and press to confirm. RusBlock Press to move the block and press it. Press to play/ pause the game and hold to return to main menu. Puzzle After entering the sub-menu, press and press... -
Page 25: Technical Data
General Information Power Supply 140mA, 3.7V Lithium battery Dimensions 41mm x 85mm x 9mm Weight Display 1.5 inch Colour Display 128MB/256MB/512MB/1GB/2GB/4GB Capacity internal flash memory Windows?98/98SE/Me/2000/XP/Vista Operating System MAC OS 9.0, 10.0 USB 2.0 Full Speed Interface Audio Playback .M P3 (8kbps ~ 320kbps), Compression .WMA (5kbps ~ 384kbps) Format... -
Page 26: Trouble Shooting
Trouble Shooting What should I do if… Q: I cannot enter the MUSIC mode after using the player for a period of time. A: You should format the memory of the player under connection to PC. (Be sure you remember to backup the data in your player before performing the above action.) Q: I cannot convert my video file into the .AMV format. - Page 27 More Disposal of your old product Electrical and electronic equipment (EEE) contains materials, parts and substances which can be dangerous to the environment and harmful to human health if wastes of electrical and electronic equipment (WEEE) are not disposed correctly. Equipments which are marked with the WEEE logo (as shown on the right), should not be thrown away with your household waste.
