NAMES OF MACHINE PARTS
Bobbin cover (on machine)
XE8992-101
Accessory bag
XC4487-021
Embroidery frame with decal set
H 36 cm × W 24 cm
(H 14 inches × W 9-1/2 inches)
SA449S (Americas)
EF95S: XH4465-001 / 115D05E0017 (Europe)
EF95SAP: 115D05E7017 (other areas)
Embroidery frame with decal set
H 18cm × H 13cm
(H 7 inches × W 5 inches)
SA439S (Americas)
EF75S: XH4464-001 / 115D05E0016 (Europe)
EF75SAP: 115D05E7016 (other areas)
Embroidery bobbin thread (#90, white)
EBT-PE (Americas)
EBT-PEN: XC5996-101 (Europe)
EBT-PEN: 115G05E7002 (other areas)
Embroidery positioning sticker sheets × 4
SAEPS2 (U.S.A.) / SAEPS2C (Canada)
EPS2: XG6749-001 / 115Z05E000E (Europe)
EPS2: XF0763-001/ EPS2CN: 115Z05E600E
(other areas)
Lens calibration sheet
XH4336-001
Operation Manual
This manual
Quick Reference Guide
XH3875-001 (Americas)
XH3951-001 (other areas)
Memo
• The screw for the embroidery foot is available
through your authorized Brother dealer (Part code
XA5904-051).
• Please visit " http://s.brother/cpeab/ " to download
documents.
12
Part Name
Part Code
Accessories that are Included in Some
Countries or Regions
If these accessories are not included with your
machine, these are available as optional accessories.
Embroidery frame with decal set
H 10 cm × W 10 cm
(H 4 inches × W 4 inches)
SA438S (Americas)
EF74S: XH4463-001 / 115D05E0015 (Europe)
EF74SAP: 115D05E7015 (other areas)
Bobbin center pin and instruction sheet
XF5048-001
Stabilizer material
SA519 (Americas)
BM3: XG6683-001 / 115Z05E0007 (Europe)
BM3: XE0806-001/ BM3CN: 115Z05E6007
(other areas)
Bobbin clip × 10
XE3060-001
Memo
• Placing bobbin clips on bobbins helps prevent the
thread from unwinding from the bobbin. In
addition, snapping bobbin clips together allows the
bobbins to be conveniently stored and prevents
them from rolling around if they are dropped.
Part Name
Part Code
