NOTICE
When handling supplemental restraint system components (removal,
installation or inspection, etc.), always follow the direction given in the repair
manuals listed above to prevent accidents and supplemental restraint
system malfunction.
FOREWORD
This wiring diagram manual has been prepared to provide
information on the electrical system of the 2005 tC.
Applicable models: ANT10 Series
For service specifications and repair procedures of the above
models other than those listed in this manual, refer to the
following manuals;
Manual Name
D 2005 SCION tC Repair Manual
D 2005 SCION tC New Car Features
All information in this manual is based on the latest product
information at the time of publication. However, specifications
and procedures are subject to change without notice.
Pub. No.
Volume 1
RM1104U1
Volume 2
RM1104U2
NCF264U
