- Page 1 DA ..27 BRUKSANVISNING NO .37 GEBRAUCHSANWEISUNG DE...47 INSTRUCTIONS FOR USE EN...58 MODE D’EMPLOI FR...68 GEBRUIKSAANWIJZING NL...79 8211-0007-70 S T I G A P A R K D I E S E L D I E S E L 4 W D...
- Page 2 J K L...
-
Page 7: Safety System
1 GENERAL This symbol indicates WARNING. Seri- ous personal injury and/or damage to property may result if the instructions are not followed carefully. You must read these instructions for use and the accompanying pamphlet “SAFETY INSTRUCTIONS” careful- ly, before starting up the machine. 1.1 SYMBOLS The following symbols appear on the machine. - Page 8 2.4.2 Implement lifter, hydraulic (4:M) (4WD) The hydraulic implement lifter only works when the engine is running and the clutch pedal and parking brake pedal are not depressed. The imple- ment lifter is controlled using the lever (4:M). The lever has the following four positions: Floating position.
- Page 9 2.4.9 Ignition lock (4,5:I) Ignition lock used for starting/stopping the engine. There are 3 positions: 1. Stop position – the engine is short-cir- cuited. The key can be removed. 2. Operating position 3. Start position – the electric start motor is activated when the key is turned to the spring-loaded start position.
-
Page 10: Areas Of Use
Risk of burns and crushing in- juries. 3 AREAS OF USE The machine may only be used for the following tasks using the genuine STIGA accessories stated. Work Accessories, STIGA genuine Mowing Using mowing decks: 121 M,... -
Page 11: Safety Checks
Only fill or top up with fuel outdoors, and never smoke when filling or top- ping up. Fill with fuel before starting the engine. Never remove the fuel cap or fill with fuel while the engine is running or still warm. -
Page 12: Operating Tips
5.1 Service programme In order to keep the machine in good condition as regards reliability and operational safety as well as from an environmental perspective, STIGA’s Ser- vice programme should be followed. The contents of this programme can be found in the attached service log. -
Page 13: Tyre Pressure
5.2 Preparation All service and all maintenance must be carried out on a stationary machine with the engine switched off. Prevent the machine from rolling by al- ways applying the parking brake. Stop the engine. Prevent unintentional starting of the motor by always stopping the motor and disconnecting the negative cable from the battery. -
Page 14: Belt Transmissions
The engine must be cold when the con- densation id drained, otherwise there is a risk of fire. Smoking, fires, sparks and other heat sources are prohibited in the proximity when the condensation is drained. There is a fire risk. Drain the condensation as follows: 1. -
Page 15: Air Filter, Engine
5.10Steering The steering must be checked/adjusted after 5 hours of operation and thereafter after 100 hours of operation. 5.10.1Checks Briefly turn the steering wheel back and forth. There must be no mechanical clearance in the steering chains. 5.10.2Adjustment Adjust the steering chains if required as follows: 1. -
Page 16: Air Intake
3. Disconnect the air filter housing by slackening off the wing nut (23:H). 4. Remove the filter (24:I) by slackening off the ridged nut (24:J). Never direct the flow of compressed air towards the body. The penetration of air into the blood stream can be fatal. 5. - Page 17 w w w. s t i g a . c o m GGP Sweden AB · Box 1006 · SE-573 28 T RANÅ S...
