FA D E R C LE A N I N G
The SK ONE faders may need lubrication from time to time. This will extend the
fader life and eliminate any potential damage due to extended heavy usage.
Cleaning Instructions
1. Remove the 3 fader knobs and 4 screws
located in the corners of the PROTEKT™
(see "
" inside) panel
and take the panel off the mixer.
2 . Remove the fader to be cleaned by
unscrewing the 2 outer screws (removing
the 2 inner screws will detach the fader
from the fader plate) and disconnect the
R E PL AC E M E N T PA RT S
To replace the cross or channel faders, follow steps 1 and 2 of the cleaning
instructions. The following replacement parts are available from Stanton or your
local Stanton dealer.
PL-SK1
Two way input toggle switch
3PL-SK1
Three way input toggle
switch with FLASH™
LF-SK1
Channel input fader
CF-SK1
Crossfader
ROTATING AND REPLACING THE INPUT TOGGLE SWITCHES
ROTATING I NST RU C TI O NS
1 . Remove the PROTEKT™ panel
2. Remove the 2 outer screws from the tog-
gle switch plate (removing the 2 inner
screws will detach the switch from the
plate)
3. Rotate the plate to the desired position
and tighten the screws back in the top and
bottom holes
© 1999, Stanton Magnetics, LLC
cable coming from the mixer.
3. Spray a small amount of cleaner or
lubricant into both ends of the fader and
slide the fader back and forth a few times
to spread the fluid evenly throughout the
fader.
4. Shake and wipe off excess fluid before
re-assembling the fader.
PP-SK1
PROTEKT™ panel
PS-13US
US Power Supply (110v)
PS-13EU
European Power Supply (220v)
PS-13UK
UK only Power Supply (240v)
R E PLAC I N G I NST RU C TI O NS
1. Remove the PROTEKT™ panel
2. Remove the 2 outer screws from the tog-
gle switch plate (removing the 2 inner
screws will detach the switch from the
plate)
3. Remove the switch assembly and dis-
connect the cable coming from the mixer.
4. Set the replacement switch assembly in
the desired position and place the screws
back in the top and bottom holes.
SK ONE
Professional performance mixer
OWNER'S M A N U A L
STANTON MAGNETICS, LLC
2821 Evans St. Hollywood, FL 33020
(954) 929-8999 - Fax: (954) 929-0333
info@stantonmagnetics.com
