REVERB CONTROLS
Reverb Bypass Footswitch & LED
Footswitch bypasses reverb effect. LED Illuminates when reverb is active.
Decay
This control adjusts the reverb decay time, or length of the reverb signal.
Counterclockwise settings produce smaller room and ambient sounds, while
settings closer to fully clockwise can produce the sound of huge spaces.
Damp
Attenuates high frequencies and "darkens" reverb tail.
Level (Reverb)
Controls "wet/dry" reverb signal mix.
Reverb
Type Switch
Classic diffuse space with a
HALL
sense that walls are far apart.
Smaller, more lively feel
ROOM
Classic modern reverb effect with
octave-up pitch shift in loop between
reverb input and output. Successive
octaves are added as reverb decays,
imparting a blooming, atmospheric effect.
Small-space reverb, plus gated and
SPECIAL
reverse reverb. Set EXTRA and LEVEL
control knobs at full clockwise position
for "full-wet" reverse effect.
Very large space with some pitch
modulation. Ideal for ambient pads and
Description
than HALL.
swells.
Extra
Modifies an "extra" algorithm-specific parameter. On "Hall" and
"Room"reverb settings it controls "tilt" between high and low
frequency decay times. On Special "Shimmer" setting (see
"Variation Switch" below) it controls regeneration of cascading octaves.
On Special "Gated/Reverse" setting (see "Variation Switch" below) it
controls reverb tail shape, and on Special "Modulated" setting it controls
modulation depth.
Type Switch
Toggle among Hall, Room and Special reverb types
Variation Switch
Toggles among three different variations for each reverb type:
Variation
Switch
1: small hall
Controls amount of low-frequency rolloff in reverb decay. Turn
2: medium hall
EXTRA knob counter-clockwise for more bass in reverb tail;
3: large hall
1: small room
2: medium room
3: large room
Controls amount of regeneration into octave-up reverb effect,
1: Shimmer
which determines how much of the octave is heard and how
Controls reverb tail shape. At full counterclockwise, shape is a
2: Gated/
typicaldecaying taper. At noon produces a gated shape; at full
Reverse
3: Modulated
"Extra" Knob Function
clockwise for less (similar to a bass cut).
much octaves will "stack."
clockwise produces reverse reverb.
Controls reverb modulation depth
(modulation rate fixed at 0.1 Hz).
